3.6 Status Bars

The bottom field on all display pages consists of the status bar, which displays the device's
operating status, the current IP address, and the current date and time. "OK" means that the
device is operating normally. A 16-bit error code will be displayed in the form of a hex number if
there happens to be a malfunction.
This following table is the display on the status bar which each error occur separately.
Error code
Bit-0 DC over voltage
Bit-1 DC under voltage
Bit-2 hardware error
Inverter over voltage
Bit-3
Bit-4 Frequency over
Bit-5 Frequency under
Bit-6 AC voltage RMS over
Bit-7 AC voltage RMS under
Bit-8 Peak AC voltage over
Bit-9 AC current RMS over
Bit-10 Peak AC current over
Bit-11 Temperature over
Bit-12 ADC error
Bit-13 GFDI fault indicator
Bit-14 Relay error (for some model)
Bit-15 PLC Communication Error
10
Error MRG Display
0x0001
0x0002
0x0004
0x0008
0x0010
0x0020
0x0040
0x0080
0x0100
0x0200
0x0400
0x0800
0x1000
0x2000
0x4000
0x8000

3.7 Other Important Items and Procedures

If an IP address must be obtained automatically using DHCP, first insert the network cable and
select "DHCP" on the Ethernet settings page (this works only when there is a DHCP server on the
network). After confirming the changes, restart the device; if successful, the IP address that has
been automatically obtained will be displayed in the status bar.
If you wish to use a USB keyboard for input, plug the keyboard's USB cable into the device's USB
port, then restart the device. The device will automatically recognize the keyboard and allow it to
input data. If a keyboard is inserted but the device is not restarted, the device will not recognize
the keyboard.
Current-day power-time curve data and current-day power-generation data are lost after the
device is restarted, but power-generation data history will remain on the device even after a
restart.
4. Technical specifications
Operating voltage 208 V to 240 V
50 / 60 Hz
Operating frequency
Number of monitored inverters 1 to 100
Protection class IP20 / indoor
Ambient temperature -20°C to + 55°C
Communication PLC / 10 M / 100 M Ethernet
Power consumption < 5 W
Dimensions (D x W x H) 37 x 148 x 113 mm / 1.46 x 5.83 x 4.45 inch
Weight 342 g / 0.75 lbs
Standard warranty 1 year
