- Page 1 FEATURES AND OPERATIONS TWO WAY FM COMMUNICATION REMOTE STARTER & SECURITY SYSTEM PL-6000-TW-FM Series OWNER'S MANUEL...
-
Page 2: Transmitter Operations
TRANSMITTER OPERATIONS ONE WAY TWO WAY LCD FM TRANSMITTERS FOR FM TRANSMITTER FOR PL-6000 SERIES PL-6000 SERIES SLIDE 1 WAY FM 2 WAY LCD FM FONCTIONS TRANSMITTER TRANSMITTER Bt 1 ARM & LOCK THE DOORS (Silent mode) ARM & LOCK THE DOORS (Audible mode) Bt 1, Bt 1 Bt 1 (2 sec.) PANIC MODE... - Page 3 TRANSMITTER OPERATIONS 2 WAY LCD FM TRANSMITTER Bt 2: TEMPERATURE CHECK (optional) THEN Bt 3: ENGINE START TIMER ACTIVATION THEN Bt 2: OUTPUT # 3 ACTIVATION (pink) THEN Bt 1: OUTPUT # 5 ACTIVATION (orange) THEN Bt 1 et Bt 3 (2 sec OR 2 VEHICLE SELECTION AT THE SAME TIME...
- Page 4 TWO WAY LCD TRANSMITTER OPERATIONS...
- Page 5 TWO WAY LCD TRANSMITTER OPERATIONS Adjust real time clock Keep pressing "F" button until appear then release. The display will show the hour numbers flashing. Use "3" button to select the hour, minutes or Am/Pm. Then use the "1" button to increase or the "2" button to decrease time. When it is done, press "F"...
- Page 6 TWO WAY LCD TRANSMITTER OPERATIONS Enable wake-up timer Keep pressing "M" button until appear then release. Then use the "1" button or the "2" button to enable/disable this option. The "wake-up timer" icon will turn ON if it is enable. Transmitter ON / OFF If you want to turn the transmitter off, keep pressing "1"...
- Page 7 TRANSMITTER OPERATIONS PAGING SIGNALS TO TRANSMITTER: 1 Hi/Lo beep Automatic arming or security rearm engaged 3 Long beeps Engine stops running via remote or engine running time has expired Alarm has been triggered while you were away 5 Hi/Lo beeps 15 Long beeps Alarm in progress 1 Cricket sound...
-
Page 8: Features And Operations
FEATURES AND OPERATIONS ARMING: Arming the system will also enable the starter kill and lock the doors, if installed. You can select silent or audible arming by programming option #3. If you try to arm the system and you hear 3, 4 or 5 beeps, one of the protected zones is opened. The system will ignore the defective zone and force the system to arm. - Page 9 FEATURES AND OPERATIONS PANIC MODE: With engine not running, keep pressing "1" or button for 2 seconds: panic mode is engaged. The horn or siren will be triggered. To stop the panic mode simply press "1" or button. VALET MODE: To disarm the system in case of transmitter loss or for vehicle servicing, you must perform the sequence twice to enable the valet mode.
- Page 10 FEATURES AND OPERATIONS IGNITION LOCK: Doors locks automatically when ignition is ON and brake pedal is depressed. Doors will unlock when ignition is turned OFF (ask your dealer for this feature). SHOCK SENSOR PRE-WARNING: Siren/Horn chirps rapidly when shock sensor is triggered. If shock sensor is triggered for a second time within 10 seconds, the siren/horn sounds for 30, 60 or 120 seconds (depending on the programming).
- Page 11 FEATURES AND OPERATIONS KEYLESS RUNNING MODE: FOR AUTOMATIC TRANSMISSION: 1. You are seated in the vehicle, engine running with the ignition key, make sure the hood is closed and that the toggle valet switch is in the OFF position and that the doors and windows are closed. 1.
-
Page 12: Limited Warranty
LIMITED WARRANTY The manufacturer guarantees to the purchaser of origin the remote starter and alarm to be free of defect material and labour. However, if it is proven that the product is defective, inside the two year period as from the original date of purchase, the manufacturer will repair or replace, without expenses towards the purchaser, any part (excluding any expenses incurred to deliver the product to the manufacturer) remote starter or alarm which the manufacturer considers defective.
