Hardware
Components to buy to
make the cable
HE10 Connector female
10 pins (quantity 2)
Ribbon cable (Quantity
1m or +)
Connection to keypad 4 buttons
Page 18
Pictures
Here is the description of the
connection. Only 5 wires are usefull
to use the 4 buttons of the keypad,
but we advise to connect the 10
wires of the ribbon cable.
Ref. Farnell
249040
148011
XI Other connections
Ref. Radiospares
454-2362
246-8133
Connection to DMX
interface
