- Page 1 MODEL 100413-001 RADIO REMOTE for NL955, NVL955, NMV05 & NV05 Dealer / Owner / Operator Manual 33722...
- Page 2 FOR THE NL955, NVL955, NMV05 & NV05 Dear Radio Remote Control Customer: Thank you for purchasing our 100413-001 Radio Remote Control. We are sure that it will provide you with years of trouble free service. Your installing dealer will be happy to provide you with any assistance that may be necessary to keep all of your equipment in top operating condition.
- Page 3 SAFETY PRECAUTIONS Note: The Radio Remote Control receiver draws about 4 milliamperes from your vehicle battery. This coupled with the current draw from other vehicle components such as the conversion package, the wheel- chair lift and other devices may be enough to discharge the vehicle battery over the course of several days if the vehicle is not started.
- Page 4 INSTALLATION INSTRUCTIONS 1. Disconnect lift power wire and remove cover from lift. 2. Mount receiver with provided screws. Do not mount the receiver or the antenna..A. Within 6 feet of any motor B. Near any large bundles of wiring C.
-
Page 5: Installation Instructions
INSTALLATION INSTRUCTIONS NL955 and NVL955 Control Board Remote Transmitter C6 + C32 + ASSY R100 100083- R104 R103 R102 R106 R107 R101 R105 Figure 2 NL955 and NVL955 CAUTION! HAZARD Connection NL955/NVL955 Intermotive Accessory Board: 100285-001 100362- To Lift To Intermotive Accessory Board Control Board... - Page 6 MODEL 100413-001 RADIO REMOTE for NL955, NVL955, NMV05 & NV05 Dealer / Owner / Operator Manual 33722...
