Service Manual 2610/2626 Level 1&2
SERVICE MANUAL
Level 1&2
RH-86/87
PAGE 1 (20)
Confidential
Transceiver characteristics:
•
Band: Dual-band phone for GSM
•
•
•
Display: High resolution color display with up to
65,536 colors (128 x 128 Pixels)
•
Connector: Easy Flash connector
Transceiver with BL-5c Li-Ion battery pack
Talk time
Up to 5h
Environmental characteristics:
•
Lead-free soldered
Copyright © 2005-2007 NOKIA Corporation. All rights reserved.
Approved 2.0
30.Jan.2007
RM-291
RH-86/RM-291: 900/1800MHz
RH-87: 850/1900MHz
Standby
Note
Depends on
Up to 12,5days
network
parameters
MGR

Advertisement

Table of Contents
loading

Related Manuals for Nokia 2626

Summary of Contents for Nokia 2626

  • Page 1 Connector: Easy Flash connector Transceiver with BL-5c Li-Ion battery pack Talk time Standby Note Depends on Up to 5h Up to 12,5days network parameters Environmental characteristics: • Lead-free soldered Service Manual 2610/2626 Level 1&2 Copyright © 2005-2007 NOKIA Corporation. All rights reserved.

  • Page 2: Table Of Contents

    Version No. Date Comments Draft 11.Apr.2006 Initial draft Approved 24.Mai.2006 Approval Approved 30.Jan.2007 2626 added; Exploded view/Spare Parts overview updated; General Recycling recommendation/ Level 2 solder Components added Service Manual 2610/2626 Level 1&2 Copyright © 2005-2007 NOKIA Corporation. All rights reserved.

  • Page 3: Introduction

    1. INTRODUCTION The purpose of this document is to help NOKIA service levels 1 and 2 workshop technicians to carry out service to NOKIA products. This Service Manual is to be used only by authorized NOKIA service suppliers, and the content of it confidential.

  • Page 4: General Repair Information

    4. Spare Part Service Bulletins 5. Service Tools Service Bulletins 6. Common Software Service Bulletins etc,… Please also check NOKIA Online (NOL) for latest news and files on a regular basis. Service Manual 2610/2626 Level 1&2 Copyright © 2005-2007 NOKIA Corporation. All rights reserved.

  • Page 5: Pathfinder For Workshop Staff

    Videos – Disassembly/Assembly NOKIA Online Care Services Training Phone Models Level 1&2 e-learning courses offer a quick overview of the NOKIA phone and support for how to repair and use the phone: Overview & Guides Disassembly & Assembly Troubleshooting Basic information about the...

  • Page 6: Exploded View And Component Disposal

    4. EXPLODED VIEW AND COMPONENT DISPOSAL Recommendation for the ecologically friendly disposal of components. Colorized components show the different categories. See corresponding ITEM/CIRCUIT REF in the Spare Parts Service Bulletins on NOL. Service Manual 2610/2626 Level 1&2 Copyright © 2005-2007 NOKIA Corporation. All rights reserved.

  • Page 7: Spare Parts Overview

    PAGE 7 (20) Approved 2.0 CMO Operations & Logistics TRAINING & VENDOR Development MULTIMEDIA CREATION & SUPPORT Confidential 30.Jan.2007 5. SPARE PARTS OVERVIEW Service Manual 2610/2626 Level 1&2 Copyright © 2005-2007 NOKIA Corporation. All rights reserved.

  • Page 8: General Recycling Recommendation

    PAGE 8 (20) Approved 2.0 CMO Operations & Logistics TRAINING & VENDOR Development MULTIMEDIA CREATION & SUPPORT Confidential 30.Jan.2007 6. GENERAL RECYCLING RECOMMENDATION Service Manual 2610/2626 Level 1&2 Copyright © 2005-2007 NOKIA Corporation. All rights reserved.

  • Page 9: Level 2 Solder Components

    PAGE 9 (20) Approved 2.0 CMO Operations & Logistics TRAINING & VENDOR Development MULTIMEDIA CREATION & SUPPORT Confidential 30.Jan.2007 7. LEVEL 2 SOLDER COMPONENTS Service Manual 2610/2626 Level 1&2 Copyright © 2005-2007 NOKIA Corporation. All rights reserved.

