Page 1: User Manual
Snapshot Use on Dimmer Outdoor Use Sound Activated Master/Slave 12 V External Power Supply Replaceable Fuse User Serviceable Duty Cycle User Manual 3000 N 29 Ct, Hollywood, FL 33020 U.S.A. (800) 762-1084 – (954) 929-1115 FAX (954) 929-5560 www.chauvetlighting.com... -
Page 2: Table Of Contents
ABLE OF ONTENTS 1. Before You Begin ............................3 ....................................3 HAT IS INCLUDED ..................................3 NPACKING NSTRUCTIONS ..................................3 ANUAL ONVENTIONS ........................................3 CONS ..................................4 AFETY NSTRUCTIONS 2. Introduction ..............................5 ......................................5 EATURES ) ................................6 RODUCT VERVIEW FRONT ) ............................... -
Page 3: Before You Begin
Manual Conventions CHAUVET manuals use the following conventions to differentiate certain types of information from the regular text. EANING... -
Page 4: Safety Instructions
Do not operate this device in more than 113° F (45° C) ambient temperature conditions. There are no user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please contact CHAUVET at: 954-929- 1115. -
Page 5: Introduction
2. I NTRODUCTION The Obey™ 8 is a compact, universal intelligent lighting controller, designed for use with LED wash fixtures (dimming, color mixing). It allows for up to 32 channels of DMX with control of up to four fixtures. Up to eight scenes and eight chases may be programmed. -
Page 6: Product Overview (Front)
Product Overview (front) UTTON OR ADER UNCTION Fixtures select buttons Fixture selection Universal bump buttons representing scene location for storage and Scenes select buttons selection For adjusting DMX values, Ch 1~4 can be adjusted immediately after Channel faders pressing the respective fixture select button, Ch 5~8 after pressing the Page select button Page button Press to toggle between pages of control: 1~4, 5~8... -
Page 7: Product Overview (Rear Panel)
Product Overview (rear panel) Item Button or Fader Function Back panel sticker Shows the rear panel connections/switches and their function DMX polarity switch Used to change signal polarity DMX output connector DMX control signal output DC Input jack Main DC power input Power On/Off switch Used to power on/off the controller Obey™... -
Page 8: Setup
Maximum recommended number of fixtures on a serial data link: 32 Data Cabling To link fixtures together you must obtain data cables. You can purchase CHAUVET certified DMX cables directly from a dealer/distributor or construct your own cable. If you choose to create your own cable please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic interference. -
Page 9: Cable Connectors
3-Pin to 5-Pin Conversion Chart If you use a controller with a 5-pin DMX output connector, you will need to use a 5-pin to 3-pin adapter, such as CHAUVET Model No: DMX5M, or DMX5F. The chart below details a proper cable conversion:... -
Page 10: Operating Instructions
4. O PERATING NSTRUCTIONS Resetting the System This will reset the controller to its factory defaults. This will erase all programs and settings. Tap <PROGRAM> and <STEP/DEL>. All LEDs will blink to indicate a successful reset. (Note: This process may take up to 15 seconds) Fixture Addressing The Obey™... -
Page 11: Programming
Programming A chase is a sequence of scenes/steps. In the Obey™ 8, eight chases may be created, with up to 99 steps per chase. Entering program mode Press <PROGRAM> for five seconds, until the program LED indicator remains on. This indicates that the controller is in programming mode. -
Page 12: Chase Programming
Chase Programming A chase is created by using previously created scenes. Scenes become steps in a chase and can be arranged in any order you choose. You may use the same scene multiple times in a chase. Create a chase A chase can contain up to 99 scenes as steps. -
Page 13: Playback (Chases/Scenes)
Playback (Chases/Scenes) Manual run chase When power is first turned ON, the controller will be in Auto mode. Action Notes This mode does not affect the scenes. They will Press <MODE/UP> to select Manual mode. still operate separately, in an HTP (highest takes priority) operation. -
Page 14: Manual Run Scene
10 m. You may press <STROBE> again to use the <RUN/STROBE SPEED>fader for playback speed adjustment. Contact Us W o r l d W i d e General Information CHAUVET 3000 North 29 Court Hollywood, FL 33020 voice: 954.929.1115 fax: 954.929.5560... -
Page 15: Appendix
XLR male to female connectors. The shield connection is pin 1, while pin 2 is Data Negative (S-) and pin 3 is Data positive (S+). CHAUVET carries 3-pin XLR DMX compliant cables, DMX-10 (33’), DMX-4.5 (15’) and DMX-1.5 (5’) General Maintenance To maintain optimum performance and minimize wear, fixtures should be cleaned frequently. -
Page 16: Returns Procedure
Package must be clearly labeled with a Return Merchandize Authorization Number (RMA #). Products returned without the RMA # will be refused. Call CHAUVET and request an RMA # prior to shipping the fixture. Be prepared to provide the model number, serial number and a brief description of the cause for the return. -
Page 17: Technical Specifications
©CHAUVET, 2009, All Rights Reserved Information and specifications in this user manual are subject to change without notice. CHAUVET assumes no responsibility or liability for any errors or inaccuracies that may appear in this document. Obey™ 8 User Manual 7/20/2009 5:17 PM...
