System Overview; Console Video Game Adapter - Logitech Z-640 Setup

Thank you for purchasing the Z-640 speaker system from Logitech. The Z-640 system will
raise your audio experience to new levels. To discover more Logitech products, visit us on the
web at www.logitech.com.
1. Subwoofer
2. Right front speaker
—black plug
3. Right rear speaker
—red plug
4. Audio input cable to PC
—green, black and
orange plugs
5. Center channel speaker
—black d-sub connector
6. Power cord
7. Left rear speaker
—white plug
8. Left front speaker
—yellow plug
9. Subwoofer volume
A. Power button
B. System Volume knob
C. Fader knob
D. Power light
E. Center volume knob
F. Matrix button
G. Headphone jack

Console Video Game adapter

(not used with PCs)
RCA jacks
from console
2
-
SUB
VOLUME
3
CENTER
4
5
C
Stereo mini
to speakers
B
A
1
9
+
6
8
7
D
E
F
G
2
