Solwise C1060 Operating Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk
C
1
0
6
C
1
0
6
I
P
C
a
m
I
P
C
a
m
O
p
e
r
a
t
i
n
g
I
n
s
t
O
p
e
r
a
t
i
n
g
I
n
s
t
Version V2.0
0
0
e
r
a
e
r
a
r
u
c
t
i
o
n
s
r
u
c
t
i
o
n
s
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C1060 and is the answer not in the manual?

Questions and answers

Related Manuals for Solwise C1060

Summary of Contents for Solwise C1060

  • Page 1 Version V2.0 Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...
  • Page 2 However, no responsibility will be assumed for any inaccuracies. Specifications are subject to change without notice. The information herein is subject to change without notice. This manual is periodically reviewed and revised. No responsibility is assumed for any errors or omissions in this document. Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...

  • Page 3: Table Of Contents

    RANSLATION ....................- 33 - ORWARDING ....................- 33 - EFAULT ATEWAY ..........- 34 - CCESSING ULTIPLE AMERAS OVER THE NTERNET (DDNS)..............- 34 - YNAMIC OMAIN ERVICE ..................- 35 - ONFIGURATION XAMPLE TECHNICAL PARAMETERS ..................- 37 - Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...
  • Page 4 Figure 38 System Log View ..................- 30 - Figure 39 “Guest Zone” View..................- 30 - Figure 40 IP Camera’s Application Environment ............- 31 - Figure 41 Typical Network Environment ..............- 35 - Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...

  • Page 5: Introduction

    1. IP Camera *1 2. IP Camera Utility CD *1 3. 5V Power Adapter *1 4. Dynamic DNS Registration Card *1 5. Ceiling Mounting bracket *1 1.3 Identify IP Camera 1.3.1 IP Camera Views - 1 - Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...
  • Page 6 Figure 1 IP Camera 45-angle View Lens Tilt Night Vision LEDs Working Status LED Privacy Indicate LED User Visiting LED Privacy Status Button IP Show LCD Figure 2 IP Camera Front View - 2 - Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...
  • Page 7 LED: User Visiting Figure 4 Front View Indication and Operation The privacy button toggles Privacy mode and Normal mode, In Privacy mode, all the remote users will not be allowed to see the video. - 3 - Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...
  • Page 8 Figure 5 LCD Indications LCD will loop show IP Address/Network Mask/Gateway, as shown in the Figure 6. IP Address=192.168.0.24 Subnet mask=255.255.255.0 Gateway IP=192.168.0.1 Figure 6 IP Address/Network Mask/Gateway loop show Status icon indications list: Icon Meaning - 4 - Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...
  • Page 9 Always on or always off System error Fast Flashing: System is starting, Please wait. Turns on for 1/2 second every 1 second Slow Flashing: Upgrading firmware, Please wait. Turns on for 1/2 second every 6 second - 5 - Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...
  • Page 10 Figure 8 Input & Output defines Input Pins: The input pins can be used for 2-way external sensor input. For example, you may connect a Person Infrared Sensor (PIR) to it for motion detection. When - 6 - Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...
  • Page 11 RJ-45 Ethernet Socket: Connects your IP Camera to LAN. CF Card Socket: Insert a Compact Flash Card for scheduler or sensor trigger’s images storage. Support volume is 1MByte to 2GByte. CF Card should be format as FAT16/FAT32 before inserted. - 7 - Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...

  • Page 12: Functions And Features

    PC on the network running web browser. The IP camera utilizes MJPEG hardware compression, brings 30fps@VGA resolution live video to you. The built-in pan and tilt, live streaming,and snapshot/video capture functions can all be - 8 - Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...

  • Page 13: Advanced Features

    Relay Output Control The internal relay can be used to control external devices according to your setting. DDNS support IP Camera provides dynamic DNS function, thus you may use it in xDSL environment. - 9 - Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...

  • Page 14: System Requirement

    DNS service will make accessing from the Internet much more convenient. Signing up for a DDNS is free and easy; you can get it in some websites, such as our website that can give you more www.vipcam.cn information. - 10 - Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...

  • Page 15: Setup Procedure

    Figure 11 Connecting the Ethernet wire Connect the power supply to the back of the camera as shown, and then plug the supply into an available power outlet. Figure 12 connecting the power supply - 11 - Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...

  • Page 16: Router/Switch/Hub/Xdsl Modem Connection

    Run an Internet Explorer, and input the IP address as shown on the LCD to IE’s address bar, for example: http://192.168.0.234. Note: IP Camera by default use fixed (static) IP address setting. default address :192.168.0.234, Network Mask 255.255.255.0, Gateway is 192.168.0.1 - 12 - Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...

  • Page 17: Use Ipcamsearch Tool To Setup Ip Cameras

    Then you may click [Setup IP] button to change IP Camera’s IP address to adopt your PC setting. Click [Auto Set], let IPCamSearch tool find an available IP Address for you. - 13 - Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...
  • Page 18 IP Camera’s IP Address has changed(IP Camera is in static IP mode now). Then you may click [Connect IPCam] to run an Internet Explorer, You can do more configuration by click [System Setup] on homepage of IP Camera. - 14 - Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...

