- Page 1 OPERATION MANUAL V2000 DIGITALVEHICLECOMPASS...
- Page 2 Making Ordinary Products Extraordinary...
- Page 3 Features cated compasses available for use in a • Patented magnetic sensor technology vehicle. The PNI V2000 is one of several same as the built-in compasses in GM, models using our latest technology to make Ford, and Chrysler vehicles. a digital compass easy and fun to use, while •...
- Page 4 FEATURES • Automatic shut-off when no magnetic • Holographic LCD improves brightness field changes have been sensed for and contrast while removing glare. approximately 10 minutes. • One-year warranty. • Programmable automatic backlight shut- off feature. • Photo diode light sensing feature turns the backlight on or off depending on the amount of ambient light when used with 12-volt adapter.
- Page 5 CONVENTIONS USED IN THIS MANUAL The manual is designed with procedures 4. “Press” means quickly press and release a organized in the order that they will be needed. button in less than two seconds. Additional information about procedures or 5. “Hold” means press and hold the button compass use can be found in our Frequently for at least two seconds, or until a display Asked Questions section.
-
Page 6: Table Of Contents
Photo diode feature ... . .18 Installing the PNI V2000 ... 7 Installing the battery ... . .7 Optional accessories . -
Page 7: Display
DISPLAY “DISTORTION” Cardinal Point Numeric Heading Battery Photo Diode Icon Readout Readout Compartment Compass Rose Temperature and Buttons Temperature 12-Volt Power Bearing Point Readout Sensor Jack AdapterJack Compass Front Compass Back... - Page 8 Light button Power button Press to turn the backlight on or off or Press to turn the PNI V2000 on or off. hold to set the backlight auto shut-off value. “Distortion” icon Cal button The “ ” icon displays when mag-...
-
Page 9: Installing The Pni V2000
Installing the battery until the unit is calibrated. The unit uses a 3-volt CR123A lithium-type Every time the battery is removed the PNI battery, installed according to the diagram on V2000 must be calibrated and all previous the inside of the battery compartment. Push the feature settings must be re-programmed. -
Page 10: Windshield Installation Guidelines
The accuracy of the PNI V2000 will be diminished by a strong magnetic field, The PNI V2000 mounting bracket is such as that found in proximity to an designed to allow for the unit to be audio speaker. -
Page 11: Windshield Mounting
Dashboard Do not leave the PNI V2000 in a parked vehicle that is likely to be exposed to 1. Install the suction cups into the windshield extremely hot or cold temperatures. -
Page 12: Installing The 12-Volt Adapter
Insert the small end into the you must keep a battery in the PNI jack marked “POWER”, located on the back V2000 at all times to allow the unit to of the compass and plug the large end into keep memory settings. -
Page 13: Installing The Temperature Sensor
INSTALLING THE PNI V2000 Installing the temperature sensor 1. Insert the connector end of the tether The included temperature sensor and tether into the jack marked “ ” located on TEMP may be used outside or inside the vehicle. the back of the compass. - Page 14 ” will PLUG IN THE SENSOR cycle twice in the lower right corner. Do not leave the PNI V2000 in a parked vehicle that is likely to be exposed to extremely hot or cold temperatures. A temperature sensor tether that is...
