MobilePal™ 8000mAh Qi Wireless Power Bank
Thank you for choosing the MobilePal™ Qi wireless power bank! Before using the product,
please read the manual carefully and follow the instructions to operate properly.
The MobilePal™ QiWi™ power bank is an innovative, carefully crafted Qi wireless and wired
charger with an integrated high-capacity portable power bank. It provides you the ultimate
convenience of charging your smartphones, tablets, digital cameras, MP3/MP4 players, and other
electronic devices at home, in your office, or on the go. This manual applies to the mid-2014
8000mAh wireless power bank.
Feature Overview
• Integrated Qi wireless charging transmitter for wirelessly charging most devices
conforming to the Qi charging standard, either as a wireless charging pad or a charging
station in the pass-through mode.
• Integrated high-capacity, grade-A lithium-polymer battery for on-the-go use.
• Dual 2.1A USB outputs optimized for Apple and Samsung devices, respectively.
• A 2-in-1 Lightning+Micro-USB high-speed charging cable included for your
convenience to charge Apple and Android devices at high speed.
• Simultaneous wireless charging via Qi wireless and wired charging via USB ports.
• Intelligent circuit for avoiding short-circuiting, over-charging, and malfunctioning.
• Certifications: CE, FCC, RoHS
User Manual
1
Advertisement
Table of Contents
Related Manuals for MobilePal 8000mAh Qi Wireless Power Bank
Summary of Contents for MobilePal 8000mAh Qi Wireless Power Bank
-
Page 1: User Manual
MobilePal™ 8000mAh Qi Wireless Power Bank User Manual Thank you for choosing the MobilePal™ Qi wireless power bank! Before using the product, please read the manual carefully and follow the instructions to operate properly. The MobilePal™ QiWi™ power bank is an innovative, carefully crafted Qi wireless and wired charger with an integrated high-capacity portable power bank. - Page 2 Technical Specifications ITEM SPECIFICATION Model 8000mAh (mid-2014) Input 5V, 1A (MAX) USB Output 1 5V±0.25V, 2.1A (optimized for Samsung devices) USB Output 2 5V±0.25V, 2.1A (optimized for Apple devices) Wireless Output Cell Type Li-polymer 3.75V, 8000mAh Charging Efficiency >85% for wired charging; >70% for wireless charging Charging Frequency 100--200KHz Wireless Distance...
- Page 3 • When charging, the blue LEDs will flash one by one. Each blue light indicates 25% of the charge. When fully charged, all blue LED lights will stay on. • When recharging the power bank, you can charge other devices in pass-through mode.
- Page 4 short-circuit, over-heating, smoking, fire, deformation, or even explosion of the battery. Do not touch the device if your hands or feet are wet. Store and charge your device in a cool and ventilated place. • Do not store or charge your QiWi in very hot or very cold areas. Extreme temperatures can damage the device and reduce the charging capacity of the battery.
- Page 5 GPS on your mobile device when charging. Warranty Information MobilePal LLC warrants that this device is free from defects in material and workmanship under normal use for twelve (12) months commencing upon the date of purchase by the first consumer purchaser.