  • Page 19: View Video On Web Browser

    Figure 17 IP Camera Home Page Note: Your web browser must support Javascript function. Please download JVM from http://java.com Click “User Visit” to view video. You will see a message box which requires your login as shown below. - 15 - Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...
  • Page 20 Note: You must setup Internet Explorer’s security configuration properly, allow unsigned ActiveX Control to install. You can follow this procedure to setup IE security configuration: 1. Select [Internet Options] in [Tools] menu of IE; - 16 - Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...
  • Page 21 2. Switch to [Security] option card; 3. Select [Trusted Sites]; “ “ before 4. Uncheck √ “…… ”; https:(S) 5. Input IP Camera’s IP address or URL, for example, http://192.168.0.250 http://C1060-id.vipcam.cn; 6. Click [Add], [OK] to save. - 17 - Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...
  • Page 22 Up/Down/Left/Right, and left-right cruise or top-down cruise, or, return to home position. On the left, you can also select the Resolution, Quality, Brightness, Contrast and Zoom. Resolution can be 640x480, 320x240, and 160x120. The higher resolution, the higher clarity, while requiring more bandwidth. - 18 - Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...

  • Page 23: Setup Ip Camera On Web

    When using the camera free standing, be sure to secure the cables. Failing to secure the cables could cause the camera to be pulled off the mounting surface resulting in damage to the camera. - 19 - Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...
  • Page 24 Step 7. Secure the camera to the mounting bracket using the thumbscrew located on the bottom of the platform. Step 8. Loosen the tilt adjust thumbscrew and tilt the camera toward the area to be observed. - 20 - Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...

  • Page 25: System Configuration

    5 System Configuration 5.1 System status This page shows status of the system for diagnose. Figure 24 System Status View - 21 - Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...

  • Page 26: User Management

    Guest Zone to see the video without input any username/password. If you unchecked this (default), the visitors have to enter at least a “Guest” permission username/password to visit the “Guest Zone”. At any time, the “User - 22 - Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...

  • Page 27: Network

    Zone” only allows “User” & “Administrator” permission to visit. ”Vilar Backbone Service Setup”: This service is provided by Vimicro, you may visit www.vipcam.cn for details. 5.3 Network Figure 26 Network Setup View - 23 - Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...

  • Page 28: Date And Time

    5.4 Date and Time Figure 27 Date and Time Setup View 5.5 Video Figure 28 Video Setup View - 24 - Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...

  • Page 29: Jpeg Encryption

    5.6 JPEG Encryption Figure 29 JPEG Encryption Setup View Figure 30 Require Password Input in Client Web Browser - 25 - Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...

  • Page 30: E-Mail

    Account Name and Password to the Email server. This information is necessary to allow email notification features. “SMTP Server”: The administrator will have to enter the Email server address here. “Sender’s Email” This will determines IP Camera’s Email address. - 26 - Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...

  • Page 31: Ftp

    “E-mail Sender Username”: Enter the account name or login name to the Email server. E-mail Sender “ Password”: Enter the password for the above account name. 5.8 FTP Figure 34 FTP Setup View - 27 - Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...

  • Page 32: Sensors And Motion Detection

    5.9 Sensors and Motion Detection Figure 35 Sensors and Motion Detection Setup View - 28 - Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...

  • Page 33: Scheduler Trigger

    5.10 Scheduler Trigger Figure 36 Scheduler Trigger Setup View 5.11 System Maintenance Figure 37 System Maintenance View - 29 - Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...

  • Page 34: System Log

    1. In Local Area Network (LAN) only. 2. Direct connect to INTERNET via xDSL (PPPoE) Modem. 3. Share one INTERNET connection with other computer, and connect to INTERNET via a gateway or router. - 30 - Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...

  • Page 35: Wan Ip Address

    You can find your current WAN IP address by checking your router’s status page. There are also various websites such as www.whatismyip.com which will tell you the IP address that you are currently using to access the Internet. - 31 - Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...

  • Page 36: Network Address Translation (Nat)

    The solution to the ever changing IP address is known as DDNS or dynamic domain name service. A DDNS will allow you to find your network by a domain name, such as c1060-id.vipcam.cn, rather than needing to know the IP address. 6.2 Network Address Translation (NAT) Most home routers and business firewalls today perform something called NAT or Network Address Translation.

  • Page 37: Port Forwarding

    You camera is now live on the Internet. Browsing your camera from the Internet is the same as browsing on your LAN except that you must enter your WAN IP address (or camera domain name if you’ve set up a DDNS service) instead of the LAN IP address. - 33 - Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...

  • Page 38: Accessing Multiple Cameras Over The Internet

    WAN IP address is when you want to access your network over the Internet. The solution to the dynamic IP address problem comes in the form of a dynamic DNS service. - 34 - Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...

  • Page 39: Configuration Example

    The Internet uses DNS servers to lookup domain names and translates them into IP addresses. Domain names, such as C1060-id.vipcam.cn, are just easy to remember aliases for IP addresses. A dynamic DNS service is unique because it provides a means of updating your IP address so that your listing will remain current when your IP address changes.
  • Page 40 5) Input the following information on page: Enabled/Disabled: Enabled Name: C1060 Private IP: Input IP Camera’s Address, e.g. 192.168.0.151 Protocol Type: Private Port: Public Port: Schedule: Always 6) Click Apply to save. IP Camera can be accessed in WAN. - 36 - Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...

  • Page 41: Technical Parameters

    Size D: 105 x W: 90 x H: 135 mm Temperature 0℃~45℃ 50℃ 95% Humidity Management System Setup Web Page Upgrade Firmware upgrade by Web Other 32bit ARM@66MHz frequency. SDRAM 16MByte FLASH 4MByte - 37 - Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...
  • Page 42 Connect to LAN cable Part-B & Part-A, Replace order No.1 & 3, No.2 & 6. c. Connect LAN cable Part-B No. 3 to LAN plug No. 1 and connect the next by order. ========================== The End ========================= - 38 - Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...
