- Page 1 NSPIRE ANUAL ARIANTS UTOMATION Version 1.4...
-
Page 2: Table Of Contents
Contents Unpacking ............................. 1 Setup ..............................2 Internet Gateway ..........................2 Pairing and Connecting ........................2 Registering your Room Thermostat ....................3 Your Thermostat ........................... 5 Basic Functions ..........................6 Adjusting the Temperature ......................6 Switching your heating on and off ....................6 Boost Mode (Plus &... -
Page 3: Unpacking
1 x Wall Mount 1 x Wiring Cover 1 x Internet Gateway 1 x Network Cable 1 x Power Supply 2 x AA Batteries 2 x Screws 2 x Wall Plugs Inspire Home Automation | www.inspirehomeautomation.co.uk | Unpacking... -
Page 4: Setup
Room thermostat for 5 seconds. This will make a connection icon, located in the bottom left hand corner, flash. This icon will stay on permanently once a connection has been established. Inspire Home Automation | www.inspirehomeautomation.co.uk | Setup... -
Page 5: Registering Your Room Thermostat
Thermostat, once registered, all devices connected to your Internet Gateway should show in your account. If you purchased the NS1001 PLUS model or Landlord Model, you should have been emailed an activation code to unlock the extra functionality. Click the 'Advanced' tab, then scroll down to ‘Unit Codes’... - Page 6 If you have more than one property and wish to add additional thermostats to your account select advanced, scroll down to the additional units section and click 'Add Device'. You can also name your units within this section. Inspire Home Automation | www.inspirehomeautomation.co.uk | Setup...
-
Page 7: Your Thermostat
Enter the programming menu or activate program advance (PLUS unit only) Select / Boost Multipurpose, changes function and cycles menu options. Activates the Boost function (PLUS unit only) Adjustment Keys Multipurpose, these are used to adjust the desired temperature and program times Inspire Home Automation | www.inspirehomeautomation.co.uk | Your Thermostat... -
Page 8: Basic Functions
Your heating will switch on when the clock reaches program 1 or 2 start time for the current day, and switch off when it reaches the stop time. Your heating will be switched on. Inspire Home Automation | www.inspirehomeautomation.co.uk | Your Thermostat... -
Page 9: Boost Mode (Plus & Landlord Versions)
Note Temperature profiling (PLUS Models) Cannot be setup on the unit, and must be done via the website. Entering the program menu when profiling is enabled, will only allow adjustment of the clock. Inspire Home Automation | www.inspirehomeautomation.co.uk | Your Thermostat... -
Page 10: Setting The Clock
A 7 day schedule where the timers can be individually set for each day of the week. To change the program mode, press the 'M' button twice and then use the '+' button to switch between a 5/2 or 7 day schedule. Inspire Home Automation | www.inspirehomeautomation.co.uk | Your Thermostat... -
Page 11: Setting Programs
Pressing the 'S' key will cycle through hours and minutes. These can be adjusted by using the '+' and '-' keys. Pressing the 'M' key again will set this timer and move onto the next one. Figure 6: Timers Inspire Home Automation | www.inspirehomeautomation.co.uk | Your Thermostat... -
Page 12: Your Gateway
Power light No power Initialising Ready Internet light No Connection Unregistered Unit Establishing Connection connection established RF light No device paired Pairing Thermostat not Connection connected established Table 1: Gateway Status Lights Inspire Home Automation | www.inspirehomeautomation.co.uk | Your Gateway... -
Page 13: Troubleshooting
Room Thermostat or the gateway box has only just been switched on, it can my phone / website. take a few minutes after all lights go to green, before the website or mobile Inspire Home Automation | www.inspirehomeautomation.co.uk | Troubleshooting... - Page 14 Room Thermostat is powered up, the low battery indicator is not flashing, and that the RF Link on the Thermostat is displayed. Check the “My Thermostat will not pair or repeatedly loses connection” above for information on how to improve this. Inspire Home Automation | www.inspirehomeautomation.co.uk | Troubleshooting...
-
Page 15: Specification
5C Radio Frequency 2.4 GHz Dimensions 119 x 88 x 22 mm Gateway Power input 5V 1A Internet Connection Wired Ethernet Cable Radio Frequency 2.4 GHz Dimensions 94 x 79 x 24 mm Inspire Home Automation | www.inspirehomeautomation.co.uk | Specification...
