- Page 1 OPERATION AND MAINTENANCE MANUAL LED light machine operation lamp w.o. transformer Art. 0372 TRANSLATION OF THE ORIGINAL INSTRUCTIONS...
- Page 2 Manual on the date of issue, as listed on this page; however, the device may be subject to potentially major technical changes in the future, without the Manual being updated. Therefore, contact FERVI for information about modifications that may have been implemented. REV. 2...
-
Page 3: Table Of Contents
MACHINES AND ACCESSORIES CONTENTS GENERAL INFORMATION................4 GENERAL SAFETY WARNINGS ..............4 Precautions with regard to electric shocks ..............4 Precautions regarding installation ................5 Precautions regarding cleaning..................5 Technical Assistance .....................5 DESCRIPTION OF THE SPOTLIGHT AND INTENDED USE......6 Identification plate .......................6 TECHNICAL SPECIFICATIONS .............. -
Page 4: General Information
MACHINES AND ACCESSORIES 1 GENERAL INFORMATION This manual is considered an integral part of the lighting device to which it was attached at the time of purchase. The manufacturer holds all ownership to material and intellectual property of this manual; any disclosure or copying, even partial, of this publication without prior written consent is forbidden. -
Page 5: Precautions Regarding Installation
MACHINES AND ACCESSORIES 2.2 Precautions regarding installation Risks associated with installation Attach the unit to a solid and strong support surface: stably and securely attach the device to the support structure or frame of the machine tool. Install the unit as described in the instructions for use regarding the position and the type of fixation. -
Page 6: Description Of The Spotlight And Intended Use
ACCESSORIES 3 DESCRIPTION OF THE SPOTLIGHT AND INTENDED The LED light machine operation lamp w.o. transformer (Art. 0372) is a heavy-duty, securable and adjustable lighting fixture. It is a device designed to illuminate within and near stationary machine tools, to allow safe use of the machines themselves, in industrial plants or similar environments. -
Page 7: Technical Specifications
MACHINES AND ACCESSORIES 4 TECHNICAL SPECIFICATIONS Description (Measurement unit) 0372 AC voltage (V) Maximum power (LED x W) 5 x 2 Level of IP protection Height (mm) Weight (kg) Number of nodes Lamp Diameter (mm ) 125 5 IMPROPER USES AND PRECAUTIONS The following actions described, which obviously can not cover the entire range of potential possibilities of "misuse"... -
Page 8: Transportation And Moving
MACHINES AND ACCESSORIES 6 TRANSPORTATION AND MOVING Lifting the equipment for transportation, can be done manually, by the operator. The relatively low weight of the lamp allows it to be moved manually and safely without the danger of injury to the operator. The operator must hold the device with both hands when lifting and moving it. -
Page 9: Commissioning
MACHINES AND ACCESSORIES 8 COMMISSIONING 8.1 Powering on/Connecting the Device To power the device, you must have an appropriate power cable that takes voltage (24 V AC) from the machine tool itself. Characteristics of the power cord: 2 X 0.75 mm For proper connection of the power cord use insulated terminals: Figure 4 - Power supply Connection... -
Page 10: Turning The Lamp On
MACHINES AND ACCESSORIES 9 TURNING THE LAMP ON After you have successfully installed the device, turn on the lamp by moving the switch, located on the handle on top of the cover, in position "I". Figure 6 – Detailed view of the switch. -
Page 11: Troubleshooting
MACHINES AND ACCESSORIES 11 TROUBLESHOOTING The following table shows the type of defect / problem, possible causes, and possible remedies for the malfunction. The table is a useful aid for the maintenance technician when looking for problems with the equipment. Fault Cause Solution...
