- Page 1 GT200 GSM/GPRS/GPS Tracker User Manual TRACGT200UM002 Revision: 2.01 Quectel Wireless Solutions www.quectel.com Info@quectel.com...
- Page 2 TRACGT200UM002 General Notes Quectel offers this information as a service to its customers, to support application and engineering efforts that use the products designed by Quectel. The information provided is based upon requirements specifically provided to Quectel by the customers. Quectel has not undertaken any independent search for additional relevant information, including any information that may be in the customer’s possession.
-
Page 3: Table Of Contents
3.2. Keypad and MINI USB Interface Description ..............7 3.3. LED Indicator Description ....................8 4. Basic Function..........................9 4.1. Turning GT200 On or Off ....................9 4.2. Number Key Dial Call......................9 4.3. Make An Emergency Call ....................9 4.4. Volume Adjust and State Switch ..................10 4.5. -
Page 4: Revision History
GT200 User manual 0. Revision history Revision Date Author Description of change 2.01 2009-09-11 Ella HUANG Initial TRACGT200UM002 - 3 -... -
Page 5: Introduction
GT200 User manual 1. Introduction GT200 is a powerful GPS Locator which is designed for kids care. With superior receiving sensitivity, fast TTFF and GSM frequencies 850/1800/1900MHz or 900/1800/1900MHz. Its location can be real time or schedule tracked by backend server or specified terminals. Base on the... -
Page 6: Getting Started
During charging, the Battery LED Indicator is blinking slowly. When the battery is full charged, the Battery LED Indicator will be solid. You can also charge the battery by USB cable which connects GT200 with the PC. Charging process usually takes about 4 hours. -
Page 7: Install Sim Card
GT200 User manual 2.3. Install SIM Card Turn off the GT200; remove the battery cover and battery. Move the SIM card slot cover up, pull it up, and insert the SIM card into the SIM card slot according to the direction shown, then close the cover and pull it down to lock;... -
Page 8: Product Overview
3.2. Keypad and MINI USB Interface Description Keypad Function description Power Key Hold down this key to turn on / turn off GT200 Volume +/-Key When in voice call, press this key to adjust the volume; In idle state, keep pressing the Volume – Key for 3 seconds will switch between normal and silent state. -
Page 9: Led Indicator Description
Plug in the AC power adapter to this interface for battery charging. Backend server developer or administrator can use the Data_Cable_M to configure GT200. 3.3. LED Indicator Description There are three LED Indicators in GT200 to indicator different status of GT200. Details as below: Light event State... -
Page 10: Basic Function
At first, user should preset the SOS call number. User can keep press SOS key for 3 seconds with any case to dial the SOS call number for help. At the same time, GT200 will try to get GPS fixing and send the report with position TRACGT200UM002... -
Page 11: Volume Adjust And State Switch
GT200 User manual information to backend server. Please note, in Fake Power Off Mode or Fake Ghost Mode, keep press SOS key for 3 seconds, it will only open GPS and send position information to backend server. 4.4. Volume Adjust and State Switch Press volume+/- key to increase or decrease the volume while in talking. - Page 12 GT200 User manual key can be used to end the call. TRACGT200UM002 - 11 -...
-
Page 13: Troubleshooting And Safety Info
Poor signal. Please move to a place with a better signal and try again. Messages can’t be The SIM card in GT200 doesn’t support Try a GPRS supported SIM reported to the GPRS. card. backend server by APN is wrong. -
Page 14: Safety Info
GT200 User manual No response from GT200 is in power saving mode. Remove the Data_Cable_M, UART when and plug it in again. After this configure GT200 operation, GT200 will exit through UART from power saving mode for 10 seconds. 5.2. Safety info Please do not immerse the device in liquids.
