COLOUR TELEVISION
INSTRUCTIONS
Thank you for buying this JVC
colour television.
To make sure you understand how to
use your new TV, please read this
manual thoroughly before you begin.
AV-16N211
AV-21Y211
GGT0010-001A-E
0803-NIC-JMT
Contents
2 Inserting the batteries ................................... 3
4 Connecting the power cord ........................ 5
5 SETUP TOUR .............................................. 6
ECO SENSOR button ..................................... 8
PICTURE MODE button ................................. 8
COLOUR SYSTEM button ............................. 8
SOUND SYSTEM button ............................... 8
DISPLAY button ............................................. 9
MUTING button ............................................. 9
OFF TIMER button ......................................... 9
PICTURE BOOSTER button ........................... 9
RETURN + button ........................................ 10
CHANNEL SCAN button .............................. 10
Basic operation ............................................ 11
INPUT ........................................................... 12
ON TIMER ..................................................... 12
AUTO SHUTOFF .......................................... 13
CHILD LOCK ................................................. 13
BLUE BACK .................................................. 13
AI ECO DISPLAY .......................................... 14
SETUP TOUR ............................................... 14
AUTO CH PRESET ....................................... 14
MANUAL CH PRESET .................................. 15
SKIP .............................................................. 16
LANGUAGE .................................................. 16
Picture Adjustments .................................... 16
© 2003 VICTOR COMPANY OF JAPAN, LIMITED
2
2
7
11
17
18
19
Back cover
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for JVC AV-16N211
Summary of Contents for JVC AV-16N211
-
Page 1: Table Of Contents
COLOUR TELEVISION INSTRUCTIONS Thank you for buying this JVC colour television. To make sure you understand how to use your new TV, please read this manual thoroughly before you begin. AV-16N211 AV-21Y211 GGT0010-001A-E 0803-NIC-JMT Contents Safety precautions Preparation 1 Confirm which remote control you have ... 3 2 Inserting the batteries ... -
Page 2: Safety Precautions
• Do not allow objects or liquid into the cabinet openings. • In the event of a fault, unplug the TV and bring to JVC service centre. Do not attempt to repair it by yourself or remove the rear cover. -
Page 3: Preparation
• Use AA/R6/UM-3 dry cell batteries. • If the remote control does not work properly, fit new batteries. The supplied batteries are for testing, not regular use. - / -- RM-C367GY For TV model: AV-16N211 PICTURE POWER SENSOR BOOSTER SYSTEM PICTURE... -
Page 4: Connecting The Aerial And External Devices
Preparation 3 Connecting the aerial and external devices • For further details, refer to the manuals provided with the devices you are connecting. • Connecting cables are not supplied. • The front and rear AUDIO/VIDEO input jacks are directly connected so that input to either jack is output through both. -
Page 5: Connecting The Power Cord
Preparation ■ Connecting other external devices VIDEO AUDIO • Illustration of AV-21Y211 Headphones • Use the headphones with a stereo mini jack (3.5 mm in diameter). When you connect the headphones, the TV speakers go off. • Because the front AUDIO jacks are monaural, even stereo input becomes monaural. 4 Connecting the power cord Connect the power cord to the AC outlet. -
Page 6: Setup Tour
Preparation 5 SETUP TOUR When the TV is first turned on, it enters the SETUP TOUR mode, and the JVC logo is displayed. Follow the instructions on the on-screen display to perform the SETUP TOUR. • In case of resetting that the reason for such as removal, you can set the AUTO CH PRESET function on the “MENU 3”... -
Page 7: Basic Operation
