Thank you for purchasing this Quested monitor. You can be certain that you have purchased one
of the finest monitors in the world. If you take time and care in positioning and aligning the system,
you will appreciate why Quested monitors have a reputation for faithful reproduction covering the
entire audible spectrum. They are professional monitors and therefore are not designed to flatter
but to faithfully reproduce. Please take care to maintain the system and it will give you many years
of service. You will also be assured the best possible performance and long-term reliability of your
system.
Please read this manual, which we have kept as concise as possible, as it really will help you and
covers important safety considerations
The SB10 is a remote-powered sub woofer.
ideal in areas where space is at a premium but bass extension is still a requirement. However its
power output of 210 Watts RMS also enables the sub bass to be used in larger rooms and
applications requiring a powerful yet portable monitor. The
filters, which allow it to be matched accurately with a variety of full range cabinets. Used in
conjunction with the Quested S6, S7 or S8 active 2-way monitors, the SB10 enables an active, 3-
way, full range system in rooms that would preclude the use of a large full range monitors
The SB10 is remote powered, i.e. the amplifier and crossover electronics are housed in a separate
1U box. This brings with it several advantages. Firstly you can now mount the SB10 electronics
close to hand, bringing monitoring functions and metering to hand. This also makes it a lot easier
to precisely setup the sub bass. Additionally very low frequency reproduction causes vibration. In
standard self-powered designs these vibrations often feed back through the microphonic
components within the amplifier and cause distortion. Another advantage of this design is that the
cabinet and electronics can be upgraded independently of each other. Typical applications include
near to mid-field bass extension or dedicated LFE channel for recording/mixing, programming, post
production suites, broadcast and surround sound.
2

SAFETY CONSIDERATIONS

2.1 General

Before proceeding to connect your Quested monitor to the AC power supply, please read the
following safety information:-
CAUTION: RISK OF ELECTRICAL SH O CK. REFER SERVICING TO QUALIFIED
PERSONNEL.
THE POWER C ORD MUST ALWAYS BE REMOVED BEFORE THE
AMPLIFIER IS
DISMANTLED.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRICAL SHO CK, DO NOT
EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
WARNING: THIS APPLIANCE MUST BE EARTHED.
The cores in the supplied mains lead are colour coded in accordance with the following code:
As the colours of these wires may not correspond with the coloured markings identifying the
terminals in your plug, proceed as follows:
The wire, which is coloured green and yellow, must be connected to the terminal in the plug,
which is marked with the letter 'E' or by the earth symbol, or coloured green and yellow.
The wire, which is coloured blue, must be connected to the terminal in the plug which is marked
with the letter 'N' or coloured black.
.
Its remote electronics and its compact size make it
Green and Yellow: Earth
Blue: Neutral
Brown: Live
3
SB10 has variable low and high pass
