- Page 1 RF500 System Manual Comark Limited Comark House, Gunnels Wood Park, Gunnels Wood Road, Stevenage, Herts. SG1 2TA Tel: 01438 367367 Fax: 01438 367400 Email: salesuk@comarkltd.com RF500 System Manual 20070702...
-
Page 2: Table Of Contents
Comark Wireless Monitoring - RF500 System Manual Contents RF500 System Components......................4 RF500 Gateway.......................... 4 Transmitters..........................4 RF512 Temperature Transmitter..................... 4 RF512M Temperature Transmitter Backbone Option.............. 4 RF513 Temperature and Humidity Transmitter................ 4 RF513M Temperature and Humidity Transmitter Backbone Option........4 RF516 Precision Temperature Transmitter................ - Page 3 Lumberg Connector........................29 RF512 Pinout......................... 29 RF516 Pinout......................... 29 Power Connector........................29 Gateway Relay Outputs......................30 FCC Approvals..........................30 Equipment Ratings........................30 Supply Voltage.......................... 30 Environmental Conditions......................30 Gateway Storage/Operating Conditions................. 30 RF51X Transmitter Operating Conditions................30 RF51X Transmitter Storage Conditions................. 30 Maintenance and Cleaning......................
-
Page 4: Rf500 System Components
RF500 System Components RF500 Gateway The RF500 Gateway Kit consists of the following items. RF500 Gateway Part No. RF500 Transmitter Activator (2-off) Part No. RF525 Jack Plug 2.5mm (2-off) Part No. RFJACK High Gain Antenna. Part No. RF504 Dc Adaptor Mains Lead with either UK, EU or US plug. -
Page 5: Optional Accessories
Bridge. 1.0m lead to enable transmission through RF resistant barriers. RF500BACKUP RF500 Backup Server Software Know your Gateway Figure 1 - Front view of RF500 Gateway ALARM FAULT MAINS/BATTERY Gateway There are three LEDs on the front of the Gateway:... - Page 6 Figure 2 - Rear view of RF500 Gateway A. Modem Jack – Connect to RJ11 line cord. B. 12V DC input. C. Cable clamps. D. RJ45 Ethernet LAN Socket. E. Rear panel connectors. Do not connect any equipment to any other connector.
-
Page 7: Know Your Transmitter
A. Alarm LED. Flashes red to indicate any one channel in alarm. B. Active LED. Flashes green to indicate external power detected. C. Infra-Red interface. For Comark use only. D. Antenna. (Do not remove whilst in operation) E. Lashing eye - Four available. -
Page 8: Transmitter Display
Transmitter Display RF512, RF513 and RF516 transmitters all have a liquid crystal display as shown below. Only RF512 is capable of using all three display areas. Figure 6 - Transmitter Display EXT1 EXT2 Indicates that the door channel reads open. Indicates that the internal lithium battery requires replacement. -
Page 9: Safety Information
Any modification would void the CE compliance of the Gateway and may invalidate any warranty. If the equipment is used in a manner not specified by Comark, then the protection provided by the equipment may be impaired. -
Page 10: Rf500 Wireless Monitoring System Overview
PC using special software. For operating the RF500 system the only software required is a Web Browser such as Internet Explorer or Firefox. There is no requirement to install software on each users PC. -
Page 11: Meshing Transmitters And Backbone Transmitters
Automatic Data Retrieval (ADR) The fact that transmissions between transmitters and the RF500 Gateway are acknowledged ensures that the transmitters know exactly which data records have been successfully transferred to the Gateway and those which must be re-transmitted. Therefore if the Gateway is temporarily unable to receive or transmit messages for whatever reason, data will not be lost during this period. -
Page 12: Equipment Installation
2 screws and the transmitter then slides into the bracket from the top. With each transmitter Comark Limited provide two cable ties which, once the transmitter is slid into the bracket, can be fed through the slots in both bracket and transmitter case to retain it. The door and DC power cables should be tie-wrapped to the bracket to avoid accidental disconnection. -
Page 13: Powering On And Off
Powering On and Off This chapter covers connectors, switching on and off. Switch On PLEASE ENSURE THE ANTENNA HAS BEEN FITTED. IT IS ESSENTIAL TO AVOID DAMAGE. 1. Plug the Gateway mains adaptor into the socket on the underside of the Gateway. The Mains/Battery indicator should show steady amber. -
Page 14: Gateway Commissioning
Gateway Commissioning This section covers network connection, network configuration, setting date and time, adding users and adding transmitters. The Gateway is commissioned using a Web Browser via a Network connection. This connection can be via cross-over RJ45 cable (recommended) or via modem. Requirements for Commissioning •... - Page 15 Figure 8 – Local Area Connection Properties 3. In the General Tab select the “Internet Protocol TCP/IP” item and click on the Properties button.
-
Page 16: Gateway To Pc Network Connection Via Modem
Figure 9 – General Tab 4. Select the “Use the following IP address” button. 5. Enter the following IP address: 192.168.25.200 6. Enter the following subnet mask: 255.255.255.0 then click OK Gateway to PC Network Connection via Modem This procedure requires that the PC has a modem installed. For Windows 98, ME, 2000 and XP... - Page 17 Figure 10 - Internet Options 1. Start Internet Explorer. 2. From the menu bar click Tools then Internet Options… 3. In the Connections Tab click the Add button. 4. Using the “Network Connection Wizard”, follow the steps, entering the information below. 5.
