ALWAYS READ THESE INSTRUCTIONS AND USE THIS PRODUCT STRICTLY IN ACCORDANCE WITH THIS SAFETY
INFORMATION - KEEP THIS NEAR OR ON THE PRODUCT AT ALL TIMES FOR EASE OF REFERENCE. WHILST USING
THE PRODUCT THERE ARE RISKS AND THE PRODUCT MUST ONLY BE USED AFTER READING AND THEN ONLY IN
ACCORDANCE WITH THESE SAFETY INSTRUCTIONS.
FAILURE TO FOLLOW THE PROCEDURES BELOW MAY RESULT IN SERIOUS INJURY DUE TO THE OPERATION OF THE
PINCH POINT AREA BETWEEN THE RUNNING GEAR AND THE UPRIGHT FRAMES.
•
DO NOT TIP THE BOX ON ITS SIDE WITH THE TREADMILL STILL IN IT.
•
DO NOT MOVE THE TREADMILL OUT OF THE BOX UNTIL THE UNIT HAS BEEN ASSEMBLED
1. LAY BOX ON A STABLE, FLAT SURFACE AND ENSURING THE TOP SIDE IS FACING UP.
2. COLLAPSE ALL FOUR SIDES OF THE BOX BEFORE COMMENCING UNIT ASSEMBLY IN ACCORDANCE WITH THE ASSEMBLY
INSTRUCTIONS.
3. ONCE ASSEMBLED, ONLY MOVE THE TREADMILL OUT OF THE BOX ON ITS WHEELS WHILE THE DECK IS IN THE FOLDED AND
LOCKED POSITION.
•
ONCE ASSEMBLED AND REMOVED FROM THE BOX DO NOT TIP THE TREADMILL ON ITS SIDE.
OWNER'S GUIDE
Pursuit Treadmill
RISK WARNING
MAR16/2010
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Inspiration Pursuit
Summary of Contents for Inspiration Pursuit
- Page 1 OWNER’S GUIDE Pursuit Treadmill RISK WARNING ALWAYS READ THESE INSTRUCTIONS AND USE THIS PRODUCT STRICTLY IN ACCORDANCE WITH THIS SAFETY INFORMATION - KEEP THIS NEAR OR ON THE PRODUCT AT ALL TIMES FOR EASE OF REFERENCE. WHILST USING THE PRODUCT THERE ARE RISKS AND THE PRODUCT MUST ONLY BE USED AFTER READING AND THEN ONLY IN ACCORDANCE WITH THESE SAFETY INSTRUCTIONS.
- Page 2 Congratulations on purchasing a fitness equipment from Inspiration Fitness You have chosen a high quality, safe and innovative piece of equipment as your training partner and we are certain it will keep you motivated on the way to achieving your personal fitness goals.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Contents Safety Information Customer Support Assembly Instructions Operational Instructions • Adjustment Running Mat ......... 10 • Deck Lubrication ............ 10 • Safety Key ..............11 • The Display Range ..........11 • Operations Guide ..........12 • Quick Start ..............12 • Target Modes ............ -
Page 4: Safety Information
Inspiration Fitness reserves the right to Operation Precautions: change the specifications of the hardware and software • Before use, always ensure that the treadmill is positioned described herein at any time without prior notice. -
Page 5: Other Precautions
SAFETY INFORMATION Other Precautions: Exercise Precautions: • Parents and others in charge of children should be aware • Wear proper workout clothing: Do not wear loose of their responsibility. The playful instinct of children can clothing. lead to situations and behavior for which this equipment • Do not wear shoes with leather soles or high heels. -
Page 6: Customer Support
CUSTOMER SUPPORT Care & Maintenance Contact Us • Always place the equipment in a dry environment. ENGLAND York Way, Daventry, Northants, England NN11 4YB • Use a warm, damp cloth to keep the product clean. Tel: (01327) 701800 • No wet cleaning of electrical components. Unplug before Helpdesk Tel: (01327) 701824 any care and maintenance. -
Page 7: Assembly Instructions
ASSEMBLY INSTRUCTIONS RISk wARNINg do not moVe treAdmill out of the boX until unit is Assembled And do not tip the boX on its side with the treAdmill in it. Also once the Assembled treAdmill hAs been remoVed from the boX do not tip the treAdmill on its side. collApse boX bottom And lAy sides down before Assembly. - Page 8 ASSEMBLY INSTRUCTIONS Step 1 Fixings Part No. 86 x 10 Curved Washer (Ø8) Part No. 7 x 10 Round Head Allen Screw (M8 x 15L) Step 2 Fixings Part No. 86 x 4 Curved Washer (Ø8) Part No. 7 x 4 Round Head Allen Screw (M8 x 15L)
-
Page 9: Final Check
ASSEMBLY INSTRUCTIONS Step 3 Fixings Part No. 77 x 6 Self Tapping Screw (M4 x 15L) Final Check Your treadmill is now assembled. Please make the following final checks: • Make sure all screws / bolts are tightened. • Make sure the equipment is on a flat, level surface. Power Up • Plug one end of power cable into the treadmill as shown. -
