- Page 1 REMOTE ENGINE STARTER SYSTEM FOR MANUAL OR AUTOMATIC VEHICLES INSTALLATION MANUAL...
-
Page 2: Wiring Description
WIRING DESCRIPTION 6 WIRE CONNECTOR (14 GAUGE WIRE) 12V constant wire (12V positive input) connect to a 12V constant, 30A fuse built-in 12V constant wire (12V positive input) connect to a 12V constant, 30A fuse built-in GREEN Auxiliary 12V positive output for 2 ignition, 2 accessory, 2 starter, 20A fuse built-in (see option # 5) - Page 3 WIRING DESCRIPTION 20 WIRES CONNECTOR (20 GAUGE WIRE) OUTPUT# 4: 500mA negative output for trunk opener GREEN / BLACK PURPLE TACH wire (AC input) connect to TACH signal wire (coil or injector or alternator DC voltage) GREEN / YELLOW Negative parking light 500mA WHITE / GREEN Unlock wire (500mA negative output) See central door lock connection diagram WHITE / RED...
-
Page 4: Wiring Diagram
WIRING DIAGRAM... -
Page 5: Central Door Lock Connection
CENTRAL DOOR LOCK CONNECTION DIAGRAM 1: REVERSE POLARITY TYPE DIAGRAM 2: NEGATIVE TYPE DIAGRAM 3: ADDING DOOR LOCK ACTUATOR... - Page 6 PROGRAMMING Our remote starter is delivered with factory default settings. You can install it without programming or you can modify the configuration to suit your customer’s need. Important: the installation must be completed before accessing programming mode. Programming the system: 1.
-
Page 7: Programming Chart
PROGRAMMING CHART OPTION FUNCTION PRESS BUTTON TO: PRESS BUTTON TO: PRESS BUTTON TO: TACH Learning Learn See example: #3 TACH fine tuning Increase Decrease See example # 4 ♦ Normal Cranking adjustment Slight increase Increase ♦ Audible Arming/Disarming Enable Disable ♦15 minutes Running time Duration 10 minutes... - Page 8 PROGRAMMING CHART ♦ Horn Horn/Siren Siren ♦ Disable Dome light delay Enable & Doors Bypass for 45 seconds when engine shut-off ♦ Normal Fast Unlock (2 way only) Fast Unlock ♦ Normal Door Lock/Unlock Unlock before start Lock only after remote configuration Lock after start start shut down...
-
Page 9: Programming Options
PROGRAMMING OPTIONS OPTION 1A: TACH LEARNING ( SEE EXAMPLE #3 ) The factory default setting should normally adapt to most vehicles on the market. After the installation is completed, start engine with transmitter and most of the time you will have a perfect start. If the starter motor is over crank or release too fast, you must process with the TACH learning option or manual fine-tuning. - Page 10 PROGRAMMING OPTIONS OPTION 6: GLOW PLUG WAITING TIME ( FOR DIESEL ENGINE ) Diesel engines need to warm up glow plugs before starting. Turn ignition key ON and count how many seconds it takes for the glow plug light to turn OFF then select the closest waiting time. OPTION 7:OUTPUT # 5 Starter kill 2.
- Page 11 PROGRAMMING OPTIONS OPTION 11: IGNITION LOCK This feature allows the system to lock all doors when ignition key is ON. By depressing the brake pedal, all doors will unlock automatically when ignition key is OFF. OPTION 12: PASSIVE LOCK Passive lock works only when passive arming option is enable (see option #13). Passive lock allows the system to lock all doors when armed.
- Page 12 PROGRAMMING OPTIONS OPTION 16: DOME LIGHT DELAY If the vehicle comes with dome light delay, it is important to enable this option. Otherwise, the start sequence for manual transmission only may be lost. Note: When dome light delay mode is selected, the parking lights will flash 3 times when arms the system.
-
Page 13: Programming Examples
PROGRAMMING EXAMPLES EXAMPLE 1, OPTION 13: CHANGE FROM PASSIVE ARMING TO ACTIVE ARMING Option 13, default setting is passive arming. System will arm automatically after ignition key is OFF for 30 seconds delay. You want to change to active arming. 1. - Page 14 PROGRAMMING EXAMPLES EXAMPLE 2, OPTION 20: TRANSMITTER CODE LEARNING The transmitter supplied is already programmed to the system. This option allows you to add more transmitters to your system if needed. 1. Access programming mode (see programming procedure). 2. Press and release program button 20 times and count 20 beeps. 3.
- Page 15 PROGRAMMING EXAMPLES EXAMPLE 4, OPTION 1B: FINE TUNING THE TACH SIGNAL Even with the factory TACH default setting or TACH learning features you can not reach the exact setting; example: idle is too high. This option will allow you to fine tune the TACH signal manually; make sure the engine is not running. 1.
- Page 16 PROGRAMMING EXAMPLES EXAMPLE 5, OPTION 19: REINITIALIZE TO FACTORY DEFAULT SETTING In case of confusion or you want to install the system in another vehicle and you don’t want to keep the old settings. The option 19 allows resetting of the system back to factory default setting. 1.
- Page 17 REMOTE ENGINE STARTER DIAGNOSTIC DIAGNOSTIC FOR REMOTE STARTER: Each time you try to remote start the vehicle and it doesn’t start, the parking lights will flash to indicate the reason why. 1 Flash: Brake pedal depressed 2 Flashes: Valet mode ON 3 Flashes: Hood opened 4 Flashes:...
-
Page 18: Limited Warranty
LIMITED WARRANTY The manufacturer guarantees to the purchaser of origin the remote starter and alarm to be free of defect material and labour. However, if it is proven that the product is defective, inside the two year period as from the original date of purchase, the manufacturer will repair or replace, without expenses towards the purchaser, any part (excluding any expenses incurred to deliver the product to the manufacturer) remote starter or alarm which the manufacturer considers defective.
