Summary of Contents for TouchTunes DA415
- Page 2 Montreal, Quebec, Canada H4N 3L4 Telephone: 1-847-419-3300 Fax: (847) 419-3304 TouchTunes may use or distribute whatever information you supply in any way it believes appropriate without incurring any obligations to you. Copyright © 2009 TouchTunes Interactive Networks. All rights reserved, including those to reproduce this publication or parts thereof in any form without permission in writing from TouchTunes Interactive Networks.
-
Page 3: Table Of Contents
Contacting TouchTunes ........ -
Page 5: Introduction
Contacting TouchTunes ........ -
Page 6: Package Contents
Part No. Description Quantity 700039-002 DA415 amplifier (3-channel) 700039-001 DA415 amplifier (4-channel) 300180-026 AC power cable The following accessories for the DA415 amplifier are also available from TouchTunes: Part No. Description 300142-018 Category 5 cable, RJ45-RJ45 100000-001 Euroblock connector kit Specifications •... -
Page 7: Important Safety Information
Do not remove the cover or back. There are no user-serviceable parts inside. Servicing must be performed by qualified personnel only. WARNING: To reduce the risk of fire or electric shock, do not expose the DA415 to rain or moisture. - Page 8 Introduction Contacting TouchTunes Directly from the Dashboard You can use the Contacts page in the TouchTunes Dashboard to email many departments at TouchTunes, including Technical Support. Using the Contacts page is the easiest way to contact TouchTunes and also allows TouchTunes to respond to your question, problem or request very quickly.
-
Page 9: Hardware Overview And Installation
Hardware Overview and Installation This section provides an overview of the DA415 three-channel and four- channel amplifiers, and explains important installation procedures. Contents Overview ..............9 Features . -
Page 10: Features
Hardware Overview and Installation • A 4-channel, 2-zone amplifier: This amplifier is currently offered in the TouchTunes Ovation wall-mounted jukebox. Features The DA415 amplifiers incorporate the following features: Four-channel Three-channel Feature/Specification amplifier amplifier Class-T Architecture. Proprietary digital processing technology. Uncompromising sound quality. -
Page 11: Speaker Wiring Guide
Similarly, wiring two pairs of Bose model 301 speakers in parallel will result in unsatisfactory performance and may cause damage to your equipment. Example 1: TouchTunes 2-Way Speakers This example illustrates wiring of TouchTunes 2-way speakers (maximum 4 per channel) for a total impedance load of 4 ohms. Row 1... - Page 12 Hardware Overview and Installation Row (series) impedance specifications Row 1 2 speakers in series: 4.0 ohms + 4.0 ohms for a total of 8 ohms per row. Row 2 2 speakers in series: 4.0 ohms + 4.0 ohms for a total of 8 ohms per row.
-
Page 13: Three-Channel Amplifier
DA415 Three-channel Amplifier 1. Power connector Connect the supplied power cord here. The DA415 will automatically start when the power cord is plugged into a wall outlet (AC 120V /60Hz MAX 1000W). There is no power switch. CAUTION: Do not connect the AC power cord to a wall outlet until all audio connections have been completed. - Page 14 Installation Please refer to the figure on page 13 while performing the installation. 1. Ensure that the power supply cord is disconnected from the power connector on the DA415 amplifier. 2. Connect a standard category 5 cable with RJ45 connectors from the Zone 1 output on the MJS to the input connector (3) on the DA415 amplifier.
-
Page 15: Four-Channel Amplifier
Four-channel Amplifier Four-channel Amplifier The DA415 4-channel amplifier is shown in the figure below. DA415 Four-channel Amplifier Unlike the 3-channel model, the 4-channel amplifier does not support daisy-chaining of components; the RJ45 connectors for Zones A and B are both inputs. - Page 16 3. Zone A and Zone B audio input connectors Two RJ45 connectors are provided to connect the DA415 to the Zone A and Zone B audio outputs of the MJS via standard category 5 cable.
-
Page 17: Amplifier Conversion
(AC 120V /60Hz MAX 1000W) and the power connector on the amplifier. Amplifier Conversion It is possible to convert a DA415 amplifier from a 3-channel to a 4-channel version, and vice- versa, by changing the amplifier’s I/O board. Such a procedure should be undertaken by qualified service personnel only. - Page 18 Hardware Overview and Installation...
- Page 19 TouchTunes Interactive Networks, Inc. TouchTunes Interactive Networks, Inc. Technical Support 400 Sainte Croix Avenue, Suite 200 E 3455 Salt Creek Lane, Suite 100 847-353-1954 Montreal, Quebec, Arlington Heights, IL 60005 www.touchtunes.com Canada, H4N 3L4 Copyright © 2009 TouchTunes Interactive Networks...
