DVS‐4040 Instruction Book
Revision 1
I R T Electronics Pty Ltd A.B.N. 35 000 832 575
26 Hotham Parade, ARTARMON N.S.W. 2064 AUSTRALIA
National:
Phone: (02) 9439 3744
Fax: (02) 9439 7439
International:
+61 2 9439 3744
+61 2 9439 7439
Email: sales@irtelectronics.com
Web:
www.irtelectronics.com
IRT Eurocard
Type DVS‐4040
5x1 ASI / SDI Switcher
Designed and manufactured in Australia
IRT can be found on the Internet at:
http://www.irtelectronics.com
www.irtelectronics.com
Page 1 of 15
4040‐DVS_ib_Rev1.doc

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVS?4040 and is the answer not in the manual?

Questions and answers

Related Manuals for IRT DVS?4040

Summary of Contents for IRT DVS?4040

  • Page 1 +61 2 9439 3744 +61 2 9439 7439 Email: sales@irtelectronics.com Web: www.irtelectronics.com IRT Eurocard Type DVS‐4040 5x1 ASI / SDI Switcher Designed and manufactured in Australia IRT can be found on the Internet at: http://www.irtelectronics.com www.irtelectronics.com Page 1 of 15 4040‐DVS_ib_Rev1.doc...
  • Page 2 DVS‐4040 Instruction Book Revision 1 IRT Eurocard Type DVS‐4040 5x1 ASI / SDI Switcher Revision History Revision Date Change Description Applicable to: 10/09/2004 Original Issue. S/N: ≥ 0404001 08/03/2011 Link 4 information updated in Configuration section S/N: ≥ 0404001 and SNMP parameter explanation expanded upon.

  • Page 3: Table Of Contents

    DVS‐4040 Instruction Book Revision 1 IRT Eurocard Type DVS‐4040 5x1 ASI / SDI Switcher Instruction Book Table of Contents Section Page Revision History Operational Safety General Description Technical Specifications Configuration Interconnecting modules Switch pulses Power on reset Switcher set‐ups larger than 5x1...

  • Page 4: General Description

    All panels have tally LED’s and switch label inserts. Multiple panels may be used with tally to each panel. The DVS‐4040 is designed to fit IRT’s standard Eurocard frames as well as IRT’s 4000 series frame for use with IRT’s SNMP system and may be used alongside any other of IRT’s analogue or digital Eurocards.

  • Page 5: Technical Specifications

    Plug in 10 pin HE14 dual IDC. Other: Temperature range 0 ‐ 50° C ambient. Mechanical Suitable for mounting in IRT 19" rack chassis with input, output and power connections on the rear panel. Finish: Front panel Grey background, black lettering & red IRT logo.

  • Page 6: Configuration

    Interconnecting modules: The DVS‐4040 control buss can be daisy chained with other types of IRT 3000 and 4000 series switchers, such as analogue video, audio and data switchers, and control panels. Modules are looped by joining PL5 (data out) on one module to PL4 (data in) on the next.

  • Page 7: Switcher Set-Ups Larger Than 5X1

    Connector PL 5 (data out) on switcher 1 ‐ 5 connects to PL 4 (data in) on switcher 6 ‐ 10 and so on. Cables may be wired using the connectors provided or may be ordered from IRT using the following part numbers: GDW‐3010...

  • Page 8: Wire Per Crosspoint Operation

    DVS‐4040 Instruction Book Revision 1 Wire per crosspoint operation In most cases, the BCD encoded remote control system offers the most satisfactory way of controlling one or more switchers. There are however, situations where it is necessary to provide a wire per crosspoint access for control and / or a line per crosspoint tally system.

  • Page 9: Installation

    All switchers are sold with a plain front panel with DC power LED and printed with the switcher type number and IRT logo. The TPS‐3010 provides the necessary components to add tally LED indicators to the front panel. This is desirable when switchers are controlled only by remote connections that are distant from the switcher.

  • Page 10: Smu-4000 Installation

    Note also that an SMU‐4000 will only be functionally operational when the main module that it is plugged into is fitted into an IRT SNMP capable frame fitted with a CDM‐xxxx SNMP agent and being interrogated by a suitable Network Management System.
  • Page 11 DVS‐4040 Instruction Book Revision 1 Front & rear panel connector diagrams The following front panel and rear assembly drawings are not to scale and are intended to show connection order and approximate layout only. Fitted with CPS‐3050 Local Standard Control Panel 5x1 SW D V S-40 40 CP S-30 50...
  • Page 12 It is not the intention here to discuss the differences between various versions, only to bring attention to the fact that IRT Electronics modules, fitted with SNMP capability, use SNMPv1. An SNMP managed network consists of three key components: Network Management Systems (NMS), agents, and managed devices.
  • Page 13 Communication between the NMS, the frame and its loaded modules are via this CDM‐xxxx module. Note that the NMS software is third party and not supplied by IRT Electronics. Ethernet connection for SNMP operation is via an RJ45 connector on the rear of the frame, below the mains inlet.

  • Page 14: Dvs-4040 Snmp Functions

    With the DVS‐4040 fitted with the optional plug‐in SMU‐4000 SNMP module, programmed with firmware to suit, and installed in an IRT frame with SNMP capability, it is possible to remotely monitor the presence of inputs and which input is currently switched to the output, as well as to remotely select desired input to output, using an NMS.

  • Page 15: Equipment Return

    For situations when “No Fault Found” for repairs, a minimum charge of 1 hour’s labour, at IRT’s current labour charge rate, will apply, whether the equipment is within the warranty period or not.