Page 10: Operational Instructions
OPERATIONAL INSTRUCTIONS Adjusting Running Mat Tension Note: Check lubrication before adjusting the mat as symptoms can be similar. The tension of the mat has been pre-set at the factory; however, with use the mat can stretch slightly and become loose. If the mat is too loose you will find it starts to slip during use. -
Page 11: Safety Key
OPERATIONAL INSTRUCTIONS Safety Key The treadmill will only operate when the safety key is in position - if the safety key is removed while the treadmill is in operation, it will stop immediately. Before every workout session please make sure you attach the safety key to the console and the clip at the other end to your clothing. -
Page 12: Operations Guide
OPERATIONAL INSTRUCTIONS Operations Guide Button Description START Begin work out. STOP Stop the treadmill. MODE During standby, press “MODE” button to switch modes in the following order: TIME MODE > CALORIES MODE > DISTANCE MODE > NORMAL MODE PROGRAM During standby, press “PROG” button to switch programs in the following order: P1 >... -
Page 13: Program Modes
OPERATIONAL INSTRUCTIONS Program Modes Press “PROG” button to select program: P1 > P2 > P3 > NORMAL MODE • Default: 20 minutes 1. Press “Speed + / -” buttons to change target time. (8:00 ~ 99:00) 2. Press “START” to begin workout. Operations: • Use “Speed + / -”... -
Page 14: Features
FEATURES Monitoring Your Heart Rate The treadmill is fitted with 2 hand pulse sensors. To obtain a pulse reading you must have both your left and right hands on the sensors at the same time. Do not grip the hand sensors too tight and allow the computer a few seconds to display the reading. -
Page 15: Maintenance
MAINTENANCE Maintenance Proper maintenance is very important to ensure your treadmill is always in top working condition. Improper maintenance could cause damage or shorten the life of your treadmill and exceed the LIMITED WARRANTY coverage. Important: Never use abrasives or solvents to clean the treadmill. To prevent damage to the computer, keep liquids away and keep it out of direct sunlight. -
Page 16: Warranty
This warranty does not extend to any product that has been damaged or rendered defective: (a) as a result of accident, misuse, abuse or lack of reasonable care; (b) by the use of parts not manufactured by Inspiration Fitness or sold by Inspiration Fitness;... -
Page 17: Fitness Guide
FITNESS gUIDE Starting Your Workout ALWAYS CONSULT YOUR DOCTOR BEFORE UNDERTAKING A NEW EXERCISE REGIME. IF YOU EXPERIENCE NAUSEA, DIZZINESS OR OTHER ABNORMAL SYMPTOMS DURING EXERCISE, STOP AT ONCE AND CONSULT YOUR DOCTOR. Begin each workout with a warm up session - a few minutes of stretching to help prevent strains, pulls and cramps: 1. -
Page 18: Suggested Stretches
FITNESS gUIDE Suggested Stretches The correct form for several basic stretches is shown at the right. Move slowly as you stretch—never bounce. 1. Hamstring Stretch Sit with one leg extended. Bring the sole of the opposite foot toward you and rest it against the inner thigh of your extended leg. -
Page 19: Heart Rate Training
FITNESS gUIDE Heart Rate Training To get the most out of your new equipment and see the best results from your training you should exercise at the right level of effort, and that means listening to your heart! Working out to a target heart rate means you can direct your workout to achieve different goals: GOOD HEALTH - For those wishing to improve quality of life and general well being. -
Page 20: Exploded Drawing / Part List
ExPLODED DRAwINg... -
Page 21: Part List
PART LIST PART NO. DESCRIPTION PART NO. DESCRIPTION 51098-1 Main Frame 51098-61 Running Deck Lubricant 51098-2 Left Upright Post 51098-62 Cap Nut (M12) 51098-3 Right Upright Post 51098-63 Motor Lower Cover 51098-4 Console Frame 51098-64 Allen Key (GJ-15) 51098-5 Base Frame 51098-65 Transport Wheel Bracket 51098-6... - Page 22 NOTES...
- Page 23 NOTES...
