Please completely read and understand the entire manual before using, assembling and/or
disassembling your remote controlled car.
1/16TH SCALE 4WD ELECTRIC POWERED BUGGY/TRUGGY/MONSTER TRUCK
OFF ROAD TRUGGY
ITEM NO.: 16882
OFF ROAD MONSTER TRUCK
ITEM NO.: 16883
MODEL
NAME
16881
BUGGY
16882
TRUGGY
MONSTER
16883
TRUCK
Notification: This date is subject to change without the prior notice.
The series of cars are Ready to Run with battery pack of Li-ion
of the charger which is needed for charging your li-ion battery pack.
The cars feature 3-in-1 unit (ESC/receiver/ 5 wire servo) and 2.4GHz radio system, which are called entry-
level hobby grade products and suitable for R/C beginners. Ball bearings and brass bushes are installed
throughout the whole vehicles.
Many optional parts are available from factory and please refer to the part lists. If you perform a drive
train upgrade, replace the entire system ( such as motor, ESC, receiver , ball bearings and the like) so that
all components are properly matched. Any malfunction incurred by custom modification or incorrect
operation will void your warranty.
This product is not a toy. It is not intended for persons under 14 years of age, unless closely
supervised by an adult.
This manual is subject to change without prior notice.
LENGTH
WIDTH
260mm
175mm
265mm
205mm
270mm
215mm
INSTRUCTION MANUAL
OFF ROAD BUGGY
ITEM NO.: 16881
HEIGHT
WHEELBASE WHEEL SIZE GEAR RATIO
105mm
175mm
175mm
110mm
175mm
135mm
7.4V
,800mAH, the charger and the adapter
63mm(Dia.)
1: 9.28
25mm(Width)
70mm(Dia.)
1: 11.44
40mm(Width)
80mm(Dia.)
1: 11.44
45mm(Width)
MOTOR &
BATTERY
RC 380
Motor &
Li-ion
Battery
Pack (7.4V,
800mAH)
Advertisement
Table of Contents
Related Manuals for Haiboxing 16881 OFF ROAD BUGGY
Summary of Contents for Haiboxing 16881 OFF ROAD BUGGY
- Page 1 Please completely read and understand the entire manual before using, assembling and/or disassembling your remote controlled car. 1/16TH SCALE 4WD ELECTRIC POWERED BUGGY/TRUGGY/MONSTER TRUCK INSTRUCTION MANUAL OFF ROAD TRUGGY OFF ROAD BUGGY ITEM NO.: 16882 ITEM NO.: 16881 OFF ROAD MONSTER TRUCK ITEM NO.: 16883 MOTOR &...
-
Page 2: General Information
GENERAL INFORMATION This user's manual is designed for use with your vehicles and contains the instructions you will need to assemble, operate and maintain your vehicles. We know you are anxious to start driving, but it is very important that you take time to read the manual even if you are an experienced R/C driver. -
Page 3: Safety Information
SAFETY INFORMATION We want users to enjoy our RC vehicles and to operate them with care. Failure to operate your vehicle in a safe and responsible manner may result in injury to yourself, others or damage to property around you. Read and understand all instructions carefully before use and assembly/disassembly. -
Page 4: Battery Installation
GETTING FAMILIARIZED WITH YOUR 2.4GHz RADIO SYSTEM Your car is equipped with the new 2.4GHz radio system .Please read and understand all instructions below before operating. A: Steering Wheel 1: Steering Trim 4: Power Switch 7: Throttle Reverse B: Trigger 2: Steering Reverse 5: Steering Dual Rate 8: Green Indicator... - Page 5 TO BIND THE RECEIVER TO THE RADIO CONTROLLER Before running , make sure that the radio controller is bound with the receiver, which have normally been done at factory. If it is not the case, you are require to perform the binding procedure following the instructions below.
-
Page 6: Steering Trim
CHECK STEERING PERFORMANCE Ensure good steering performance. CENTRE TURN LEFT TURN RIGHT 1) To keep the car run straight in line , do not move the 3) Turn it right to allow your 2) Turn it left to allow your control wheel.(Keep it vehicle turn to right. - Page 7 TO TUNE THE STEERING DUAL RATE CONTROL DIAL Decrease Increase STEERING D/R This dial adjusts the overall travel of the steering servo. Push the dial forward for maximum steering. Pull the dial back to reduce the steering level. - Set the Steering Dual Rate Control Dial to Minimum first. To set the desired steering level increase it again whilst decelerating your vehicle.