- Page 18 Figure 11 - Enter the Password 10. Enter both the User name and Password as “RF500 - - - - - - -”. Do not literally type the dashes but replace them with the serial number of the Gateway. 11. Click the “Properties” button.
- Page 19 Figure 12 - Connection Properties 12. In the “Networking” tab, deselect the “Client for Microsoft Networks” item then click OK. You will be returned to the “MyRF500 Settings” screen showing the password. Click “OK”...
-
Page 20: Viewing The Commission-Gateway Web Pages
Figure 13 - Internet Options 13. Select the “Always dial my default connection” item and click “OK”. 14. Connect the Gateway modem jack to an analogue telephone outlet using the appropriate lead and adaptors. Ensure the PC modem is also connected to a telephone outlet. Internet Explorer will now be configured for dial up to the Gateway. -
Page 21: Setup Of First Administrator
Administrator to the Gateway. Thereafter this Administrator’s username is used to perform all subsequent commissioning. 1. At the Gateway user login screen, type the Username “comark” and click Enter. 2. At the password screen enter “42”. -
Page 22: Gateway Clock Setup
The Gateway supports SMS alerts via a third party “Email to SMS” conversion service. Comark have tested the TextMagic “Email to SMS service” www.textmagic.co.uk. To enable SMS alert emails to be sent, subscribe to the TextMagic service and enter your email address... -
Page 23: Email Options
The Emails waiting to go value shows the number of emails that are queued awaiting transmission to the email server. The buttons available on this page are: Comark Displays the log of email server communication. This is invaluable when identifying a “stuck email” for example. -
Page 24: Gateway Programming And Use
This, the RF500 System Manual covers installation and commissioning of the RF500 Wireless Monitoring system from a hardware point of view. A Web-View Help manual for the RF500 Wireless Monitoring System is available online via the Gateway itself. This is a detailed manual incorporating help and detailed information on... -
Page 25: Gateway Specification - Rf500
Gateway Specification – RF500 Channels Up to 512 Transmitters Up to 128 Storage Capacity Up to 10 years storage RF Frequency 2.4GHz using IEEE 802.15.4 +5°C to +35°C, 10-90% RH non- Operating Range condensing. No waterproof option available. Mains power adaptor, rechargeable... -
Page 26: Transmitters Specification - Rf512, Rf513 And Rf516
Transmitters Specification – RF512, RF513 and RF516 Temperature Measurement Range Integral Thermistor Sensor - RF512, RF516 -30°C to +70°C Integral Thermistor Sensor - RF513 -30°C to +70°C External Sensor -40°C to +125°C External Pt100 Sensor -200°C to +400°C Humidity Measurement Range 10 to 90% RH System Accuracy with Standard Sensors Temperature... - Page 27 Logging Memory 32000 records Programmable between 1 minute and 60 Logging Frequency minutes Monitoring Frequency 1 minute Red – Warning LEDs Green – External Power Over moulded food safe clear Case Material Polycarbonate with BioCote® antimicrobial Case enclosure designed to meet IP67 Environmental Protection BS EN 60529 Replaceable Lithium ‘C’...
-
Page 28: Changing Lithium Battery On Rf512 Series Transmitters
C-size cell. Manufacturers part number Saft LSH14 LIGHT. Only replace with the same or equivalent type recommended by the manufacturer. Re-Order number from Comark ‘RFBATT’. Battery Change Procedure Using a suitable screwdriver undo the two battery cover retaining screws and remove the battery cover. -
Page 29: Pinout And Wiring
Pinout and Wiring These connectors are drawn from the point of view of looking into the socket from outside the transmitter Door Connector A Door Positive B RF525 Activator Positive C Common Ground for Door and RF525 Lumberg Connector RF512 Pinout Thermistor External-2 Thermistor External-1 Thermistor External-4 (Reserved for future use) -
Page 30: Gateway Relay Outputs
90-240V AC Frequency 50/60Hz Only use adaptors as supplied by Comark and do not attempt to use others as damage to the equipment and voiding of the CE approval may occur. Environmental Conditions All RF500 equipment is designed for indoor use only. -
Page 31: Maintenance And Cleaning
No specific maintenance is required for the Gateway or the transmitters. Should service be required then a “return to base” service is provided by Comark. Please contact Comark or your local distributor to make arrangements for return of any items for repair. -
Page 32: Declaration Of Conformity
Gunnels Wood Road Stevenage Herts. SG1 2TA Comark Wireless Monitoring System Comprising Part Numbers: RF500, RF512, RF513, RF516 & RF520 Is in conformity with the requirements of the following documents (Directives): EMC Directive 89/336/EEC. The Low Voltage Directive (73/23/EEC) as amended 93/68/EEC Radio &... -
Page 33: Transmitter Error Codes
Transmitter Error Codes Under certain conditions the transmitter display can show an error. These errors can help in diagnosing the reason a transmitter may fail to transmit data to the Gateway. This is not an exhaustive list of errors only the most common will be described here. Error Meaning Resolution... -
Page 34: Definitions Of Gateway Terminology
Autodialler – An optional Autodialler can be provided by Comark for connection to the Gateway to ensure that in the event of an alarm, an audible alarm message is relayed by analogue phone. -
Page 35: Glossary
PC or where a PC is used to retrieve the data, 21 CFR Part 11 can be applied. The RF500 system is designed to aid compliance with 21 CFR Part 11. - Page 36 Modem – Device for connecting to an analogue phone line to communicate with another Personal Computer remotely. Used to dial-in to the Gateway for user access and service. Can also be used to send email alarms via Internet dial-up account. PST –...
