Brunswick Frameworx LCD Interface Installation Manual page 7

IMPORTANT! The "Remote Video Boards" do not have to be removed to identify the part
number.
a. Does the center have video board, part number 57-300103-4xx? ______
b. Does the center have the 2000 video board, part number 57-301081-4xx? ______
c. Does the center have both video boards? ______
NOTE: Check ALL Lane Group Processors or if they do not have any Lane Group Proces-
sors, shaver scoring consoles will need to be checked for the type of video boards
NOTE: If the center does not have any existing overheads and would like to add LCD
overheads, an exception request will need to be processed
3. What type of Frameworx LCD upgrade will be ordered?
Description
FX LCD UPGRADE 32" SAMSUNG FOR ALL MARKETS
INCLUDING ASIA EXCEPT EUROPE
FX LCD UPGRADE 40" SAMSUNG FOR ALL MARKETS
INCLUDING ASIA EXCEPT EUROPE
FX LCD UPGRADE 46" SAMSUNG FOR ALL MARKETS
INCLUDING ASIA EXCEPT EUROPE
FX LCD UPGRADE 32" SAMSUNG FOR EUROPE
FX LCD UPGRADE 40" SAMSUNG FOR EUROPE
FX LCD UPGRADE 46" SAMSUNG FOR EUROPE
NOTE: Model Number includes Samsung monitor, electronics, and mounting bracket.
IMPORTANT: The customer's responsiblity to provide a quantity of three IG outlets for the
Frameworx LCD Interface. One for each component: Frameworx LCD Interface, S-video to
VGA convertor, and the LCD overhead.
NOTE: The customers are NOT allowed to provide their own LCD overhead.
NOTE: All electronics are capable of 120/230 volts and 50/60 hertz.
Guidance Model No.
Per monitor E3-300434-032
Per monitor E3-300434-040
Per monitor E3-300434-046
Per monitor E3-300435-032
Per monitor E3-300435-040
Per monitor E3-300435-046
Frameworx to LCD Interface Pre-Installation
QTY
7
