Model:
LBX15-EX27
Congratulations on owning a Scag Giant-Vac blower! This manual contains the
operating instructions and safety information for your Scag Giant-Vac blower.
Reading this manual can provide you with assistance in maintenance and
adjustment procedures to keep your blower performing to maximum efficiency.
The specific models that this book covers are listed on the inside cover. Before
operating your blower, please read all the information enclosed.
© 2013
Scag Giant-Vac
Division of Metalcraft of Mayville, Inc.
OPERATOR'S
MANUAL
PART NO. 03348
PRINTED 7/2013
PRINTED IN USA
Advertisement
Table of Contents
Related Manuals for Scag Power Equipment Giant-Vac LBX15-EX27
Summary of Contents for Scag Power Equipment Giant-Vac LBX15-EX27
- Page 1 Leaf Blower Model: LBX15-EX27 Congratulations on owning a Scag Giant-Vac blower! This manual contains the operating instructions and safety information for your Scag Giant-Vac blower. Reading this manual can provide you with assistance in maintenance and adjustment procedures to keep your blower performing to maximum efficiency.
- Page 2 CONCERN, PRUDENCE, AND PROPER TRAINING OF THE PERSONNEL INvOLvED IN THE OPERATION, TRANSPORT, MAINTENANCE, AND STORAGE OF THE EqUIPMENT. This manual covers the operating instructions and illustrated parts list for: LBX15-EX27 with a serial number of 002A00001 to 002A99999 Always use the entire serial number listed on the serial number tag when referring to this product.
-
Page 3: Table Of Contents
Table of Contents Table of Contents SECTION 1 - GENERAL INFORMATION ...................1 1.1 INTRODUCTION ............................1 1.2 DIRECTION REFERENCE ...........................1 1.3 SERvICING THE ENGINE AND DRIvE TRAIN COMPONENTS ..............1 1.4 SYMBOLS ..............................2 SECTION 2 - SAFETY INFORMATION ..................3 2.1 INTRODUCTION ............................3 2.2 SIGNAL WORDS ............................3 2.3 BEFORE OPERATION CONSIDERATIONS ....................3 2.4 OPERATION CONSIDERATIONS ........................4... - Page 4 5.4 ENGINE AIR CLEANER ..........................13 5.5 TIRES ................................13 SECTION 6 - ILLUSTRATED PARTS LIST ................14 6.1 SCAG GIANT-vAC APPROvED ATTACHMENTS AND ACCESSORIES..........14 NOTES ................................15 EXTREME BLOWER ASSEMBLY ........................16 EXTREME BLOWER ASSEMBLY ........................17 EXTREME BLOWER DECALS ........................18 LIMITED WARRANTY - EXTREME LEAF BLOWER ......Inside Back Cover...
-
Page 5: General Information
They carry a full line of Scag Giant-Vac service parts. DIRECTION REFERENCE - IMPORTANT - The “Right”... -
Page 6: Symbols
Section 1 SYMBOLS SYMBOL DESCRIPTION SYMBOL DESCRIPTION Choke Transmission On/Start Spring Tension on Idler Off/Stop Spinning Fan Blades Thrown Object Hazard Fast Slow Continuously Variable - Linear Pinch Point 481039S Keep Bystanders Away Read Operator's Manual... -
Page 7: Safety Information
The signal word “CAUTION” is a reminder of safety make your request. Please indicate the complete model practices on or near the machine that could result in and serial number of your Scag Giant-Vac product when personal injury if proper precautions are not taken. requesting replacement manuals. -
Page 8: Operation Considerations
Section 2 DO NOT wear loose fitting clothing. Loose clothing, OPERATION CONSIDERATIONS jewelry or long hair could get tangled in moving parts. Do not operate the machine wearing shorts; Know the function of all controls and how to stop always wear adequate protective clothing including quickly. -
Page 9: Maintenance Considerations & Storage
Section 2 Use only in daylight or good artificial light. Do not straighten or weld the blower fan. Replace damaged or failed blower fans. Do not leave the machine unattended. Disconnect spark plug wire to prevent accidental The machine and attachments should be stopped starting of the engine when servicing or adjusting and inspected for damage after striking a foreign the machine. -
Page 10: Safety And Instructional Decals
Section 2 SAFETY AND INSTRUCTIONAL DECALS 484983 485073... -
Page 11: Specifications
ENGINE General Type ....................Heavy Duty Industrial/Commercial Gasoline Brand ..................................Subaru Engine Model: (Scag Giant-Vac Model LBX9152S) ..................Subaru Model # EX27 Displacement: Subaru EX27 ..............................265cc Cylinders ............................1 with Cast-Iron Sleeve Governor ..........Centrifugal Flywheel Type Set to 3,600 RPM at maximum load (+/- 100 RPM) Idle Speed: Subaru .......................... - Page 12 Section 3...