-
Page 15: Calibration
4. Press seconds. “ ” displays briefly in lower right DONE 2. Press corner. The V2000 is now calibrated. At the same time, “ ” will TURN ONCE flash on and off in the lower left corner, and “ TURN ONCE THEN PRESS CAL TO... -
Page 16: Bearing Point Mode
BEARING POINT MODE Bearing point allows one numeric heading to 3. Press be stored and displayed for use as a reference The stored bearing point appears numer- point. If the battery was just installed, 00° ically in the lower right corner and as a displays in the lower right corner. -
Page 17: Temperature Mode
Temperature display is turned on or off. The message “ PRESS AGAIN TO STEP HOLD ” cycles in the lower right corner. The PNI V2000 displays temperature readings TO SELECT between 1°F and 158°F (-17°C to 70°C). 2. Press Either °C or °F flashes in the lower right... -
Page 18: Ice Alert Feature
ICE alert feature warns -17°C minimum. you if the temperature drops to 35°F (2°C). When this happens, the PNI V2000 will Similarly, If the temperature rises above 158°F automatically switch to temperature mode (70°C), the display will flash “... -
Page 19: Backlight Mode
BACKLIGHT MODE Press to turn the backlight on or off. To 3. Hold program the backlight auto shut-off value, To select the interval for the auto shut-off do the following: until “ ” displays. DONE 1. Hold 4. Press “ ”... -
Page 20: Photo Diode Feature
BACKLIGHT MODE Photo diode feature The 12-volt adapter or optional hard- The PNI V2000 comes equipped with a photo wire kit must be installed for the photo diode light sensor that turns the backlight on diode feature to work. or off depending on the amount of ambient light it senses. -
Page 21: Optional Accessories
OPTIONAL ACCESSORIES A hard-wire kit is available for an addi- A 30-foot temperature sensor tether is tional charge by calling our customer ser- available for an additional charge by vice department at (888) 422-6672 from calling our customer service depart- anywhere in the U. -
Page 22: Frequently Asked Questions
Where can the PNI V2000 be used? difference in the earth’s field from your vehicle’s The PNI V2000 can be used in any type of magnetic field.The PNIV2000’s microprocessor vehicle including cars, trucks, vans, SUVs, electronically subtracts out your vehicle’s... - Page 23 S, SSW, SW, WSW, W, WNW, NW, NNW) displays inaccurate compass readings. give you a general sense of direction. The When do I need to calibrate the PNI V2000? numeric digits show your exact direction The PNI V2000 needs to be calibrated when down to the nearest 5 degrees.
- Page 24 Many things generate external magnetic fields battery has just been installed, and calibration causing compass inaccuracy, including metal is necessary. and electronics. The PNI V2000 senses any significant change magnetic fields. How can I improve the calibration process? “...
- Page 25 FREQUENTLY ASKED QUESTIONS unit (if you intend to use the 12-volt adapter). If you typically drive with your headlights and stereo on (or any other electronic instrument), turn these on prior to calibration. How can the bearing point feature help me? Setting a bearing point to a desired heading or to a sighted landmark allows you to monitor and maintain your heading and remain on...
-
Page 26: Service And Replacement
30 days of the purchase. If you wish to (PST) Monday through Friday, with your return the unit for replacement or repair to questions. PNI Corporation, please follow the following procedures: 1. Obtain a return merchandise authoriza- tion (RMA) number by contacting PNI Corporation. - Page 27 SERVICE & REPLACEMENT • By fax: (707) 566-2261 Once you have acquired an RMA number, pack the unit securely to prevent damage • By e-mail: techsupport@pnicorp.com in transit. If possible, use the original 2. Provide a proof of purchase, such as packing material and box.
- Page 28 SERVICE & REPLACEMENT problem to the following address: PNI Corporation 5464 Skylane Blvd., Suite A Santa Rosa, CA 95403-1084 Type or print your name and address where the replacement should be delivered.After receipt of your documents and unit, a replacement unit will be sent to you.
-
Page 29: Limited Warranty
(ii) the period of time remaining on the original one (1) year If the product is found by PNI to be defective warranty. and you have provided proof of purchase acceptable to PNI, PNI’s entire liability and... - Page 30 MERCHANTABILITY AND OF FITNESS including, but not limited to, loss of use, FOR A PARTICULAR PURPOSE, OR (2) revenue, or profit. In no event shall PNI’s THAT USE OF THE PRODUCT WILL BE total liability for all claims regarding the UNINTERRUPTED AND ERROR FREE.
- Page 32 PNI Corporation www.pnicorp.com 80-1284-0001 Version D1-01...