  • Page 10: Spare Parts List

    Bulletins (spare parts, SWAP units and service tools) from NOL! This will ensure, that you are using up-to-date order codes only. Therefore Service Bulletins have to be checked from NOL on daily basis. Service Manual 2610/2626 Level 1&2 Copyright © 2005-2007 NOKIA Corporation. All rights reserved.

  • Page 11: Service Tools

    It provides controlled supply voltage and necessary connections between the phone and the Flash Device. It substitutes for the phone’s standard battery during the software update. Service Manual 2610/2626 Level 1&2 Copyright © 2005-2007 NOKIA Corporation. All rights reserved.
  • Page 12 Wetec tweezers 22 SA-ESD Wetec tweezers 13 SA-SMD ESD Wetec tweezers PSF SA-ESD Wetec ESD brush E1211 Kaiser Fototechnik airbrush 6315 Wetec dental tool DEM83266/0 Components Scissors 323-5732 Service Manual 2610/2626 Level 1&2 Copyright © 2005-2007 NOKIA Corporation. All rights reserved.

  • Page 13: Sw-Update

    Now, push down the bottom side of the phone, do not Battery Connector side. use too much force. When removing the phone, always start from the bottom Now, take the unit away. side of the unit. Service Manual 2610/2626 Level 1&2 Copyright © 2005-2007 NOKIA Corporation. All rights reserved.

  • Page 14: Disassembly Instructions

    For assembly, use the reverse order and Module with a clean cloth carefully. a Torx Plus size 6 driver with a torque setting of ® 24Ncm. Service Manual 2610/2626 Level 1&2 Copyright © 2005-2007 NOKIA Corporation. All rights reserved.
  • Page 15 Take care to the flex foil of the LCD Module. 16.) Lift the Engine Module a bit with the SRT-6 and 15.) Remove the Light Guide Assy. remove it from the D-Cover Assy. Service Manual 2610/2626 Level 1&2 Copyright © 2005-2007 NOKIA Corporation. All rights reserved.
  • Page 16 18.) Press out the Easy Flash Connector by using the 17.) The Antenna IHF Assy drops out when turning DC-plug. the D-Cover Assy. 19.) Remove the Microphone with the slotted screwdriver. Service Manual 2610/2626 Level 1&2 Copyright © 2005-2007 NOKIA Corporation. All rights reserved.

  • Page 17: Legend For Quick Trouble Shooter

    Pads or contacts: Check optical and mechanical condition particularly regarding to corrosion. Clean with ESD brush only, if necessary. No more actions possible send product to the appropriate service supplier with higher service level. Service Manual 2610/2626 Level 1&2 Copyright © 2005-2007 NOKIA Corporation. All rights reserved.

  • Page 18: Quick Trouble Shooter Part 1

    PAGE 18 (20) Approved 2.0 CMO Operations & Logistics TRAINING & VENDOR Development MULTIMEDIA CREATION & SUPPORT Confidential 30.Jan.2007 13. QUICK TROUBLE SHOOTER PART 1 Service Manual 2610/2626 Level 1&2 Copyright © 2005-2007 NOKIA Corporation. All rights reserved.

  • Page 19: Quick Trouble Shooter Part 2

    PAGE 19 (20) Approved 2.0 CMO Operations & Logistics TRAINING & VENDOR Development MULTIMEDIA CREATION & SUPPORT Confidential 30.Jan.2007 14. QUICK TROUBLE SHOOTER PART 2 Service Manual 2610/2626 Level 1&2 Copyright © 2005-2007 NOKIA Corporation. All rights reserved.

  • Page 20: Battery Test

    TRAINING & VENDOR Development MULTIMEDIA CREATION & SUPPORT Confidential 30.Jan.2007 15. BATTERY TEST A battery tester lets you test the capacity of NOKIA batteries. Please refer to the actual information on NOKIA Online. http://www.cadex.com/ http://www.astratec.co.uk/ Service Manual 2610/2626 Level 1&2...