-
Page 8: Charging The Battery Pack
CHARGING THE BATTERY PACK To be connected to the charging Charger Adapter socket. Charger (9V, 600mA) To be connected Li-ion Battery To be connected Pack -Use only the specified charger (9V,600mA) to charge the Li-ion battery pack. - The charger adapter is needed during charging, on which on the one side the charger is connected and on the other side the battery pack is connected. -
Page 9: Troubleshooting
MAINTAINING YOUR CAR After running your car, the following procedures should be performed regularly and will help to maintain your car's performance. Inspect your car for any obvious damage. Check the gears for wear, debris or broken/slipping teeth. Check the wheels and tighten the wheel screws properly. Check for loose screws in the chassis. -
Page 10: Part List
PART LIST-1 1-16 FOUR WHEEL DRIVE VEHICLES ITEM NO.: 16810 ITEM NO.: 16003 ITEM NO.:16004 ITEM NO.: 16005 2PCS 4PCS 4PCS 4PCS Steering Bush+ Steering Post Suspension Hinge Pins-Outside Suspension Hinge Pins-Inside Shock Coils +E-clip(2mm/4mm) ITEM NO.: 16006 ITEM NO.: 16007 ITEM NO.: 16008 ITEM NO.: H011 2PCS... - Page 11 PART LIST-2 1-16 FOUR WHEEL DRIVE VEHICLES ITEM NO.: 16048 ITEM NO.: 16049 ITEM NO.: 16050 ITEM NO.: 16051 Connector Connector changed changed Li-ion Battery Pack Motor RC 380 (25000rmp) 5-Wire Servo ( 19g) 3-in-1 Unit (7.4V, 25A) (7.4V, 800mAH) ITEM NO.: H021 ITEM NO.: P011 ITEM NO.:P100...
- Page 12 PART LIST-3 1-16 FOUR WHEEL DRIVE VEHICLES ITEM NO.: 16001 ITEM NO.:16090 ITEM NO.: 16019 ITEM NO.: 16091 BUGGY /TRUGGY ONLY MONSTER TRUCK ONLY BUGGY /TRUGGY ONLY MONSTER TRUCK ONLY Centre Drive Shaft (Needed for installing slipper Spur Gear Slipper Spur Gear Unit clutch) Centre Drive Shaft ITEM NO.:16093...
-
Page 13: Optional Parts
PART LIST-4 1-16 FOUR WHEEL DRIVE VEHICLES ITEM NO.: 16046W ITEM NO.: 16046K MONSTER MONSTER TRUCK TRUCK ONLY ONLY W/white W/black rims rims Wheels Complete(Truck) Wheels Complete(Truck) ITEM NO.:16071 ITEM NO.:16072 ITEM NO.: S128 ITEM NO.:S150 BUGGY ONLY TRUGGY / MONSTER TRUCK BUGGY ONLY BUGGY ONLY ONLY... - Page 14 UNITS ASSEMBLY VIEW SHOCK ASSEMBLY 16005 16024 FINISHED 16024 SERVO INSTALLATION 16018 16051 88021 16025 S149 FINISHED DIFF. ASSEMBLY (Fr./Rr.) 16026 BUGGY/TRUGGY ONLY 16804 H030 16020 S011 16811 （6.3*12.5*0.2mm) 16020 16020 16029 16020 16020 16811 （6.3*12.5*0.2mm) 16020 16804 16026 FINISHED...
- Page 15 DIFF. ASSEMBLY (Front) 16026 MONSTER TRUCK ONLY 16804 H030 16020 S011 16811 （6.3*12.5*0.2mm) 16020 16092 16020 16020 16020 16811 （6.3*12.5*0.2mm) 16020 16804 16026 FINISHED DIFF. ASSEMBLY (Rear) 16026 MONSTER TRUCK ONLY 16804 H030 16020 S011 16811 （6.3*12.5*0.2mm) 16020 16092 16020 16020 16020 16811...
- Page 16 STEERING ASSEMBLY VIEW 16007 88021 16025 16025 E-Clip(4mm) is applied here after the kit is assembled. 16810 16025 16025 16810 E-Clip(2mm) is applied here after the kit is assembled. S013 locked with S153 to the chassis 16810 from the bottom 16093 MONSTER TRUCK ONLY 16093...
-
Page 17: Exploded View
EXPLODED VIEW 16040 1-16TH SCALE 4WD ELECTRIC 16071 16039W(16039K) OFF ROAD BUGGY S062 S013 S062 16023 S150 S120 S062 16036 S120 S013 S062 16038 16027 16008 16026 16032 16006 16038 16003 16022 16038 16034 16004 16031 16071 16040 S020 S091 S029 H030 S013... - Page 18 16043 EXPLODED VIEW 16072 1-16TH SCALE 4WD ELECTRIC 16042W(16042K) OFF ROAD TRUGGY S013 16023 S062 16037 S062 S013 S029 S062 16027 16033 S062 16030 16008 16026 16006 S029 S138 16003 16022 16034 16072 16043 16004 S020 S091 S029 H030 S013 S091 S089 16006...
- Page 19 16045 EXPLODED VIEW 16072 1-16TH SCALE 4WD ELECTRIC 16042W(16042K) OFF ROAD MONSTER TRUCK S013 16023 S062 16037 S062 S013 S029 S062 16027 16033 S062 16030 16008 16026 16006 S029 S138 16003 16022 16072 16034 16045 16004 16092 S020 S091 H030 S029 S013 H030...
- Page 20 Please completely read and understand the entire manual before using, assembling and/or disassembling your remote controlled car. Thank for purchasing our product. This product is an authentic remote controlled vehicle (RC vehicle). It is not a toy. Read and understand this instruction manual thoroughly before operating the vehicle. If you are not familiar with RC vehicles, we recommend that seek out RC experts for reliable advice.
