Sigma 2100 Series Operator's Manual

Digital switchers high performance digital routing

Advertisement

DIGITAL SWITCHERS
2100 SERIES
HIGH PERFORMANCE DIGITAL ROUTING
OPERATORS MANUAL
Includes Module and Frame Information for:
AUDIO
DAS-2144
DAS-2188
DAS-21616
SIGMA ELECTRONICS, INC.
P.O. Box 448
1027 COMMERCIAL AVENUE
EAST PETERSBURG, PA 17520-0448
(717) 569-2681
(MAR 04)
VIDEO
DVS-2144
DVS-2184
DVS-21164
DVM-1616
DVS-1616

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2100 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Sigma 2100 Series

  • Page 1 DIGITAL SWITCHERS 2100 SERIES HIGH PERFORMANCE DIGITAL ROUTING OPERATORS MANUAL Includes Module and Frame Information for: AUDIO VIDEO DAS-2144 DVS-2144 DAS-2188 DVS-2184 DAS-21616 DVS-21164 DVM-1616 DVS-1616 SIGMA ELECTRONICS, INC. P.O. Box 448 1027 COMMERCIAL AVENUE EAST PETERSBURG, PA 17520-0448 (717) 569-2681...
  • Page 2: Table Of Contents

    CONTROL PANEL OPERATION System Control Panel ................Multiple Pages SECTION 4 FRAME AND POWER SUPPLY Modular Frame / Power Supply ............... Multiple Pages SECTION 5 (OPTIONAL) 2100 SERIES OPTIONS Descriptions for 2100 Series Options ............Multiple Pages...
  • Page 3: Specifications

    2100 DIGITAL Specifications DIGITAL VIDEO SWITCH FRAME (DVS -1616, DVM-1616, DVS-2144, DVS-2184, DVS-21164) DIGITAL VIDEO INPUT: Input Signal ................16, Single-ended, terminated 75Ω Input Level ................SMPTE 259M, 800 mVp-p Data Rate ................400 Mb/s maximum Input Cable Length (DVS-1616)..........100 ft. (33 meters) maximum (BELDEN 8281) (others) ............
  • Page 4 2100 DIGITAL Specifications (cont.) SYSTEM CONTROL INTERFACE MODULE (SCI-2144) Data Transmission System ............ RS-232 & RS-422 Serial Port Baud Rate ............4,800, 9,600, 19,200, 38,400 baud Control Levels ............... 4 Communication Line ............. Coaxial, up to 2000 feet Control Panels ....
  • Page 5: Unpacking

    Inspect your packages and equipment for any damage that may have occurred during shipping. Report any damages to both Sigma Electronics, Inc. and your shipping company. It is the buyer’s responsibility to file a claim against the shipping company for cost of repair due to shipping damage.
  • Page 6: Sync. Reference Input

    This may result in non-synchronous switching. REDUNDANT POWER The 2100 Series can be configured with a 3RU frame that contains a redundant power supply. The dual power supplies operate simultaneously. When the 3RU frame contains a redundant power supply the number of card slots available drops from seventeen to thirteen.
  • Page 7: System Frames

    Simply connect the source video cables to corresponding input BNCs on the rear of the video routing frame. Refer to the sections below to review drawings for input and output layout. Sigma Electronics’ connector layout is designed to economically maximize performance. The source video cable connects to the video input on the rear panel.
  • Page 8 DVS-1616 and DVM-1616 SERIES 2100 DVS-1616 SIGMA ELECTRONICS, INC. DVS-1616 FRONT PANEL CONTROL BUS CLEAR 1616 FUSE 3.0 AMP SERIAL I/O INPUTS OUTPUT SLO-BLO REF IN COMM System Control Serial Digital Serial Digital Power Supply Interface Video Input Video Output...
  • Page 9: Dvs-2144, Dvs-2184 And Dvs-21164

    DVS-2144, DVS-2184 AND DVS-21164 The DVS-2144 is a four-input to four-output video switch, the DVS-2184 is an eight input to four output video switch and the DVS-21164 is a sixteen input to four output video switch. The inputs; arranged in ascending numerical order, top to bottom;...
  • Page 10: Das-2144 Module Drawing

    DAS-2144 Module Block Diagram The 4x4 digital audio switcher is DAS-2144 provided as a one-slot width module. The W1 - Level Jumper rear panel has inputs on the top half and outputs on the bottom half of the module. Logic IC The main PCB, also identified as DAS- Control Bus 2144, is directly attached to the rear...
  • Page 11: Das-2188 Module Drawing

    DAS-2188 Module Block Diagram The 8x8 digital audio is provided Level / DAO-108 DAI-108 as a two card slot width module. The rear Matrix / Group panel has inputs on the left half of the module. The input card, DAI-108, is Logic IC J5 / J6 attached to the input connector panel.
  • Page 12: Das-21616 Module Drawing

    DAS-21616 The 16x16 digital audio is DAO-916 Module Block Diagram provided in a four card slot width DAO-108 Level/Group module. Inputs are provided on Level/Group Logic the left side of the rear panel. Logic Control Control Outputs are located on the right side of the rear panel.
  • Page 13: Control Panels

    9 Pin D connector on the SLV-2126 located in the master frame. If 2100 Series frames are used only for modules other than routing, there is not a need to interface the frames. This applies to frames that house analog or digital distribution amplifiers, transcoders, encoders, decoders and sync generator modules.
