- Page 1 ������� ������� ����� ����������� ������ �� UK-1...
-
Page 2: Table Of Contents
CONTENTS FEATURES UK-3 KEY ARRANGEMENT UK-4 MODE OPERATION UK-5 TIME UK-6 STOP WATCH UK-8 DAILY ALARM UK-9 COUNTDOWN TIMER UK-11 DUAL TIME UK-13 DIGITAL COMPASS UK-14 COMPASS CALIBRATION UK-15 DECLINATION SET UK-17 BATTERY REPLACEMENT UK-19 CARE OF YOUR WATCH UK-20 UK-2... -
Page 3: Features
FEATURES - Digital compass with 16 cardinal point segments display - Digital direction indication in degree with 1 degree interval - Time with HOUR, MINUTE, SECOND, MONTH, DATE and WEEKDAY - Support both 12/ 24 hour display format. - 4 daily alarms with hour and minutes - Hourly Chime signal - 1/100s resolution chronograph with 24 hours working range... -
Page 4: Key Arrangement
KEY ARRANGEMENT UK-4... -
Page 5: Mode Operation
MODE OPERATION ��������� ���� ���� ���� ��� ����� ���� �� ����� ��� � ���� ����� ���� ���� ���� ����� ���� ������� ��������� ���� ���� ����� ���� ���� ���� ���� UK-5... -
Page 6: Time
TIME ������� ���� Use the time mode to set and view the current time and date. To turn the hourly chime signal ON/OFF: 1. In the Time Mode, press START/STOP button to turn it on and off. Bell icon indicates the Hourly Chime signal is ON. - Page 7 To set time and date 1. In the Time mode, hold down REST/SPLIT button until the second digits start to flash. The “Hold To Set” text will appear at once when press RESET/SPLIT button. 2. The year digits display instead of the day of week in the setting screen.
-
Page 8: Stop Watch
STOP WATCH Measuring elapsed time and split times: 1. The display range of the stopwatch is 23hr 59min 59.99 sec. 2. The stopwatch continues to run, restarting from zero after it reaches its limit, until you stop it. 3. The stopwatch measurement operation continues even if you exit the Stopwatch mode. -
Page 9: Daily Alarm
DAILY ALARM The alarm sounds at the preset time for about 30 seconds (in all modes), or unitl pressing any button to stop it. To select the daily alarm and turn it on and off: 1. In the Alarm mode, press START/STOP button once to scroll to the diffeent daily alarm. - Page 10 4. Press RESET/SPLIT button to exit the setting screen. Initial Setting: 7:00 (AM) / 7:00 (24hr) & Alarm & Chime OFF UK-10...
-
Page 11: Countdown Timer
COUNTDOWN TIMER The timer counts down from the last setting memory: 1. The display range of the timer is 23hr 59min, 59sec. 2. The timer stops running & reloads after it reaches 0:00 00. 3. The timer does not start to run when the time is set to zero. - Page 12 To set the timer: 1. In the Timer mode, hold down RESET/SPLIT button for 2 sec. Until the second digits of the timer time start to flash. 2. The “Hold To Set” text will appear at once when press RESET/SPLIT button. 3.
-
Page 13: Dual Time
DUAL TIME Dual Time Mode allows you to view and set the second time while you are in other city. To set the dual time 1. In the Dual Time Mode, hold down RESET/SPLIT button for 2 sec until the hour digits of the dual time start to flash. -
Page 14: Digital Compass
DIGITAL COMPASS To Enter and exit the Digital Compass Mode (refer to key option) 1. In any modes, the watch immediately starts a Digital compass operation. The cardinal segments start to rotate in the clockwise. 2. After about 1 second, the letters and digits appear on the display to indicate the direction that the 12 o’clock position of the watch is pointing. -
Page 15: Compass Calibration
COMPASS CALIBRATION � ���� ���������� ���� ���� ������ � ��� �� �� ����� �������� ���������� �� �� ��� ������� To calibrate the digital compass 1. In Compass Mode, hold down RESET/SPLIT button for 2 sec until the “PRESS START” message shows on the display. 2. - Page 16 5. The “TURN 2 To CAL” message appears, follow and turn the watch twice in the circles slowly. The rotation cardinal segment can be a referencing rate. 6. The cardinal segments rotate at 1 Hz rate up to 16 segments and flash at 0.5 sec on and 0.5 off. 7.
-
Page 17: Declination Set
DECLINATION SET To set declination angle: 1. In Compass mode, hold down RESET/SPLIT button until the “PRESS START” message shows on the display. 2. Press MODE button to change to declination setting screen. The E/W starts flash. Press MODE button to move the flashing among the E/W. ten digit and first digit of the angle. - Page 18 And the declination angles for major world cities are listed as follow: City Declination Angle Anchorage 22 E Atlanta Bombay Boston 16 W Calgary 18 W Chicago Denver 10 E Jerusalem London Little Rock Livingston, MT 14 E Munich New York City 14 W Orlando Oslo...
-
Page 19: Battery Replacement
BATTERY REPLACEMENT To replace the battery: 1. Insert a coin into the slot located on the battery compartment cover on the backside of the watch. 2. Turn the coin counterclockwise until it is aligned with the open position marker, or even slightly further for easy opening. -
Page 20: Care Of Your Watch
CARE OF YOUR WATCH - Never attempt to disassemble or service your watch. - Protect your watch from extreme heat, shocks and long time exposure to direct sunlight. - Watch can be wiped clean with a lightly moistened cloth. Apply mild soap to the area if there are stubborn stains or marks.
