Summary of Contents for UCAN LV 360
- Page 2 When fastening directly into concrete or steel, use the proper stabilizer or guard, suited for the application. In this instruction manual you will also find illustrations of the LV 360 as well as information about cartridges, pistons, and spare parts. If you have...
- Page 3 TOOL HANDLING & USE cont'd..LIMITATIONS OF USE cont'd..10. Under no circumstances shall a loaded tool be left unattended. Fasteners with a shank diameter of 4.83mm (0.190 in) or less shall not be driven into steel: 11. Tools, whether loaded or not, must not be pointed at any person. that is less than 4.83mm (3/16 in) in thickness;...
- Page 4 IMPORTANT: To make successive fastenings,always insert the fastener before advancing magazine as in illustrations 1 & 2. Overdriving due to Clean and lubricate the tool as recommended in the Instruction using too strong a cartridge, too short a fastener, or too little resistance in Manual.
- Page 5 Repeat steps 1, 2 and 4 until the cartridge magazine has been Lift the end of the annular spring Slide out the complete exhausted (ten fastenings). To remove the magazine, slide the base and rotate toward top of tool. operating assembly. plate forward and pull the strip out from the top of the tool body.
- Page 6 DO NOT SPRAY the inside of the steel liner or magazine chamber on the piston sleeve. Lubricant Ear Plugs Spare Parts Safety Goggles spray ( Disposable ) UCAN Fastening Products provides a set of disposable sample ear plugs with each tool. These are not intended as permanent ear protection.
- Page 7 Item Description Part No. Item Description Part No. Body 301001 Firing Pin Assembly 301400 Pin, Trigger 301034 Spring Holder 301420 Holder, 301529 Spring 301421 Advance Bar 301422 Advance Bar 301530 Spring, Sear 301026 Holder Spring, 301531 Spring, Firing Pin 301025 Advance Bar Plug 301028...
- Page 8 UCAN Fastening Products' Distributor. using a Powder Actuated Tool. If your tool requires service or warranty repairs, contact a UCAN Distributor, who will determine whether the tool is field repairable or must be forwarded to a repair center.
- Page 9 Remember that P.A.T. fasteners are made of special steel and heat treated especially for these applications. Under no circumstances UCAN Fastening Products LV Powder Actuated Tools are indirect-acting should fasteners other than those recommended by the tool tools which conform to the requirements for low velocity class tools.
- Page 10 Unsuitable base materials will be: are inserted into the tool either individually or in a strip magazine which contains 10 cartridges. The UCAN LV360 uses .27 caliber loads in strip Too hard for the fastener to penetrate (hardened steel, welds, cast magazines.
- Page 11 VII. APPLICATION RULES - WARNINGS cont'd... VII. APPLICATION RULES - WARNINGS NOTE: To determine the correct length of drive pin for a particular For Concrete..application, add the thickness of the material to be fastened and the required depth of penetration into the base material. Do not fasten into cracks or spalled areas as this weakens holding power.
- Page 12 Do not use P.A.T. tools in explosive or flammable environments. This new fastening tool is a quality product of UCAN Fastening Products. It has been developed through study and research into the fastening Never leave a P.A.T. tool unattended in a place where it would be methods and applications of the building industry and associated trades.
