- Page 1 USE AND MAINTENANCE MANUAL Low consumption lamp Art. 0891 ORIGINAL INSTRUCTIONS...
- Page 2 Manual on the date of its issuance (shown in this page). On the other hand, the instrument may also be subject to important technical changes in the future, without the manual being updated. Therefore, contact FERVI for information about modifications that may have been implemented. REV. 1...
-
Page 3: Table Of Contents
HARDWARE CONTENTS GENERAL SAFETY WARNINGS ..............4 Precautions with regard to electric shocks ..............4 Precautions regarding installation ................4 Precautions regarding cleaning..................5 Technical assistance .....................5 DEFINITIONS.................... 5 DESCRIPTION OF THE LAMP ..............6 Identification plate .......................7 Technical specifications ....................7 IMPROPER USE AND CONTRAINDICATIONS..........8 TRANSPORTATION AND MOVING .............. -
Page 4: General Safety Warnings
HARDWARE 1 GENERAL SAFETY WARNINGS Risks associated with using the instrument Each person who is in charge of the installation, use and maintenance of the lamp, must carefully read this manual, and in particular this chapter with information about safety, in order to acquire full knowledge of the device. -
Page 5: Precautions Regarding Cleaning
HARDWARE 1.3 Precautions regarding cleaning Risks associated with cleaning Plastic materials are used in some parts of the lamp. Applying organic solvents (such as benzene), or other chemicals for cleaning may cause deformation or discolouration. Clean the device gently, using a soft dry cloth. 1.4 Technical assistance For any problems or concerns, please contact, without hesitation, the Customer Service Department of the dealer from whom you purchased the product, who has specialised staff,... -
Page 6: Description Of The Lamp
HARDWARE 3 DESCRIPTION OF THE LAMP The Low consumption lamp is an adjustable table mounted lighting device, installed on an articulated and adjustable arm and equipped with a magnifying glass for the observation of machined surfaces. It is equipped with two fluorescent tubes on the sides of the magnifying lens, and an additional magnifying lens. -
Page 7: Identification Plate
The device is powered by the mains power supply (230V / 50Hz) as indicated on the identification plate attached to the body of the device. Figure 3 – Identification plate 3.2 Technical specifications Model Description (Measurement unit) 0891 Voltage (V) Frequency (80 - 16000 Hz) Power (W) 2 x 9 Arm length (mm) -
Page 8: Improper Use And Contraindications
HARDWARE 4 IMPROPER USE AND CONTRAINDICATIONS The following actions described, which obviously can not cover the entire range of potential possibilities of "misuse" of the equipment, are to be considered strictly prohibited. IT IS STRICTLY FORBIDDEN!!! To install and use the equipment on surfaces that are not strong enough to support its weight;... -
Page 9: Commissioning
HARDWARE 7 COMMISSIONING 7.1 Installation Attach the universal clamp lamp on the edge of a table or a bench and tighten the locking screw of the clamp until a rigid and secure attachment is achieved. In this regard, always choose a solid and resistant support surface. 7.2 Power supply / connection To power the device, plug the cord into an appropriate 220 V / 50 Hz wall socket. -
Page 10: Maintenance And Cleaning
HARDWARE 9 MAINTENANCE AND CLEANING The purpose of this chapter is to provide all the information on maintenance procedures and frequency required for the Flexible arm lamp with magnifying lens. Frequency INTERVENTION Daily Weekly Monthly 1. General visual inspection 2. Check that plates are clearly visible and legible 3. -
Page 11: Troubleshooting
HARDWARE 10 TROUBLESHOOTING The following table shows the type of defect / problem, possible causes, and possible remedies for the malfunction. The table is a useful aid for the maintenance technician when looking for problems with the equipment. Fault Cause Solution Plug inserted incorrectly.
