Metal cutter
MODEL 4131
I N S T R U C T I O N
WARNING:
For your personal safety, READ and UNDERSTAND before using.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
DOUBLE
INSULATION
M A N U A L
005343

Advertisement

Table of Contents
loading

Related Manuals for Makita 4131

Summary of Contents for Makita 4131

  • Page 1 Metal cutter MODEL 4131 005343 DOUBLE INSULATION I N S T R U C T I O N M A N U A L WARNING: For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.

  • Page 2: Specifications

    Intended use Responsible manufacturer: The tool is intended for cutting in mild steel. Makita Corporation Anjo Aichi Japan Power supply The tool should be connected only to a power supply of the same voltage as indicated on the nameplate, and can only be operated on single-phase AC supply.

  • Page 3: General Safety Rules

    GENERAL SAFETY RULES ENA100-1 WARNING: Read all instructions. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. The term “power tool” in all of the warnings listed below refers to your mains operated (corded) power tool or battery operated (cordless) power tool.
  • Page 4 21. Keep cutting tools sharp and clean. Properly power tool for operations different from those maintained cutting tools with sharp cutting edges intended could result in a hazardous situation. are less likely to bind and are easier to control. Service 22.
  • Page 5 Support large panels to minimise the risk of guard may operate sluggishly due to damaged blade pinching and kickback. Large panels parts, gummy deposits, or a build-up of debris. tend to sag under their own weight. Supports 12. Always observe that the lower guard is covering must be placed under the panel on both sides, the blade before placing tool down on bench or near the line of cut and near the edge of the...

  • Page 6: Functional Description

    FUNCTIONAL CAUTION: DESCRIPTION • Always be sure that the tool is switched off and unplugged before adjusting or checking function on the tool. Adjusting the depth of cut 005344 Loosen the lever on the depth guide and move the base up or down. At the desired depth of cut, secure the base by tightening the lever.
  • Page 7 Installing or removing saw blade 005347 CAUTION: • Use only the Makita wrench provided to install or remove the blade. Failure to do so may result in overtightening or insufficient tightening of the hex bolt. This could cause serious injury to the operator. •...

  • Page 8: Operation

    Rip fence (guide rule) (Accessory) 005351 The handy rip fence (guide rule) allows you to do extra-accurate straight cuts. Simply slide the rip fence up snugly against the side of the workpiece and secure it in position with the clamp screw on the front of the base. It also makes repeated cuts of uniform width possible.

  • Page 9: Maintenance

    • Always use the carbide-tipped saw blades appropriate for your job. The use of inappropriate saw blades may cause a poor cutting performance and/or present a risk of personal injury. Chip disposal 005355 CAUTION: • Always be sure that the tool is switched off and unplugged before removing or installing the dust cover.
  • Page 10 • These accessories or attachments are recommended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose.
  • Page 11 Memo...
  • Page 12 Makita Corporation Anjo, Aichi, Japan 884543D224...
