IC Dynamics RS160 User Manual

FOR USE WITH AUTOMATIC TRANSMISSION VEHICLES ONLY!
Do not use the remote start function when parked in an enclosed area or without sufficient ventilation, as carbon
monoxide build up may occur, resulting in serious injury or death. It is the operator's responsibility to use the
remote start function in a safe manner, so make sure to place the system into valet mode if the vehicle is being
serviced or if it is being used by an unfamiliar driver.
STANDARD FEATURES
The system's standard features include:
• 4-button remote transmitter
• Extended range receiver w/built-in LED sta-
tus indicator & valet switch
• Flashing parking lights
• Auto cold Start feature
• Stop & go feature
• Programmable engine run-time
• Hood & brake pedal safety inputs

OPTIONAL FEATURES

This system has optional features that may
require additional parts and/or labor. Please
contact your dealer for more details.
• Remote keyless entry (door lock/unlock)
• Remote trunk/hatch release
Note: Some features may not be appropriate
for certain vehicles.
REMOTE TRANSMITTER BUTTONS
Button 1
Button 3
Transmitter Icons
RS160 REMOTE START SYSTEM
IMPORTANT SAFETY NOTICE
Button 2
Button 4

SYSTEM OPERATION

DOOR LOCKING*
To lock the doors press button 1:
• The parking lights flash once.
• The horn honks once.*
• The doors lock.*
• The LED begins flashing after 5 seconds.
*Optional Feature
LOCK BUTTON WINDOW ROLL UP*
This feature rolls up the windows and closes
the sunroof on some late model vehicles.
To activate the Window Roll Up feature:
1. Press and release button 1 to lock the
doors.
2. Press and hold button 1 again until the
windows and sunroof are closed.
• The LED flashes once.
• The parking lights flash once.
• The doors lock.*
The optional Window Roll Up feature acti-
vates long as button 1 is held. This feature
rolls up the windows and closes the sunroof
on some late model vehicles.
*Optional Feature
DOOR UNLOCKING*
To unlock the doors press button 2.
• The parking lights flash twice.
• The horn honks twice.*
1
