Techibel MCAF94R5IAA Technical & Service Manual

Dc inverter split system air conditioner
Hide thumbs
Table of Contents

Advertisement

Quick Links

TECHNICAL
& SERVICE MANUAL
MCAF94R5IAA
MCAF124R5IAA + GRF127R5I
DC INVERTER SPLIT SYSTEM AIR CONDITIONER
Indoor Model No.
MCAF94R5IAA
MCAF124R5IAA
Indoor Unit
MCAF94R5IAA
MCAF124R5IAA
RoHS
This product does not contain any hazardous substances prohibited by the RoHS Directive.
•
WARNING
• You are requested to use RoHS compliant parts for maintenance or repair.
• You are requested to use lead-free solder.
+ GRF97R5I
Product Code No.
3 871 300 03
(1 852 345 22)
3 871 300 04
(1 852 345 23)
These air conditioners employ new refrigerant R410A.
Pay special attention when servicing the unit.
FILE NO.
Outdoor Model No.
GRF97R5I
GRF97R5IAA
GRF127R5I
GRF127R5IAA
Outdoor Unit
GRF97R5I
GRF127R5I
REFERENCE NO.
Destination: Europe
Product Code No.
(1 852 345 25)
(1 852 345 26)
SM
700725
