Approach Compact Dimensional Data Table
MODEL
Base Vehicle Manufacturer
Chassis
Base Vehicle Model
Wheel Base Length
Overall Length
Overall Width (mirrors extended)
Overall width (mirrors folded)
Overall Height
Double Bed Transverse
Drop Down Bed (Where fitted)
Fixed Bed (Where Fitted)
Front Transverse bed
Rear N/S Single
Rear O/S Single
Fresh Water Tank Capacity (Litres)
Waste Water Tank Capacity (Litres)
Gas Butane (Depending
Manufacturer)
Gas Propane (Depending
Manufacturer)
Compact 520 Compact 540
Peugeot Peugeot
AL-KO AMC AL-KO AMC
335 335
3731 mm 3731 mm
2770 mm 2770 mm
5999 mm 5999mm
2785 mm 2785 mm
1950x1540 mm
2020 x 1370 mm
90 Litre
90 Litre
on 2 x 10 Kg 2 x 10 Kg
on 2 x 10 Kg 2 x 10 Kg
