- Page 1 C1002 IP Camera Quick Installation Guide Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...
- Page 2 However, no responsibility will be assumed for any inaccuracies. Specifications are subject to change without notice. The information herein is subject to change without notice. This manual is periodically reviewed and revised. No responsibility is assumed for any errors or omissions in this document. Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...
-
Page 3: Table Of Contents
2.3.10 DDNS Service Setting ......................28 2.3.11 Mail Service Settings ......................29 2.3.12 FTP Service Settings ......................29 2.3.13 Alarm Service Settings .......................30 2.3.14 Upgrade Device Firmware ....................30 APPENDIX ........................... 31 A. C1002 R ........................31 ANEL B. C1002IR T ........................31 C. C ..................33... -
Page 4: Compliance Statement
Compliance Statement CAUTION: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Declaration of Conformity Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk... -
Page 5: Notes, Cautions, And Warnings
CAUTION: If the action specified in the “ ” is not complied CAUTION with, damage to your equipment could result. NOTE: A “ ” provides supplementary information, emphasizes a point or NOTE procedure, or gives a tip for easier operation. Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk... -
Page 6: Package Content
Package Content 1. Indoor Camera Outdoor Camera 2. Power Adapter : 5VDC, 1A 3. Utility CD : Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk... -
Page 7: Installation
1. Installation 1-1 Connect C1002 to your Local Network CAUTION: Please use the DC power adapter that is provided with camera. Connecting camera to other power source will cause permanent damage to the camera. NOTE: Please use straight Ethernet cable (CAT. - Page 8 “Double Clicks” or ”Right Click” on the camera you want to connect, choose “Access IP Camera” will bring up IE browser with camera login screen. Note: You can choose to modify the camera to fixed IP by Choosing “Network Settings” Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...
- Page 9 Please always write down the password and keep password in safe place. Please kindly notice, if you forget password you set, you will have to return the camera to manufacturer for recovery, there is no way to reset password of your camera. Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...
-
Page 10: There Is Not Dhcp Server In Your Lan
You must choose “Network Settings” to set the camera to fixed IP. Please modify the “IP Address” to the same subnet of your computer. Normally the IP should start with “192.168.xxx.xxx” Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk... - Page 11 If you are not sure of your computer IP address, please go to DOS mode by : “START” => “RUN” => Open “CMD” Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...
- Page 12 Type “ipconfig /all” at command prompt, You will be able to find you computer network settings. After input correct network settings, press “Set” Follow the procedures described in 1-1-1 There is DHCP Server in your LAN Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...
-
Page 13: Connect C1002 To Your Computer Directly
1-2 Connect C1002 to your computer directly Because there is no DHCP Server available, you have to setup the network settings manually. Please follow the procedures in previous sections (1-1-2) to link to your camera. 1-3 Connect C1002 to Internet... - Page 14 5. Access camera URL through Internet. Example: http://your_camera.dyndns.org:port Please reference more details of Router & DynDNS setup on Reference User’s Manual. Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...
-
Page 15: Software Installation
Please insert the “Utility CD” into your CD-ROM drive, auto-run program will start and below screen will guide you through installation. To install software and ActiveX plug-in Please click on the “Install 1st” tab to install software and ActiveX plug-in. Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk... - Page 16 Click on “Next”, Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...
- Page 17 Click on “Close”, The IP Camera search utility software icon will display on your desktop. Click on the “IP Camera Tool” tab to search Clairvoyant 1002 IP cameras in your local network. Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...
-
Page 18: Login & Access Camera Video
Password field blank as it is. Click on “Sign Note: Please notice it’s lower case characters admin, the User and Password are capital sensitive. On the top left corner, select language (English or Chinese). Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk... - Page 19 Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...
- Page 20 Working environment Mode : indoor ( 50Hz/ 60Hz) / outdoor Photo parameter modulation：Brightness, Contrast Scout menu : “Snapshot” and “Record” Scout window setting : 1. May see only current window 2. May increase 3 IP cameras, real-time view video in four windows as below Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...
- Page 21 To view four cameras simultaneously, go to Administrator setup page, Select “Multi-Device Setting”, as illustrated as followed. Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...
- Page 22 Click on channels to start recording: Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...
-
Page 23: To Take Snapshot Of Present Scene On Screen, Click On The "Snapshot" Button
To take snapshot of present scene on screen, click on the “snapshot” button: Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk... -
Page 24: Administrator Setup Page
Administrator setup page Page 2.3.1 Device Info Indicates Camera ID & Firmware version. 2.3.2 Alias Settings Camera Alias : Input the camera name for you to recognize. Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk... -
Page 25: Date & Time Settings
Please always write down the password and keep password in safe place. Please kindly notice, if you forget password you set, you will have to return the camera to manufacturer for recovery, there is no way to reset password of your camera. Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk... -
Page 26: Multi-Device Settings
DNS: Enter DNS IP address provided by your ISP (Internet service provider). Http Port: Enter the input port number, default as 80. If IP camera connects with ADSL directly chose Using ADSL Dialup, enter ADSL dialup user and password Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk... -
Page 27: Wireless Lan Settings
Please request User account and Password from your ADSL service provider. If the IP is not fixed (dynamic), Click “Report ADSL IP by Mail” will result email notification every time the ADSL IP is changed. 2.3.9 UPnP Settings Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk... -
Page 28: Ddns Service Setting
1. “No Action” no DDNS settings set, no action taken. 2. ”Errors in network Communication”: can’t access DDNS server due to Network errors (blocked by ISP) or wrong DNS, Gateway settings. 3. “Update successfully” : Successfully updated the DDNS server database. Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk... -
Page 29: Mail Service Settings
Make sure the DNS Server and Gateway settings are correct if you don’t choose DHCP and setup “Networking Settings” manually. 2.3.12 FTP Service Settings Note: The Upload folder must be created before successful files upload. Remember to add “/” before folder name Don’t upload when Interval is zero. Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk... -
Page 30: Alarm Service Settings
Upload Image on Alarm : Upload snapshot pictures to pre-assigned FTP server folder. 2.3.14 Upgrade Device Firmware WARNING: ONLY FOR CERTIFIED TECHNICAL ENGINEERS Get correct firmware from authorized dealer, wrong version of firmware will damage your camera permanently. Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk... -
Page 31: Appendix
Appendix A. C1002 Rear Panel LAN: RJ-45/10-100 Base T ANT : For Wi-Fi wireless (optional) DC5V: 5V/1A Power supply (indoor, Wi-Fi) B. C1002IR Tail Wire RESET: Restore factory default in case of forgetting password. ALARM IN: Connect to Sensor/ Detector, Normal Open, will trigger alarm when... - Page 32 - Optional Digital FTP alarm, scheduling, NFS storage functions - Optional Alarm inputs and outputs, Power over Ethernet, Wi-Fi wireless - Optional DVR client software for 16 cameras monitoring. - OEM PTZ or Fixed Dome camera available. Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...
-
Page 33: Cross Ethernet Cable Making Tip
Connect LAN Cable Part-A and LAN plug by order as one to one . b. Connect to LAN cable Part-B & Part-A, Replace order No.1 & 3, No.2 & 6. c. Connect LAN cable Part-B No. 3 to LAN plug No. 1 and connect the next by order. Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk... - Page 34 ========================== The End ========================= Solwise Ltd., www.solwise.co.uk, sales@solwise.co.uk...
