Instruction Manual

HPC Extreme
330 / 405 / 520
03/13
Page 1 of 23

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HPC Extreme 330 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Unitor HPC Extreme 330

Summary of Contents for Unitor HPC Extreme 330

  • Page 1: Instruction Manual

    Instruction Manual HPC Extreme 330 / 405 / 520 03/13 Page 1 of 23...
  • Page 2 Page 2 of 23...

  • Page 3: Table Of Contents

    Contents Introduction Page Page 5 – 6 Safety Instructions Page 7 – 10 Configuration/Operation/Illustrations Page 11 – 16 Start-up/Operation/Shut-down Page 17 – 18 Maintenance and Care Electric Wiring Diagram Page Technical Data Page Trouble Shooting Page Declaration of Conformity Page Page 3 of 23...

  • Page 4: Introduction

    Introduction Congratulations - you have purchased one of the most durable and reliable high pressure cleaners available on the market. Its balanced ratio of water flow and working pressure perfectly meets all cleaning requirements. The high pressure cleaner conforms to all European safety regulations which is guaranteed by the CE symbol.

  • Page 5: Safety Instructions

    Safety Instructions The following instructions to be followed before, during and after work: This instruction manual to be read completely before initial start-up. If strictly followed, no danger should occur. This machine must only be run by qualified adult persons who are fully familiar with possible dangers.
  • Page 6 Before opening the machine in case of malfunction or emergency, switch off by means of the ON/OFF switch and disconnect it from electric power source. Electric power can cause severe injuries or death. All symptoms of faulty electric components to be taken seriously and possible causes for accidents to be eliminated immediately.

  • Page 7: Configuration/Operation/Illustrations

    The range of applications can be extended by a variety of accessories available. Contact your local UNITOR representative. Page 7 of 23...
  • Page 8 Page 8 of 23...
  • Page 9 Page 9 of 23...
  • Page 10 Page 10 of 23...

  • Page 11: Start-Up/Operation/Shut-Down

    Start-up / Shut-down Before Start-up: Read and observe operation manual. In order to guarantee proper function and trouble-free operation, the following checks to be carried out before start-up: Check electricity supply with electric data on type shield. If voltage deviates by more than 10 %, there is a risk of damage due to overheating.
  • Page 12 Connections Water Supply Connect water inlet (6) of the machine to water source with a clean hose (diameter see table below). Before connecting water supply hose, rinse out thoroughly. In case of connection to the potable water distribution, observe DIN 1988 (for momentary connections use a backflow preventer with non- return function and ventilation).
  • Page 13 Operation HPC Extreme 330 This machine is equipped with an EMERGENCY STOP switch. In case of emergency push EMERGENCY STOP (2a). Before starting the machine EMERGENCY STOP switch (2a) to be unlocked by slightly turning it clockwise. Fully open water source.
  • Page 14 Particularly note: In case of malfunctions, eliminate cause according to chapter „Trouble Shooting“, call qualified service. In case frost is likely, frost protection to be carried out (see chapter „Maintenance and Care“), otherwise severe damage will result. Page 14 of 23...
  • Page 15 Operation HPC Extreme 405 / 520 These machines are equipped with an EMERGENCY STOP switch. In case of emergency push EMERGENCY STOP (2a). Before starting the machine EMERGENCY STOP switch (2a) to be unlocked by slightly turning it clockwise. Fully open water source. Unlock/release spray pistol, bleed unit.
  • Page 16 Particularly note: In case of malfunctions, eliminate cause according to chapter „Trouble Shooting“, call qualified service. In case frost is likely, frost protection to be carried out (see chapter „Maintenance and Care“), otherwise severe damage will result. Page 16 of 23...

  • Page 17: Maintenance And Care

    Maintenance and Care Every machine is only as reliable as maintenance is carried out. The manufacturer offers maintenance agreements for every machine comprising the yearly safety inspection. Contact your local distributor for more information. The machine to be inspected every year by qualified personnel, in order to guarantee trouble-free and safe operation.
  • Page 18 Cartridge Filter (micro filter 25/50 µm) Upstreams of the high pressure pump there is a cartridge filter (5) installed. The filter cartridge to be replaced whenever required. Frost Protection Frost protection of the entire water system during storage and transport is a must, as otherwise heavy damage on the system and severe dangers during operation may occur.

  • Page 19: Electric Wiring Diagram

    Electric Wiring Diagrams Model HPCExtreme 330 / 405 / 520 400 Volt / 3~50 Hz 440 Volt / 3~60 Hz Page 19 of 23...

  • Page 20: Technical Data

    Technical Data Technical Data HPCExtreme 330 HPCExtreme 405 HPCExtreme 520 Water flow 1320 l/h 1320 l/h 1020 l/h Unloading pressure 330 bar 405 bar 550 bar 150 – 500 bar Working pressure adjustable max. 310 bar 385 bar Power supply 400 V / 3 ~ 50 Hz 400 V / 3 ~ 50 Hz 400 V / 3 ~ 50 Hz...

  • Page 21: Trouble Shooting

    Trouble Shooting Electric power can cause severe injuries or death. Defective electrical components to be immediately replaced, possible causes for accidents to be eliminated without delay. Any repair work must only be carried out by qualified personnel. Only original equipment delivered, respectively expressively approved by the manufacturer to be installed, as otherwise warranty and Declaration of Conformity will expire, health and safety standards are not guaranteed.
  • Page 22 Geräteart: Unbeheizter Hochdruckreiniger > 250 bar Description: Cold water high pressure cleaner > 250 bar Gerätetyp: HPCExtreme (Elektromotor/electric motor 3~400 V/ 50/60 Hz) Model 330 / 405 / 520 310 / 385 / 500 bar Seriennr.: Serial No.: 2006/42EG ● 2006/95EG ● 2004/108EG ● 2002/44EG ● 2000/14EG ● 97/23EG Folgende harmonisierte Normen wurden angewandt / applied harmonized standards EN 1829, EN 12100-1/2, EN 55014-1/2, EN 61000-3-2, EN 60704-1 Der Unterzeichnende ist bevollmächtigt, die technischen Unterlagen zusammenzustellen.
  • Page 23 Fraser/surrey Gaspe Gros Caouna Halifax Hamilton Harbour Grace Holyrood Kitimat Long Pond Marytown Montreal Nanaimo New Westminster Bc Pictou/halifax Pointe Aux Pic.quebec Port Alfred Port Cartier Port Colborne Port Hawkesbury Port Mellon Port Moody Port Of Quebec Port Weller Powell River Prince Rupert Roberts Bank Saint John Sarnia, Ontario Sept Iles Seven Islands Sorel Souris/ halifax Squamish St.
