- Page 1 OPERATING INSTRUCTIONS • ISTRUZIONI D’USO NOTICE D’UTILISATION • BEDIENUNGSANLEITUNG INSTRUCCIONES DE USO COOL / DRY / HEAT / FAN Models MCAF74R5TAA MCAF94R5TAA MCAF124R5TAA Split air conditioner system • Condizionatore d’aria split system Climatiseurs split • Split-klimagerät Acondicionador de aire de consola partida sistema split...
-
Page 2: Table Of Contents
CONTENTS NAME OF PARTS AND OPERATION SELECTOR SWITCH INSTALLATION LOCATION ELECTRICAL REQUIREMENTS SAFETY INSTRUCTIONS USING THE REMOTE CONTROL UNIT REMOTE CONTROL UNIT HOW TO SET THE PRESENT TIME COOLING HEATING AUTOMATIC OPERATION DEHUMIDIFYING (DRY) FAN ONLY ADJUSTING THE FAN SPEED SLEEP MODE SETTING THE TIMER ADJUSTING THE AIR FLOW DIRECTION... -
Page 3: Name Of Parts And Operation Selector Switch
NAME OF PARTS AND OPERATION SELECTOR SWITCH INDOOR UNIT OUTDOOR UNIT COOL MODE lamp INDOOR UNIT RESET button (Press to turn off the filter lamp and cancel the buzzer announcer) HEAT MODE lamp STANDBY lamp OPERATION lamp TIMER lamp FILTER lamp 1. -
Page 4: Installation Location
ELETRICAL REQUIREMENTS WARNING Before installation, check that the voltage of the electric supply The OFF position does not disconnect the power. Use the in your home or office is the same as the voltage shown on the main power switch to turn off power completely. nameplate. -
Page 5: Using The Remote Control Unit
OPERATION WITH THE REMOTE CONTROL UNIT USING THE REMOTE CONTROL UNIT HOW TO INSTALL BATTERIES CAUTION Remove the lid in the rear part of the remote control unit. Insert two AAA alkaline batteries of 1,5 V-DC. Make sure the batteries point in the direction marked in the Check that the circuit breaker on the power panel is turned ON and the the STANDBY lamp is light up. -
Page 6: Remote Control Unit
REMOTE CONTROL UNIT DISPLAY SENSOR TRANSMITTER Information are displayed when the remote control unit is switched on. A temperature sensor inside the remote control Operation Mode Displayed when data trasmitted unit detects the room temperature. When you press the buttons of the Or remote control unit lock Automatic remote control unit, the... -
Page 7: How To Set The Present Time
HOW TO SET THE PRESENT TIME DEFROSTING OF HEAT EXCHANGER OUTDOOR UNIT “STANDBY” Press the SET button for five seconds. The time indication When the outdoor temperature is low, frost or ice may appear on alone flashes. the heat exchanger coil, reducing the heating performance. When this happens, a microcomputer defrosting system operates. -
Page 8: Dehumidifying (Dry)
NOTE NOTE The air conditioner changes the operation mode (from cool to heat The above mentioned data make reference to the conditioner or vice versa, if one of the following conditions occurs: operating when the sensor on the remote control unit is ON. (Refer - ZONE A: changes if the difference between the room temperature to temperature sensor selector). -
Page 9: Setting The Timer
D) HOW TO CLEAR THE TIMER SETTING THE TIMER 1. Press the TIMER button to select the timer. There are four timers that can be selected on the remote 2. Press the CLEAR button if you want that every timer operation control.Two daily timers (designated as T1,T2) ,and two optional will be cleared. -
Page 10: Operation Without The Remote Control Unit
OPERATION WITHOUT THE REMOTE CONTROL UNIT If you have lost the remote control unit or it has troubles, follow the steps below. 1. WHEN THE AIR CONDITIONER IS STOPPED If you want to turn on the air conditioner push the MODE button with a pen to select the desired mode (COOL or HEAT). -
Page 11: Tips For Energy Saving
AIR FILTER TROUBLESHOOTING The filter behind the air intake grille should be checked and cleaned when the filter lamp lights up (see page 3). WARNING HOW TO REMOVE THE FILTER The use of portable telephones near the air-conditioner may cause disturbance to its normal operation and must be avoided. - Page 12 In order to carry on a constant improvement, our products can be modified without prior notice. Per garantire un costante miglioramento dei nostri prodotti, ci riserviamo di modificarli senza preavviso. Par souci d’amélioration constante, nos produits peuvent être modifiés sans préavis. Unsere Produkte werden laufend verbessert und können Vorankündigung abgeändert Werden.
