Summary of Contents for Quectel L10
- Page 1 Quectel GPS Engine L10 User Guide L10_User _Guide_V1.00...
-
Page 2: L10 User Guide
L10_User_Guide_V1.00 General Notes Quectel offers this information as a service to its customers, to support application and engineering efforts that use the products designed by Quectel. The information provided is based upon requirements specifically provided to Quectel by the customers. Quectel has not undertaken any independent search for additional relevant information, including any information that may be in the customer’s possession. -
Page 3: Table Of Contents
2. Operational description .........................6 2.1 Tune on the module ......................6 2.2. L10 features.........................7 2.2.1 General specification ....................7 2.2.2 Hardware Specification ....................8 2.2.3 Software and other specifications................8 2.2.4 Solution of L10......................9 3. GPS Protocol..........................12 Compliance with FCC Regulations..................12 L10_User_Guide_V1.00 - 2 -... -
Page 4: Evb Kit Introduction
1. EVB Kit Introduction 1.1 EVB Top and Bottom View EVB top view L10_User_Guide_V1.00 - 3 -... - Page 5 EVB bottom view A: UART port B: Antenna interface C: Adapter interface D: Test points E: L10 Module F: POWER switch G: USB interface H: STANDBY button I: RESET button J: Indication LEDs L10_User_Guide_V1.00 - 4 -...
-
Page 6: Evb Accessories
1.2 EVB Accessories EVB accessories A: GPS active antenna (3.3V) B: DC5V/2A power adapter C: Serial port cable (USB 2.0) D: USB cable L10_User_Guide_V1.00 - 5 -... -
Page 7: Evb And Accessories
1.3 EVB and Accessories When USB to RS232 cable is used, the EVB and its accessories are equipped as shown in Figure EVB and accessory equipments with serial cable 2. Operational description 2.1 Tune on the module L10_User_Guide_V1.00 - 6 -... -
Page 8: L10 Features
2.2. L10 features 2.2.1 General specification The L10 GPS module brings the high performance of the MTK positioning engine to the industrial standard. The module supports 210 PRN channels. With 66 search channels and 22 simultaneous tracking channels, it acquires and tracks satellites in the shortest time even at indoor signal level. -
Page 9: Hardware Specification
GPS C/A, SBAS (including WAAS, EGNOS, MSAS), DGPS (RTCM), and AGPS. The L10 is an SMD type module with the compact 22.4mm x 17.0mm x 3.0 mm form factor, which can be embedded in customer applications through the 28-pin pads. It provides all hardware interfaces between the module and customer’s board. -
Page 10: Solution Of L10
22.4±0.15 x 17±0.15 x 3.0±0.1mm Weight: about 2.2g Firmware Upgrade Firmware upgrade over UART port or USB port 2.2.4 Solution of L10 The hardware solution is MT3329; The software solution is MTK Release GPS AXN. MT3329 L10_User_Guide_V1.00 - 9 -... - Page 11 2.2.5 Mechanical architecture L10 Top view and Side dimensions（Unit:mm） L10_User_Guide_V1.00 - 10 -...
- Page 12 （Unit:mm） L10 Bottom dimensions PAD Bottom dimensions（Unit: mm） L10_User_Guide_V1.00 - 11 -...
-
Page 13: Gps Protocol
When the L10 is integrated into a final product, the FCC ID label must be visible through a window on the final device or it must be visible when an access panel，door or cover is easily removed. If not, a second label must be placed on the outside of the final device that contains the following text：... - Page 14 instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: --Reorient or relocate the receiving antenna.
- Page 15 Shanghai Quectel Wireless Solutions Co., Ltd. Room 801, Building E, No.1618, Yishan Road, Shanghai, China 201103 Tel: +86 21 5108 2965 Mail: info@quectel.com...
