PR-216 SPECIFICATIONS
Audio Output:
Headset output +16 dBu
(low impedance)
Connector:
3.5 mm stereo/mono input used for:
Headphone cord antenna to receiver
•
• Audio output to headphone
• Battery charger input
•
Auxiliary power input
Indicators:
Three function LED
Power
•
• Battery status
• R.F. signal ON and OFF
Controls:
• Power On/Off switch
• Volume control (50 dB range)
•
EnviroMic ON/OFF switch (optional)
99-position rotary channel
•
selector switches
Audio Frequency Response:
80 Hz to 12 kHz ±3 dB
Harmonic Distortion:
Less than 1% (1 kHz tone 5 kHz
deviation)
Operating Radio Frequency:
•
216 to 217 MHz
Frequency synthesized
•
Frequency Stability:
0.002% frequency synthesized
crystal controlled
RF
Adjacent Channel Rejection:
Spurious Rejection:
Ultimate Quieting:
Deviation Acceptance:
Antenna:
Current Drain:
Power Requirements:
FCC Compliance:
Dimensions:
NOTE: Specifications subject to
Page 12
Sensitivity:RF Sensitivity:
0.3 µV for 12 dB SINAD
65 dB 50 kHz off channel
60 dB (image excluded)
Better than 95 dB
Up to 10 kHz
Integral with output cable
(no external antenna)
18 mA nominal
9 volt alkaline battery,
Eveready 522 or equivalent
or 9 volt Ni-MH rechargeable
Complies with Part 15
of FCC rules
1 1 /16" x 2 1 /2" x 3 1 /4"
(27 mm x 57 mm x 83 mm)
change without notice
