(U)Sim Card And Battery - Nokia N80 Quick Start Manual

(U)SIM card and battery

3
Insert the (U)SIM card and battery
1. With the back of the device facing you,
press the release button, slide the cover,
and lift it up (fig. 3.1).
Always switch the device off, and disconnect
the charger before removing the battery.
2. To release the (U)SIM card holder, slide the
holder, and lift the holder up (fig. 3.2).
3. Insert the (U)SIM card into the holder (fig. 3.3).
Make sure that the bevelled corner on the card is
facing upward from the holder, and that the
contact area on the card is facing the connectors
on the device.
4. Close the holder, and slide it to lock
it into place.
5. Insert the battery (fig. 3.4).
6. Replace the back cover.
Keep all SIM cards out of the reach of small children.
Copyright © 2006 Nokia. All rights reserved.
fig. 3.1
fig. 3.2
fig. 3.3
fig. 3.4