Basic operation The illustration below is for the remote control RM-C367GY. Your remote control may not look exactly like the illustration. PICTURE POWER BOOSTER SENSOR SYSTEM PICTURE COLOUR SOUND MODE TV/VIDEO TIMER CHANNEL RETURN SCAN DISPLAY MUTING MENU CHANNEL VOLUME REMOTE CONTROL UNIT RM-C367GY 1 Press the POWER button to turn... -
Page 8: Remote Control Buttons And Functions
Remote control buttons and functions ECO SENSOR button <AV-16N211 only> You can adjust this TV so that the screen automatically adjusts to the optimum contrast according to the brightness of your room. This function reduces eye strain and the power consumption of this Press this button to select the desired mode. -
Page 9: Display Button
Remote control buttons and functions DISPLAY button You can continuously display the current channel number or VIDEO mode on the screen. Press this button. To turn the display off, press this button again. • When selecting a VIDEO mode with no signal, indication of the VIDEO mode becomes fixed on the screen. -
Page 10: Return + Button
Remote control buttons and functions RETURN + button You can set a channel you frequently view to the Return Channel and you can view that channel at any time with one-touch. To set the channel to the Return Channel: 1 Select the channel you want to set to the Return Channel. -
Page 11: Using The Tv's Menus
Using the TV’s menus This TV has a number of functions you can operate using the menus. To use all your TV’s functions fully, you need to understand how to use the menus. CHANNEL RETURN SCAN DISPLAY MUTING DISPLAY button MENU MENU –/+ buttons... -
Page 12: Input
Using the TV’s menus INPUT You can view images from VCRs or other devices connected to your TV. 1 Press MENU T to display the “MENU 1” menu, then select “INPUT”. MENU INPUT ON TIMER PR 1 0:00 SELECT BY EXIT BY OPERATE BY -+ D I SPLA Y... -
Page 13: Auto Shutoff
Using the TV’s menus AUTO SHUTOFF You can set your TV to turn off if no signals are received for about 15 minutes or longer after the end of a broadcast. 1 Press MENU T to display the “MENU 2” menu, then select “AUTO SHUTOFF”. -
Page 14: Ai Eco Display
SELECT BY EXIT BY OPERATE BY -+ D I SPLA Y 2 Press MENU M. JVC logo is appear and the SETUP TOUR function will start. For details, see page 6. AUTO CH PRESET You can automatically preset all TV channels that can be received by your TV to channels. -
Page 15: Manual Ch Preset
Using the TV’s menus MANUAL CH PRESET You can manually preset desired TV channels to desired channels. 1 Press MENU T to display the “MENU 3” menu, then select “MANUAL CH PRESET”. MENU AUTO CH PRESET MANUAL CH PRESET SETUP TOUR LANGUAGE ENGLISH SELECT BY... -
Page 16: Skip
Using the TV’s menus SKIP You can set undesired channels to be skipped. Channels set to be skipped cannot be selected by the CHANNEL m buttons or the CHANNEL SCAN button. • Channels to which TV channels have not been preset are automatically set to be skipped. -
Page 17: Tv Buttons And Parts
TV buttons and parts <AV-21Y211> VIDEO AUDIO <AV-16N211> MENU VIDEO AUDIO 1 Headphone jack 2 VIDEO/AUDIO terminal 3 MENU buttons • MENU button • MENU m buttons 4 CHANNEL m buttons 5 VOLUME m buttons 6 AI ECO sensor ON TIMER POWER... -
Page 18: Using The Buttons On The Tv
Using the buttons on the TV Basic operation Check to make sure the CHILD LOCK function is set to “OFF”. When the CHILD LOCK function is set to “ON”, the TV cannot be operated using the front control buttons. For details, see “CHILD LOCK” on page 13. -
Page 19: Troubleshooting
Troubleshooting If there is no picture or the TV does not operate normally, make sure the problem isn’t due to the reasons indicated below. If the problem persists even after taking the measures indicated, please contact a service technician. Cannot turn the TV on •... -
Page 20: Specifications
(S11 to S20) and hyper band (S21 to S41). VIDEO input (RCA), AUDIO input (RCA) VIDEO output (RCA), AUDIO output (RCA) stereo mini jack (3.5 mm diameter) AV-16N211 Maximum 85 W, Average 54 W Picture tube 423 mm...
