Assembly - Robot Coupe J 80 Ultra User Manual

9
4
6
Motor unit Pouring spout
1 8
Bowl Ejector spout
2 9
Flange Feed tube
3 10
Basket Scraper clips
4
11
Lid Filter
5
12
Pulp container Grater disc
6 13
Safety arm
7
10
5
11
12
13
3
2) Position the bowl on
top of the motor unit.
2
8
7
1
4) Position the juicer
basket, holding it by the
scraper clips.
Rotate it until it slots into
position.

ASSEMBLY

1) Place the motor unit so
that it is facing you.
6) Position the pulp
container.
3) Fit the flange on top of
the bowl.
8) Close the safety arm.
To switch the juicer on,
push the switch.
The machine will not start
unless the safety arm
has been properly closed
(safety switch).
Place a container under the pouring spout. Your
juicer is now ready for action!
5) Line the lid up with the
notches in the flange.
7) Insert the pusher.
