COLOUR TELEVISION
INSTRUCTIONS
Thank you for buying this JVC
colour television.
To make sure you understand how to
use your new TV, please read this
manual thoroughly before you begin.
AV-16KG11
AV-16KG21
Contents
2 Inserting the batteries ..................................... 3
4 Connecting the power cord ........................ 6
5 SETUP TOUR .............................................. 6
PICTURE MODE button ................................. 8
COLOUR SYSTEM button ............................. 8
SOUND SYSTEM button ............................... 8
DISPLAY button ............................................. 9
RETURN + button .......................................... 9
CHANNEL SCAN button ................................ 9
MUTING button ............................................. 9
OFF TIMER button ......................................... 9
Basic operation ............................................ 12
ON TIMER ..................................................... 13
INPUT ........................................................... 13
VNR ............................................................... 13
AUTO SHUTOFF .......................................... 14
CHILD LOCK ................................................. 14
BLUE BACK .................................................. 14
Picture Adjustments .................................... 15
SETUP TOUR ............................................... 15
AUTO CH PRESET ....................................... 15
MANUAL CH PRESET .................................. 16
SKIP .............................................................. 17
LANGUAGE .................................................. 17
TEXT (Teletext Language) ........................... 17
2
3
7
10, 11
12
18
19
Back cover
LCT1369-001A
Advertisement
Table of Contents
Related Manuals for JVC AV-16KG21
Summary of Contents for JVC AV-16KG21
-
Page 1: Table Of Contents
COLOUR TELEVISION INSTRUCTIONS Thank you for buying this JVC colour television. To make sure you understand how to use your new TV, please read this manual thoroughly before you begin. AV-16KG11 AV-16KG21 Contents Safety precautions Preparation 1 Confirm which remote control you have ... 3 2 Inserting the batteries ... -
Page 2: Safety Precautions
Safety precautions WARNING • To prevent fire or shock hazard, do not expose the TV to rain or moisture. CAUTION • Operate only from the power source indicated on the rear of the TV. • Avoid damaging the power cord and mains plug. When you unplug the TV, pull it out by the mains plug. -
Page 3: Preparation
Preparation 1 Confirm which remote control you have Your TV comes with one of the two remote controls shown below. Functions you can operate differ depending on the type of remote control. RM-C91 SYSTEM COLOUR SOUND MUTING DISPLAY MENU TV/VIDEO TIMER PICTURE MODE... -
Page 4: Connecting The Aerial And External Devices
Preparation 3 Connecting the aerial and external devices • For further details, refer to the manuals provided with the devices you are connecting. • Connecting cables are not supplied. • The front and rear AUDIO/VIDEO input jacks are directly connected so that input to either jack is output through both. -
Page 5: Connecting Other External Devices
Preparation ■ Connecting other external devices VIDEO Headphones • Use the headphones with a stereo mini jack (3.5 mm in diameter). When you connect the headphones, the TV speakers go off. To audio output VCR (for playing) AUDIO VCR (for recording) To audio input To video... -
Page 6: Connecting The Power Cord
Operate only from the power source indicated on the rear of the TV. 5 SETUP TOUR When the TV is first turned on it enters the SETUP TOUR mode, and the JVC logo is displayed. Follow the instructions on the on-screen display to perform the SETUP TOUR. -
Page 7: Basic Operation
Basic operation • The illustration below is for the remote control RM-C91. Your remote control may not look exactly like the illustrations. POWER SYSTEM COLOUR SOUND MUTING DISPLAY TV/TEXT MENU TV/VIDEO TIMER PICTURE MODE CHANNEL RETURN+ SCAN CHANNEL VOLUME TEXT REVEAL HOLD INDEX... -
