Power Plus AIR-102W User Instruction

User's instruction for all-purpose
air conditioner remote controller
Product Introduction Product Introduction
Model AIR-102W All-purpose Air Conditioner Remote Controller has been
designed to remotely control various brands and models of the air
conditioners . This product is characteristic of point-to-point fast brand
searching and automatic digital code searching with low power
consumption, complete functions, long transmission distance, easy
setting, simple operation and fresh visual appearance and comfortable
hand feel which can facilitate you with unlimited convenience. The
product has a large LCD screen which provides easy setting and
operation. It has built-in clock, on/off timer and night illumination function
which have facilitated more convenience for you.
Panel Description：
Panel Description：
1.Signal Sending Display
2.Fan Display
1000 in 1
3.Blowing Direction Display
13
1
4.Backlight
2
14
5.Temperature "+" key
3
6..Mode Key
TIM E ON TIM E O FF
AM AM 15
7.Automatic Blowing
PM PM
AIR-102W Direction Control Key
UNIVERSAL A/C REMOTE
8.Blowing Direction Control Key
9.Timing OFF Key
16
4
10.Timing ON Key
LIGHT ON/OFF
5
11.SET
6
TEMP 17
12.Clock Function Key
18
MODE WIND
7 13.Run Mode Display
14.Temperature Display
8 19
F.Cool
15.Model Code
9 M.SWING A.SWING
16.Power Key
20
TIME ON TIME OFF F.Heat
10
17.Fan Key
21 18 .Te m pe rature "- key
11
Set Ok
CLOCK
19.Fast Cool Key
12
20.Fast Heat Key
21.Confirmation Button
Remarks:
Remarks:
Fast Cool/Heat Key
Press Fast Cool key to automatically set the machine as
refrigerating mode, 21℃, middle wind, automatic blowing
direction;
Press Fast Heat key to automatically set the machine as
heating mode, 27℃, middle wind, automatic blowing direction.
No need to set:
Once the battery is loaded, the remote control can control the
mainstream brands on the market: Gree (YB0F2), Midea,
Toshiba, Chunlan, Haier, Mitsubishi Heavy Industries 388,
Hualing and other brands.
Restore factory settings: press the buttons set and FAN
AIR-102W
simultaneously for three seconds to restore the factory settings.
Note: when the battery is loaded, the combination code does
not have timing function. To use the timing function, please
control according to the setting method described in the
instruction book, which is corresponding to the model.
Battery Installation: Battery Installation:
1. Remove the battery cover of
the remote control, install
two new 7# batteries;
2. Install the battery cover.
The time will appear in
the left corner of LCD
display.
Setting of Remote Control Setting of Remote Control
This remote controller has four setting modes that are marked as A, B, C .
Please select one mode for operation.
A
The brand corresponding point-to-point fast searching
Manually plug-in the air
conditioner, aim the remote
control at the receiving
window of the air conditioner.
Table of brand corresponding keys
GREE/Haier
SANYO\
HISENSE
1 2
Press the code key that
corresponds to your brand and
hold until the air conditioner is
started by giving out a sound
signal. Release the key and the
setting is completed.
SHARP\ MITSUBISHI
LG\
MD\TOSHIBA
KELONG /OTHER
SAMSUNG
/CHANGHONG
CHIGO\ FUJITSU\ CHUNLAN SHINCO\
DAIKIN CARRIER /AUX AUCMA
B
Manually input code
1
Manually plug-in the air
conditioner, find the type
of the air conditioner in
the Code Table, and
find the first code, for
Haier
example:
BRAND CODE
HAIER 001-019
3
Press OK button and the
selected conditioner type
code will stop flickering.
Code
stops
flashing
C Digital automatic search type
1
Manually plug-in the air
conditioner, aim the remote
control at the receiving
window of the air conditioner.
HITACHI\
Panasonic
2
Hold SET button (for about
three seconds) until the
conditioner type code flickers
in the window, press
Temperature or buttons
until the desired code flickers
in the window. When the code
is right, the air conditioner will
start.
Code is
flashing
4
Test whether the remote
control button has been
effectively set. If yes,
setting completes. And
if no, repeat steps 2-3.
2
Hold SET button (for about six
seconds) until the conditioner
type code changes in the
window, indicating you have
entered the high-speed
conditioner type search status.
press OK button to stop
searching until the air
conditioner automatically
starts.
