Please read this entire manual before installation. Save these instructions.
SAFETY NOTICE
CAUTION: HOT W HILE IN OPERATION. KEEP
CHILDREN, CLOTHING AND FURNITURE AW AY.
CONTACT M AY CAUSE SKIN BURNS.
IF THIS HEATER IS NOT PROPERLY INSTALLED,
A HOUSE FIRE M AY RESULT.
CONTACT LOCAL BUILDING OFFICIALS ABOUT
RESTRICTIONS AND INSTALLATION INSPECTION
REQUIREM ENTS IN YOUR AREA.
FAILURE TO COM PLY W ITH OW NERS' M ANUAL
INSTRUCTIONS W ILL VOID YOUR W ARRANTY!
DO NOT CONNECT TO ANY AIR DISTRIBUTION
DUCT OR SYSTEM
DO NOT CONNECT THIS APPLIANCE TO A CHIM NEY
FLUE SERVING ANOTHER APPLIANCE.
Shenandoah R77-E Wood Burning
Heater
Installation & Operating Instructions
PLEASE LEAVE THIS MANUAL WITH THE OWNER !!
Listed by Warnock Herseyl
Manual (EPA Exempt)

GENERAL INFORMATION

Congratulations on your purchase of the Sierra Stove. W e
are confident that your new stove will provide you with years
of safe, com fortable and efficient heating.
This m anual describes the installation and operation of the
Shenandoah R-77E wood burning heater.
Please read this entire m anual before you install and use
your new room heater. Failure to follow instructions m ay
result in property dam age, bodily injury, or even death.
Save these instructions for future reference.
SAFETY NOTICE
If this appliance is not properly installed, a house fire m ay
result. For your safety, follow the installation instructions.
Check with local building or fire officials about restrictions and
installation inspection requirem ents in your area.
It is best to have a professional install your Sierra Stove. If
you prefer to install it yourself (see Installation Instructions),
be sure to obtain the proper perm its. Have the local building
officials inspect the stove and chim ney pipe for safety and
code com pliance after the installation is
com plete.
FAILURE TO FOLLOW INSTRUCTIONS M AY
RESULT IN PROPERTY DAM AGE, BODILY INJURY,
NOT APPROVED FOR M OBILE HOM ES.
DO NOT USE CHEM ICALS OR FLUIDS TO START
DO NOT BURN GARBAGE OR FLAM M ABLE FLUIDS.
ALL SHENANDOAH SOLID FUEL ROOM HEATERS
HAVE BEEN TESTED IN ACCORDANCE W ITH
U.L.TEST STANDARD 1482-1998 TEST STANDARD
1482-1998
OR EVEN DEATH.
THE FIRE!
