- Page 1 GW9014 TeleHealth Gateway 311-9014000-002 Version 1.0 2010/08...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION TO THE SYSTEM Contents of the System Appearance and Key Functions of the Gateway QUICK INSTALLATION STEPS GW9014A GW9014B LED INDICATION AND TRANSMISSION NOTES ABOUT INSTALLATION LOCATION PROBLEM SOLVING GUIDE SPECIFICATIONS SYMBOL INFORMATION... -
Page 3: Introduction To The System
Please read this instruction manual thoroughly before using this device to ensure safe and accurate use. The FORA GW9014 Gateway works as data receiver and transmitter which helps users or their healthcare providers to manage the data eas- ily and remotely. By using this product, healthcare providers can moni- and analyze your test results remotely and effectively through the connection to the server. -
Page 4: Contents Of The System
Contents of the System Before using FORA GW9014 Gateway, please make sure that you have all the contents listed. For GW9014A, your system includes: Quick Start User Guide FORA GW9014A Gateway Owner’s Manual Quick Start User Guide ... -
Page 5: Appearance And Key Functions Of The Gateway
Appearance and Key Functions of the Gateway Front View Port Area Led Indicators Panel About LED Indicators PWR: The status of power supply. Green light will turn solid green if the power supply is stable. The gateway now is ready for transmis- sion. - Page 6 Bottom View Meter Label For configuration use (Please do NOT open if you are general users) Back View (GW9014A) Power Network Cable Port AC Power Adapter Port RS232 Port Telephone Line Port Back View (GW9014B) ...
-
Page 7: Quick Installation Steps
Service), and make sure that it can work properly. For the settings of internet router, please refer to your service carrier's owner manual. 2. Open FORA GW9014 Gateway kit and take out the contents. 3. Plug power adapter into a power outlet and power adapter port on the gateway. - Page 8 Data Transmission through Telephone Line (FORA GW9014A Gateway contains built-in ISP dial-up service.) 1. Open FORA GW9014 Gateway kit and take out the contents. 2. Plug power adapter into a power outlet and power adapter port on the gateway. 3. Connect RS232 interface cable to RS232 port on the gateway.
-
Page 9: Gw9014B
Service), and make sure that it can work properly. For the settings of internet router, please refer to your service carrier's owner manual. 2. Open FORA GW9014 Gateway kit and take out the contents. 3. Plug power adapter into a power outlet and power adapter port on the gateway. - Page 10 Data Transmission through Telephone Line (FORA GW9014B Gateway contains built-in ISP dial-up service.) 1. Open FORA GW9014 Gateway kit and take out the contents. 2. Plug power adapter into a power outlet and power adapter port on the gateway. 3. Securely insert telephone line into one of the telephone line port on the gateway.
-
Page 11: Led Indication And Transmission
LED INDICATION AND TRANSMISSION You can refer to the following information to know the status of your FORA GW9014 Gateway. LED Indicators Gateway Status Note After gateway turns on, a Ready for use green PWR indicates that the gateway is ready. -
Page 12: Notes About Installation Location
NOTES ABOUT INSTALLATION LOCATION CAUTION! • For safety reason and to obtain the best wireless transmission ef- ficiency, place the Gateway in a wide open area. • To avoid the transmission interference, do NOT place the gateway in the following environments: ■... -
Page 13: Problem Solving Guide
PROBLEM SOLVING GUIDE When the Gateway is connected PWR/NET/WSN LED indicators will be lit. The NET indicator will blink per 10 to 20 seconds during transmission. The gateway will signal two short beeps when data transmission is complete. The table listed below is the descriptions of light signals of LED indicators. - Page 14 If you cannot perform a normal transmission and a red ERR LED indicator is lit, or the gateway sounds long beeps, please check if all the installations are correct. Status Possible Cause Problem Solving Suggestion No LED No power supply to the ●...
-
Page 15: Specifications
SPECIFICATIONS Model no. GW9014A Input Interface RS232 Output Interface ISP dial-up service or Ethernet Dimension 170mm x 120mm x 30mm Weight 221.8g AC power adapter (input: 100-240Vac; output: Power 6V, 1A) Operation 10°C-40°C, below 90% R.H. (Non- Environment condensing) Storage -20°C-65°C, below 90% R.H. -
Page 16: Symbol Information
SYMBOL INFORMATION Symbol Referent Consult instructions for use Do not use if package is damaged Manufacturer Serial number Caution, consult accompanying documents CE Mark Class II Equipment...
