Topcon RD-100W Instruction Manual

REMOTE DISPLAY
RD-100W
Thank you for purchasing the TOPCON RD-100W.
For the best performance of the instruments, please read these instruc-
tions carefully and keep them in a convenient location for future refer-
ence.
GENERAL HANDLING PRECAUTIONS
Before starting work or operation, be sure to check that the system is
functioning properly.
Affection of the radio waves
When using the instrument in the following place, the strong radio wave
may cause faulty operation.
• Near the instrument occurring strong radio waves. (e.g. Transceiver)
• Near the radio wave towers such as television or radio.
Battery replacement
• Replace all 3 batteries with new ones at the same time. Do not mix
used and new batteries, and do not mix different types of batteries
together.
• Use alkaline dry cells. (3 Dry cells for initial operation check are com-
posed in a standard package.)
Nickel hydrogen dry cells and nickel cadmium dry cells can be used
too, but the operating time is different from the time of alkaline dry
cells.
DISPLAY FOR SAFE USE
In order to encourage the safe use of products and prevent any danger
to the operator and others or damage to properties, important warnings
are put on the products and inserted in the instruction manuals.
We suggest that everyone understand the meaning of the following dis-
plays and icons before reading the "Safety Cautions" and text.
Display
Ignoring or disregard of this display may lead to
WARNING
death or serious injury.
Ignoring or disregard of this display may lead to per-
CAUTION
sonal injury or physical damage to the instrument.
• Injury refers to hurt, burn, electric shock, etc.
• Physical damage refers to extensive damage to buildings or equipment and
furniture.
HANDLING PRECAUTIONS
Guarding the instrument against shock
When transporting the instrument, provide some protection to minimize
risk of shock. Heavy shock may affect beam accuracy.
SAFETY CAUTIONS
• There is a risk of fire, electric shock or physical harm if you attempt to
disassemble or repair the instrument yourself.
This is only to be carried out by TOPCON or an authorized dealer, only!
• Risk of fire or electric shock.
Do not use damaged power cable, plug and socket.
• Risk of fire or electric shock.
Do not use a wet battery.
• May ignite explosively.
Never use an instrument near flammable gas, liquid matter, and do not use in
a coal mine.
• Do not hold the RD-100W magnetic clamp near anyone who uses a pace
maker or other electronic medical devices.
The strong magnetic field can disrupt the normal operation of such devices.
• Battery can cause explosion or injury.
Do not dispose in fire or heat.
• The short circuit of a battery can cause a fire.
Do not short circuit battery when storing it.
Risk of injury to fingers.
Do not place fingers on magnet while mounting to equipment.
Strong magnetic field.
Do not place RD-100W magnetic clamp near any sensitive electronic devices
or magnetic storage media such as computer disk.
Do not allow skin or clothing to come into contact with acid from the batteries,
if this does occur then wash off with copious amounts of water and seek med-
ical advice.
INSTRUCTION MANUAL
Meaning
WARNING
CAUTION
EXCEPTIONS FROM RESPONSIBILITY
1)The user of this product is expected to follow all operating instructions and make
periodic checks of the product's performance.
2)The manufacturer, or its representatives, assumes no responsibility for results of a
faulty or intentional usage or misuse including any direct, indirect, consequential
damage, and loss of profits.
3)The manufacturer, or its representatives, assumes no responsibility for
consequential damage, and loss of profits by any disaster, (an earthquake, storms,
floods etc.).
A fire, accident, or an act of a third party and/or a usage any other usual conditions.
4)The manufacturer, or its representatives, assumes no responsibility for any
damage, and loss of profits due to a change of data, loss of data, an interruption of
business etc., caused by using the product or an unusable product.
5)The manufacturer, or its representatives, assumes no responsibility for any
damage, and loss of profits caused by usage except for explained in the user
manual.
6)The manufacturer, or its representatives, assumes no responsibility for damage
caused by wrong movement, or action due to connecting with other products.
Standard Set Composition
1 RD-100W Instrument ..................................... 1pc.
2 AA-size dry cells............................................. 3pcs.
3 Instruction manual.......................................... 1pc.
FCC WARNING
Changes or modifications not expressly approved by the manufacturer for
compliance could void the user's authority to operate the equipment.
In order to comply with FCC radio-frequency radiation exposure guidelines
for an uncontrolled exposure, this device and its antenna must not be co-
located or operating in conjunction with any other antenna or transmitter.
This equipment complies with FCC/IC radiation exposure limits set forth for
uncontrolled equipment and meets the FCC radio frequency (RF) Expo-
sure Guidelines in Supplement C to OET65 and RSS-102 of the IC radio
frequency (RF) Exposure rules. This equipment has very low levels of RF
energy that it is deemed to comply without testing of specific absorption
ratio (SAR).
This device complies with Part 15 of FCC Rules and RSS-Gen of IC Rules.
Operation is subject to the following two conditions : (1) this device may
not cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of this device.
