- Page 1 Network Video Recorder Quick Operation Guide...
-
Page 2: Nvr Pre-Installation
Quick Operation Guide of Premium IP Series NVR Thank you for purchasing our product. If there is any question or request, please do not hesitate to contact dealer. NVR Pre-Installation This series NVR are highly advanced surveillance equipment that should be installed with care. Please take into consideration the following precautionary steps before installation of the NVR. - Page 3 Quick Operation Guide of Premium IP Series NVR Connect the power cable to the HDD. Place the HDD on the bottom of the device and then fasten the screws on the bottom to fix the HDD. Re-install the cover of the NVR and fasten screws.
-
Page 4: Rear Panel
Quick Operation Guide of Premium IP Series NVR Rear Panel (with 8 POE) Note: The rear panels of others provide 8 POE interfaces. Item Description Connector for LAN (Local Area Network). LAN Network Interface Connects to RS-485 devices. RS-485 Interface... - Page 5 Quick Operation Guide of Premium IP Series NVR Up position shows the RS-485 is not terminated. Down position shows the RS-485 is terminated with 120Ω resistance. RS-485 Interface Connector for RS-485 devices. T+ and T- pins connects to R+ and R- pins of PTZ receiver respectively.
-
Page 6: Specifications
Quick Operation Guide of Premium IP Series NVR Specifications Model IP video input 8-ch Video/Audio input 1-ch, RCA (2.0 Vp-p, 1kΩ) Two-way audio input Incoming bandwidth 40Mbps Bandwidth Output bandwidth 40Mbps Decoding resolution 5MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF 1-ch, resolution: HDMI/VGA output 1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 ×... - Page 7 Quick Operation Guide of Premium IP Series NVR 16 channels Model IP video input 16-ch Video/Audio input 1-ch, BNC (2.0 Vp-p, 1kΩ) Two-way audio Recording 5MP /3MP /1080P /UXGA /720P /VGA /4CIF /DCIF /2CIF /CIF resolution /QCIF Main stream: 25 fps (P) / 30 fps (N)
-
Page 8: Hdd Storage Calculation Chart
Quick Operation Guide of Premium IP Series NVR HDD Storage Calculation Chart The following chart shows an estimation of storage space used based on recording at one channel for an hour at a fixed bit rate. Bit Rate Storage Used... -
Page 9: Menu Operation
Quick Operation Guide of Premium IP Series NVR Menu Operation Menu Structure Startup and Shutdown Proper startup and shutdown procedures are crucial to expanding the life of the NVR. To start your NVR: 1. Check the power supply is plugged into an electrical outlet. It is HIGHLY recommended that an Uninterruptible Power Supply (UPS) be used in conjunction with the device. -
Page 10: Using The Start Wizard
Quick Operation Guide of Premium IP Series NVR Using the Start Wizard By default, the Setup Wizard starts once the NVR has loaded, as shown in Figure below. Start Wizard Interface Operating the Setup Wizard: 1. The Setup Wizard can walk you through some important settings of the NVR. If you don’t want to use the Setup Wizard at that moment, click the Cancel button. - Page 11 Quick Operation Guide of Premium IP Series NVR Internal NIC IPv4 Addre Network Configuration Note: the internal NIC IPv4 address should be configured for the cameras connecting to the PoE network interface or the built-in switch of the NVR. 7. Click Next button after you configured the network parameters, which takes you to the HDD Management window.
-
Page 12: Live View
Quick Operation Guide of Premium IP Series NVR Search for IP Cameras 11. Click Next button. Configure the recording for the searched IP Cameras. Record Settings 12. Click Copy to copy the settings to other channels. Copy Record Settings 13. Click OK to complete the startup Setup Wizard. -
Page 13: Ptz Control
Quick Operation Guide of Premium IP Series NVR PTZ Control Follow the procedure to set the parameters for PTZ. The configuring of the PTZ parameters should be done before you set the PTZ camera. Before you start, please check that the PTZ and the NVR are connected properly through RS-485 interface. - Page 14 Quick Operation Guide of Premium IP Series NVR PTZ Control Bar Description of the PTZ toolbar icons Icon Description Icon Description Icon Description Direction button and Zoom+, Focus+, Zoom-, Focus-, Iris- the auto-cycle button Iris+ The speed of the Light on/off...
- Page 15 Quick Operation Guide of Premium IP Series NVR Playback Play back the record files of a specific channel in the live view menu. Channel switch is supported. Instant playback by channel Steps: Choose a channel in live view mode using the mouse and click the button in the quick setting toolbar.
- Page 16 Quick Operation Guide of Premium IP Series NVR Playback Interface Just check the channel or channels if you want to switch playback to another channel or execute simultaneous playback of multiple channels. Export Recorded files can be backed up to various devices, such as USB flash drives, USB HDDs or a DVD writer.
- Page 17 Quick Operation Guide of Premium IP Series NVR Enter Export interface, choose backup device and press Export button to start exporting. Quick Export using USB1-1...
- Page 18 Quick Operation Guide of Premium IP Series NVR Checkup of Quick Export Result Using USB1-1...
