Page 1
2.4 GHz IEEE 802.11g 54Mbps Wireless LAN USB Adapter GW-US54GZL MAC Installation Guide Planex Communications Inc.
Page 2
MAC Installation Guide Install driver and ZDWlan Utility................2 Use ZDWlan Utility....................7 UnInstall driver and ZDWlan Utility..............12...
Page 3
1. Install driver and ZDWlan Utility Double Click PCI ZD1211MacUSB_install_3_0_0_0.dmg Double Click ZD1211MacUSB_install_3_0_0_0.pkg Select install folder by Mac OS version. Click Continue...
Page 4
Click Continue Select a Destination Volume Click Continue...
Page 5
Click Upgrade Enter Name and Password the user with Administrative rights. Click Click Continue Installation...
Page 6
Click Restart Now the Driver and Utility Installation is Complete! Restart the computer. If this the first time you run this Wireless card after installaion, please enable the new network interface in the Network Control Panel System Preferences. It is essential to follow the steps in below, before first launch of ZyDASWLan utility. Click Network...
Page 7
Click Click Apply Now Now It’s ready to use Wireless.
Page 8
2. Use ZDWlan Utility Launch ZyDasWLan After installation and enable network configuration, you can open the wireless lan Utility in System Preferences...
Page 9
MainView Double Click one SSID in Available Network or Click Connect this site : it would connect to the selected siteSSID. Click Refresh: Site survey. Click More Setting…: Open more setting panel Click one SSID in Available Network: it would show the AP information in right window.
Page 10
More Setting Change connection setting Open WEP key setting Open Information Close the More Setting Panel Apply the new setting.
Page 11
WEP Key Setting Note: If you open the “Wep Setting” along by click the button “WEP Encryption Setting” from More setting panel, you need to do re-connection by “apply” or double click the AP by the list of available network. 1 Apple the new setting.
Page 12
Information Network setting Check the TCP/IP setting for your network.
Page 13
3. UnInstall driver and ZDWlan Utility Please close Utility before uninstall it! Double Click ZD1211MacUSB_uninstall_3_0_0_0.pkg Click Continue...
