- Page 1 INSTALLATION AND INSTRUCTION MANUAL Model ULB42 Undercover Interior LED Lightbar PLITSTR299 REV. D 3/28/05...
- Page 2 NOTICE Due to continuous product improvements, we must reserve the right to change any specifications and information, contained in this manual at any time without notice. Star Headlight & Lantern Co., Inc. makes no warranty of any kind with regard to this manual, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
-
Page 3: Mounting Instructions
#8 Flat Washers #8 Tooth Washers #8 Nut Rubber Channel Gasket The ULB42 is designed to be mounted in the front windshield of a vehicle using both the pre-existing visor clips as well as the corner posts. VISOR CLIP BRACKET INSTALLATION... - Page 4 1. Connect one of the slotted "L" brackets to one of the forked "L" brackets using one of the screws, a flat washer, a tooth washer, and a nut. 2. Repeat this using the other slotted "L" bracket and forked bracket. You should now have two adjustable forked mounting brackets.
- Page 5 6. Some vehicles may not have visor clips appropriate for this application, or may completely lack any visor clips. An alternate mounting screw hole is provided in the bracket for these situations. This hole can be used with an appropriate user supplied screw or other suitable fastener.
- Page 6 10. Once the brackets are installed securely, check to see that the bottoms of the brackets are level. If they are not level, remove the brackets and carefully bend them as necessary. Reinstall them and check again for levelness. Repeat this process until the brackets are level. 11.
- Page 7 13. After you have set the brackets to the proper height, refer to the diagram below for the "Safe" areas to attach your forked mounting bracket. Mark two holes for each bracket. Star highly recommends marking the desired screw holes first. Remove the lightbar and measure the marked points to ensure they are within the "Safe Area".
- Page 8 2. Connect one of the double-slotted "L" brackets to one of the slotted straight brackets using one of the screws, a flat washer, a tooth washer, and a nut. 3. Repeat this using the other double-slotted "L" bracket and slotted straight bracket.
-
Page 9: Baffle Adjustment
Loosen the brackets, temporarily slide them aside, and drill a 1/8" hole in each of the marked locations. Caution: Be sure to check that there are no wires or anything else behind the molding that may be damaged by the screw holes. Return the brackets to their original position against the corner post and use two of the self-tapping screws in each side to secure each bracket to the corner posts. -
Page 10: Pattern List
Operating Instructions 1. The Star Phantom ® is designed for simple operation. This unit has an On/Off switch, a Pattern Select Button, and a Map Light Button. 2. The On/Off switch is located closest to the driver's side. It switches The ®... - Page 11 4. The right button is the Map Light switch. Located at the center of the lightbar is the "night vision" map light. Depressing the button once will illuminate the "night vision" map light. Pressing the button again will turn the light off. Once your Star Phantom ®...
-
Page 12: One-Year Limited Warranty
® The Star Phantom uses state-of-the-art Light Emitting Diode (LED) technology. This undercover lightbar is comprised of ten segments of ultra- bright LEDs that are operated in a multiplexed mode to efficiently produce light output with lifetimes up to 100,000 hours. Under normal circumstances, you will not need to replace any lights in this lightbar.
