QUAD Link D-1 Owner's Manual

Attention before service
Symptom Cause Remedy
LED on Link D-1 Computer is switched off. Switch on the computer.
USB D/A Converter Connection at either end is loose. Re-connect USB cable to
does not glow. secure connection.
Computer does not detect the Go to control panel - >
There is no sound. presence of the Link D-1; outboard Sounds and Audio Devices
DAC does not lock onto incoming Properties - > Audio tab - >
data even with USB cable is Sound playback - > Select the
connected. Link D-1 as default device.
Audio cable to amplifier input not Connect the audio cable.
connected. Turn volume control up to
Volume control is set to minimum. desired level.
Should the above symptoms persist with all instructions observed, your Link D-1 USB D/A
Converter may require servicing.
6
Link D-1
the design and specifications
QH11-MNL0002
Safety Caution
C A U T IO N !
RISK OF ELECTRIC SHOCK
DO NOT OPEN
USB D/A Converter
TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK)
NO USER-REMOVEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED PERSONNEL
AVERTISSEMENT: RISQUE DE CHOC ELECTRIQUE-
Read these instructions.
Follow all instructions.
Keep these instructions.
Heed all warnings.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings.
Install in accordance with the manufacturer's instructions.
Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
Do not defeat the safety purpose of the polarized or
grounding type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wider blade or the
third prong is provided for your safety. If the provided plug
does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
Protect the power cord from being walked on or pinched,
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
Use only attachments/accessories specified by the
manufacturer.
Unplug this apparatus during lightning storms or when
unused for long periods of time.
Refer all servicing to qualified service personnel. Servicing
is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
NE PAS OUVRIR
WARNING: To reduce the risk of fire or electrical shock, do
not expose this product to rain or moisture. The product
must not be exposed to dripping and splashing and no
object filled with liquids such as a vase of flowers should
be placed on the product.
No naked flame sources such as candles should be placed
on the product.
CAUTION: Changes or modifications not expressly
approved by the manufacturer could void the user's
authority to operate this device.
WARNING: The mains power switch for this appliance is
located on the rear panel. To permit free access to this
switch, the apparatus must be located in an open area
without any obstructions.
WARNING: The mains plug is used as disconnect device,
the disconnect device shall remain readily operable.
This equipment is a Class II or double insulated
electrical appliance. It has been designed in such
a way that it does not require a safety connection to
electrical earth.
1
