Page 1: Installation Guide
VIP2502W Wireless IPTV Receiver Installation Guide... - Page 2 VIP2502W Wireless IPTV Receiver Installation Guide...
- Page 3 Do not place it in a sealed enclosure without providing for adequate airflow. • Use only the power adapter and cord supplied to connect the VIP2502W to your home AC power outlet. • Do not plug the AC power adapter into a switched power outlet.
-
Page 4: Table Of Contents
Troubleshooting ......... . 11 VIP2502W Wireless IPTV Receiver Installation Guide... -
Page 5: Introduction
Congratulations on receiving your Motorola VIP2502W Wireless IPTV Receiver. ® The VIP2502W provides these extraordinary home entertainment features: • Wireless input via the VAP2500 Wireless Access Point lets you easily position or move your video entertainment system anywhere in your residence -- or even outside -- without network wires or cables •... -
Page 6: Overview
Lights green when receiving a video stream Lights blue when receiving video resolution of 720p or 1080i RECORD Lights red when a recording is in progress MENU Displays the VIP2502W menu on your TV screen Up/Down Changes the channel (channel up/channel down) arrow keys Left/Right... -
Page 7: Rear Panel
Overview Rear Panel The VIP2502W rear panel features are described in the following table. Item Function NETWORK Ethernet 10/100Base-T RJ-45 port RCA component video outputs to an HDTV VIDEO OUT RCA standard-definition composite video output to a TV, VCR, or other device... -
Page 8: Wireless Connection
8. An icon appears on the screen, indicating that the connection sequence is in process. When three horizontal dots appear, the connection has been successful. 9. On the front panel of the VIP2502W, two or more bars on the signal strength indicator should light green. You have now established a secure wireless connection between the Access Point and your VIP2502W. -
Page 9: Connecting Your Tv Receiver
Connecting Your TV Receiver This section describes alternative methods for connecting the VIP2502W to your home entertainment system. Instructions and diagrams are included for connections to: • High-Definition TV (HDTV) • Home Theater Receiver–Audio • Stereo TV Before you move or change components on your entertainment system, always disconnect power from the wireless receiver. -
Page 10: Common Cabling Examples
AUDIO L and R connections. Common Cabling Examples The following cabling diagrams illustrate common sample audio/video (A/V) connections. When connecting other components to your TV Receiver, refer to the other component installation manuals for additional connection information. VIP2502W Wireless IPTV Receiver Installation Guide... -
Page 11: Connecting To An Hdtv - Video Only
DVI and component video carry video signals only. To connect the audio, refer to the following page. To connect to a home theater receiver, refer to “Connecting Audio to a Home Theater Receiver – Audio Only. ” VIP2502W Wireless IPTV Receiver Installation Guide... -
Page 12: Connecting To An Hdtv - Audio Only
OUT L and R connectors. In most cases, S/PDIF offers better audio quality, including support for Dolby Digital 5.1 Surround Sound. HDMI carries video and audio. If you connect your HDTV using HDMI, no additional audio connections to the TV are necessary. VIP2502W Wireless IPTV Receiver Installation Guide... -
Page 13: Connecting Audio To A Home Theater Receiver
If your home theater receiver supports it, use the OPTICAL S/PDIF output. Otherwise, use the AUDIO OUT L and R connectors. In most cases, S/PDIF offers better audio quality, including support for Dolby Digital 5.1 Surround Sound. VIP2502W Wireless IPTV Receiver Installation Guide... -
Page 14: Connecting To A Stereo Tv
HDMI Sample stereoTV INPUT S-VIDEO VIDEO AUDIO LEFT CABLE/ ANTENNA IN AUDIO RIGHT This video connection method does not support HD video. For more information, see “Connecting an HDTV – Video Only. ” VIP2502W Wireless IPTV Receiver Installation Guide... -
Page 15: Troubleshooting
Signal strength is indicated by the number of illuminated bars quality is poor or on the front panel indicator: missing. If signal strength is inadequate, try reorienting or relocating the Wireless TV receiver or the Access Point for improved reception. VIP2502W Wireless IPTV Receiver Installation Guide... -
Page 16: Regulatory Information
The band from 5600-5650MHz will be disabled by the software during the manufacturing and cannot be changed by the end user. This device meets all the other requirements specified in Part 15E, Section 15.407 of the FCC Rules. VIP2502W Wireless IPTV Receiver Installation Guide... -
Page 17: Industry Canada Statements
The Wireless Fidelity (WiFi) certification as defined by the Wi-Fi Alliance. Wireless LAN and your Health The VIP2502W, like other radio devices, emit radio frequency electromagnetic energy, but operate within the guidelines found in radio frequency safety standards and recommendations. -
Page 18: Software License
Software provided by third parties may be subject to separate end user license agreements from the manufacturers of such Software. The Software is never sold. Motorola licenses the Software to the original customer and to any subsequent licensee for personal use only on the terms of this License. Motorola and its third party licensors retain the ownership of the Software. - Page 19 License. The Software, including any images, graphics, photographs, animation, video, audio, music, and text incorporated therein is owned by Motorola or its third party licensors and is protected by United States copyright laws and international treaty provisions. Except as otherwise expressly provided in this License, the copying, reproduction, distribution, or preparation of derivative works of the Software, any portion of the Product, or the documentation is strictly prohibited by such laws and treaty provisions.
- Page 20 Visit our website at: www.motorola.com 591850-001-b 05/13...