-
Page 13: Operating Instructions
Section 4 OPERATING INSTRUCTIONS Engine Throttle Control (Figure 4-1). Used to CAUTION control the engine speed. Pushing the lever forward increases engine speed. Pulling the lever back decreases engine speed. Full back position is the Do not attempt to operate this blower unless you IDLE position. -
Page 14: Starting The Engine
Section 4 STARTING THE ENGINE PARkING THE BLOWER Park the machine on a flat, level surface only. Do not CAUTION park the machine on an incline. Slow the engine to idle speed. Turn the ignition switch to the OFF position. DO NOT USE STARTING FLUIDS. -
Page 15: Removing Clogged Material
Section 4 REMOvING CLOGGED MATERIAL DANGER ROTATING FAN BLADES NEvER PUT YOUR HANDS INTO THE AIR INTAkE OR OUTLET FOR ANY REASON! Shut off the engine, remove the spark plug wire and only then use a stick or similar object to remove material if clogging has occurred. -
Page 16: Maintenance
Section 5 MAINTENANCE MAINTENANCE CHART - RECOMMENDED SERvICE INTERvALS HOURS PROCEDURE COMMENTS BREAk-IN 100 200 500 (FIRST 10) Check all hardware for tightness S e e e n g i n e o p e r a t o r ' s Check engine oil level manual *Clean blower... -
Page 17: Engine Oil
Section 5 ENGINE OIL Never remove the gas cap or add fuel with the engine running. Allow the engine to completely cool before fueling. A. CHECkING ENGINE CRANkCASE OIL LEvEL Never fuel the machine indoors or in an enclosed trailer. The engine oil level should be checked after every 8 hours of operation or daily as instructed in the Engine Operator’s Never store the machine or fuel container where... -
Page 18: Illustrated Parts List
Section 6 ILLUSTRATED PARTS LIST SCAG GIANT-vAC APPROvED ATTACHMENTS AND ACCESSORIES. Attachments and accessories manufactured by companies other than Scag Giant-Vac are not approved for use on this machine. -
Page 19: Notes
Section 6 NOTES... -
Page 20: Extreme Blower Assembly
Section 6 EXTREME BLOWER ASSEMBLY... -
Page 21: Extreme Blower Assembly
Impeller Weldment, 15" Extreme -LBX 04017-52 Bolt, Hex Head Serrated Flange 5/16-24 x 3/4" 462630 Housing Weldment, Extreme w/Decals 04001-11 Bolt, Hex Head 5/16-18 x 1-1/2" 04040-15 Flatwasher, 5/16-.375 x .875 x .083 484952 Engine, Subaru EX27 (not available through Scag Giant-Vac) -
Page 22: Extreme Blower Decals
Section 6 EXTREME BLOWER DECALS 485073 485045 484983 485088 484984 - Black 485047 - Red... - Page 23 Giant-Vac Service Dealer within the warranty period. The expense of delivering the blower to the dealer for warranty work and the expense of returning it to the owner after repair will be paid for by the owner. Scag Giant-Vac’s responsibility is limited to making the required repairs and no claim of breach of warranty shall be cause for cancellation or rescission of the contract of sale of any Scag Giant-Vac product.
