    IRT 1RU Type DDS-1100 G.703 8x4 Switcher Instruction Book Table of Contents Section Page Operational Safety General Description Technical Specifications Installation Front and rear layouts Operation Front panel control Serial control Maintenance & Storage Warranty & Service Equipment return Drawing List Index This instruction book applies to units later than S/N 0206001.
  • Page 3: General Description

    G.703 8x4 Switcher General Description The DDS-1100 is a broadband 8x4 switcher for use with 2, 8, 34 & 45 Mb/s G.703 compliant signals. Any of the 8 inputs can be switched to any or all of the 4 outputs.
  • Page 4: Technical Specifications

    Power AC IEC 320. Other: Temperature range 0 - 50° C ambient. Mechanical IRT 19" rack chassis with input, remote interface, output and power connections on the rear panel. Finish: Front panel Grey, black lettering & red IRT logo. Rear panel Silk-screened bright passivated steel, silk-screened black lettering.
  • Page 5: Installation

    OUTPUTS A, B, C & D. Front & rear panel connector diagrams The following front panel and rear assembly drawings are not to scale and are intended to show connection order and approximate layout only. DDS-1100 8x4 G.703 SWITCHER SERIAL CONTROL INPUTS...
  • Page 6: Operation

    Operation Front panel control: Press desired OUTPUT A, B, C or D, then press which input that is to be switched to that output. For example, suppose the requirement was for input 1 to go to outputs C and D, input 2 was to go to output B and input 8 was to go to output A.
  • Page 7: Serial Control

    Serial control: Baud rate is 9600, 8 bits of data in each byte, no parity SELECT CROSSPOINT BREAK ADDRESS Must match setting of Address SW WORD COUNT COMMAND $80 Row 1 $81 Row 2 $82 Row 3 $83 Row 4 VALUE 0 to 7 CHECK SUM...
  • Page 8: Maintenance & Storage

    For situations when “No Fault Found” for repairs, a minimum charge of 1 hour’s labour, at IRT’s current labour charge rate, will apply, whether the equipment is within the warranty period or not.
  • Page 9: Drawing List Index

    Drawing # Sheet # Description 804106 DDS-1100 8x4 G.703 Switcher circuit diagram – sheet 1 of 4. 804106 DDS-1100 8x4 G.703 Switcher circuit diagram – sheet 2 of 4. 804106 DDS-1100 8x4 G.703 Switcher circuit diagram – sheet 3 of 4.