Page 8: Remote Control Buttons And Functions
Remote control buttons and functions PICTURE MODE button You can select one of three picture adjustment settings as you like. Press this button to select a mode. BRIGHT: Heightens contrast and sharpness. STANDARD: Standardizes picture adjustments. SOFT: Softens contrast and sharpness. •... -
Page 9: Display Button
Remote control buttons and functions DISPLAY button You can continuously display the current channel number or VIDEO mode on the screen. Press this button. To turn the display off, press this button again. • When selecting a channel or VIDEO mode with no input signal, indication of selected channel or VIDEO mode becomes fixed on the screen. -
Page 10: Viewing Teletext Programmes
Viewing teletext programmes <Only for AV-16KG21> SYSTEM COLOUR SOUND MUTING DISPLAY MENU TV/VIDEO TIMER PICTURE MODE CHANNEL RETURN+ SCAN CHANNEL VOLUME TEXT REVEAL HOLD INDEX SUBPAGE RM-C91 TV/TEXT button Coloured buttons REVEAL button SUBPAGE button HOLD button SIZE buttonI CANCEL button INDEX button ■... - Page 11 Viewing teletext programmes REVEAL Some teletext pages include hidden text (such as answers to a quiz). You can display the hidden text. Each time you press the REVEAL button, text is hidden or revealed. HOLD You can hold a teletext page on the screen for as long as you want, even while several other teletext pages are being received.
-
Page 12: Using The Tv's Menus
Using the TV’s menus This TV has a number of functions you can operate using the menus. To use all your TV’s functions fully, you need to understand how to use the menus. SYSTEM COLOUR SOUND MUTING DISPLAY DISPLAY button MENU MENU buttons... -
Page 13: On Timer
Using the TV’s menus ON TIMER Your TV will automatically turn on and tune into the channel you set after the period of time you set. 1 Press MENU T to display the “MENU 1” menu, then select “ON TIMER”. MENU Channel INPUT... -
Page 14: Auto Shutoff
Using the TV’s menus AUTO SHUTOFF You can set your TV to turn off if no signals are received for about 15 minutes or longer after the end of a broadcast. 1 Press MENU T to display the “MENU 2” menu, then select “AUTO SHUTOFF”. -
Page 15: Picture Adjustments
SELECT BY EXIT BY OPERATE BY -+ D I SPLA Y 2 Press MENU JVC logo is appear and the SETUP TOUR function will start. For details, see page 6. AUTO CH PRESET You can automatically preset all TV channels that can be received by your TV to channels. -
Page 16: Manual Ch Preset
Using the TV’s menus MANUAL CH PRESET You can manually preset desired TV channels to desired channels. 1 Press MENU T to display the “MENU 3” menu, then select “MANUAL CH PRESET”. MENU AUTO CH PRESET MANUAL CH PRESET SETUP TOUR LANGUAGE ENGLISH SELECT BY... -
Page 17: Skip
Using the TV’s menus SKIP You can set undesired channels to be skipped. Channels set to be skipped cannot be selected by the CHANNEL m buttons nor the CHANNEL SCAN button. • Channels to which TV channels have not been preset are automatically set to be skipped. -
Page 18: Using The Buttons On The Tv
Using the buttons on the TV MENU CHANNEL VOLUME EXIT Basic operation • Check to make sure the CHILD LOCK function is set to “OFF”. When the CHILD LOCK function is set to “ON”, the TV cannot be operated using the front control buttons. For details, see “CHILD LOCK”... -
Page 19: Troubleshooting
Troubleshooting If there is no picture or the TV does not operate normally, make sure the problem isn’t due to the reasons indicated below. If the problem persists even after taking the measures indicated, please contact a service technician. Cannot turn the TV on •... -
Page 20: Specifications
Language displayed by teletext English, French, Turkish, Arabic, Farsi Accessories • Remote control unit: RM-C360GY for AV-16KG11, RM-C91 for AV-16KG21 • AA / R6 / UM-3 dry cell battery × 2 • Rod aerial × 1 • Matching aerial adapter × 1 Design and specifications subject to change without notice.
