Pura QCUF Installation & Operation Manual

Quick change ultrafiltration drinking water system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Installation, Operation & Service Instructions with Part List
Quick Change Ultrafiltration Drinking Water System
Models: QCUF
www.pura.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QCUF and is the answer not in the manual?

Questions and answers

Related Manuals for Pura QCUF

Summary of Contents for Pura QCUF

  • Page 1 Installation, Operation & Service Instructions with Part List Quick Change Ultrafiltration Drinking Water System Models: QCUF www.pura.com...
  • Page 3 The PURA Quick Change Drinking Water System contains a replaceable ultrafiltration membrane filter which is critical for the effective reduction of Total Dissolved Solids. The filtered water should be tested periodically to verify that the system is performing properly.

  • Page 4: Table Of Contents

    Overview of the PURA Quick Change UF System’s Components ....... .

  • Page 5: Specifications And Performance Data Sheet

    Stage 1 Stage 2 Stage 3 Stage 4 Faucet Ultrafiltration Activated Carbon Chrome QCUF 1340201-60 Sediment Filter Sediment Filter Membrane Filter or Standard Daily Production rate L/day (g/day) . . . 2725.5 (720) efficiency rating..... 100% recovery rating .
  • Page 6 recommended influent Water Characteristic Notes Pressure 40 - 100 psi 1. A softener is strongly recommended for water over 10 gpg hard. Installing a system without a softener on water with hardness higher Temperature 40 - 77 ºF than 10 gpg will reduce the life of the membrane. 5 - 10 2.

  • Page 7: Suggested Installation Equipment

    Suggested Installation Equipment         recommended tools 1. Utility Knife  2. Flathead Screwdriver 3. Phillips Screwdriver   4. Center Punch 5. 7/8” Stepped Drill Bit 6. Finish Hole Saw 7. Porcelain Saw 8.

  • Page 8: Overview Of The Pura Quick Change Uf System's Components

    Dispenser Faucet The PURA faucet (5) allows the product water to be drawn from the system with a simple rotation of the handle. Note: Cleanliness is essential in the Preparation procedure. Be sure to wash your hands thoroughly before handling...

  • Page 9: Package Contents

    Package Contents                 Figure 3 1. UF Manifold 7. Piercing Saddle Valve 13. 4X #10 Phillips Self Tapping Screws 2. Sediment Filter 8. Locking Clip (3/8”) 14.

  • Page 10: Preparation

    Product Information This manual covers the technical aspects of PURA Quick Change drinking water systems. It is important to read this manual thoroughly so that you can properly apply, install, and service these systems. The substances reduced by this system are not necessarily in the customer’s untreated water.

  • Page 11: Installation

    (figure 7) must be observed. The PURA drinking water system is designed to be mounted near a sink for easy access to cold water. Lengths of 1/4-inch and 3/8-inch OD plastic tubing will be required to make this installation.

  • Page 12: Step 1 Select Component Installation Locations

    The following steps will enable you to install the system quickly and orderly. Some variation may be necessary depending on the installation. See page 4 for a check list of tools and materials. typical installations follow this sequence: 1. Select Component Installation Locations 2.

  • Page 13: Step 2 Faucet Installation

    Step 2 – Faucet installation To simplify its access and installation, we suggest you install the faucet on the rear lip of the sink. It should be evenly positioned with the sink faucet and spray attachment. Should the spray faucet hole not be available for the installation, the sink must be drilled.
  • Page 14 Standard Faucet  Faucet Small Rubber Washer  Base  Large Rubber Washer  (Remove white protective film)   Lock Washer Plastic Washer  Faucet Adapter  Drinking Water Line to Faucet (3/8” Blue Tubing) Standard Faucet installation 1. Remove white protective film from faucet base. Install faucet body, small rubber washer, metal base, and large rubber washer above sink (items 1-4).

  • Page 15: Step 3 Install Adapter Valve On Water Supply

    Step 3 – install adapter Valve on Water Supply 1. Locate shut off valves on water lines under sink. To iden-  tify hot & cold supply pipes, turn on both faucets and let water run. Hot water pipe will be the warmer pipe. Turn off cold water supply valve.

  • Page 16: Step 4 Install Filter System Assembly

    Step 4 – install Filter System assembly The mounting bracket contains four mounting slots. The holes are sized to accept #10 round head wood screws (supplied). Some types of surfaces such as particle board or drywall, may require the use of plastic screw anchors or toggle bolts to provide adequate support for the unit.

  • Page 17: Step 5 Start Up

     Attach locking clips to each white elbow fitting. Clips should slide in behind collet on the fittings. Step 5 – Start-Up 1. Check system to verify all components are correctly installed 2. Open inlet valve and tank valve. 3. Check system thoroughly for leaks. If any are found, shut off both inlet and tank valves and correct the issue. 4.

  • Page 18: Service And Maintenance

    Service Schedule To keep the PURA system operating properly, it is necessary to change the filters and sanitize the system periodically. Typically, this should be done on an annual basis. Service frequency may vary depending on local water conditions. High sediment, chlorine, turbidity, or hardness levels may require more frequent service.

  • Page 19: Parts Breakdown

    Parts Breakdown        item # Description Qty. 134040U Manifold, Quick Change Ultrafilter, 4 Stage 41407001 Cartridge, Quick Change Sediment Filter - Stage 1 & 2 41407002 Cartridge, Quick Change Carbon Block - Stage 4 41407005 Cartridge, Quick Change Ultrafiltration Membrane - Stage 3 33501064...
  • Page 20 Other Parts 1. Faucet & Hardware – Part # 92192 2. Piercing Valve - Part # 92276 3. Locking Clip (3/8") – Part # 92346 4. Faucet Adapter – Part # 92652 5. Locking Clip (1/4") – Part # 92345 6.

  • Page 21: Troubleshooting

    Troubleshooting Guide If a problem cannot be corrected through the use of this troubleshooting guide please have the following information ready prior to calling the 1-800 number on the back of this manual: • Serial # • Model # Problem Possible Cause remedy Insufficient...

  • Page 22: Warranty Information

    PURA Guarantee Subject to the conditions and limitations described below, WaterGroup warrants its PURA Ultrafiltration Drinking Water Treatment Systems (excluding membrane and cartridge filters), when installed in accordance with WaterGroup specifications, to be free from defects in materials and workmanship under normal use within the operating specifications for a period of two (2) years from the date of purchase (with bill of sale).
  • Page 24 WaterGroup Companies, Inc. 580 Park Street Regina, SK, S4N 5A9, Canada USA Office: 193 Osborne Road Fridley, MN, 55432, USA www.pura.com 55026.1212...
